8 Control Panel

The keyboard is composed of four push button properly identified and protected: depending on the status
of each device button assumes a specific function, as described below.
Text or Combination
▲
▼
F UN C
MA N
Description of function associated
Configuration and operational
Skip to next parameter or group
Configuration and ongoing operational and edit
Increases the value of the parameter currently displayed
Operating with manual output
Increases the value of control output
Automatic Operation
If enabled, after 3 sec ill set point increases
Configuration and operational
Skip to the previous group or parameter
Configuration and ongoing operational and edit
Decreases the value of the parameter currently displayed
Operating with manual output
Decreases the value of control output
Automatic Operation
If enabled, after 3 sec the set point decreases
Operating
Release
Avoid the Change of the value displayed through the upper LCD.
Accept the changed value
Operating
T> 3 sec
Special Views: load current, leakage current, heating power, the cooling power, firmware version.
Configuration
Avoid the Change of the value of information displayed through the upper LCD.
Accept the changed value
Operating
Exit the current group
While editing a parameter abort editing
Operating
T> 3 sec
Set automatic or manual control mode
Configuration
Exit the current group
While editing a parameter abort editing
