CD Automation Revo TC User Manual page 41

CD Automation srl
RELATIVE COOLING GAIN
(availabele only with PID or PI - CntF <> onoF (miSC group of configuration) with at least one output
set as cooling)
Upper Display
Lower Display
Range
0.20 ↔ 1.00
When selftune is active and rCEn = On the range become
PAL = AIr
0.85 ↔ 1.00
PAL = OIL
0.80 ↔ 0.90
PAL = H2O
0.30 ↔ 0.60
DEAD BAND/OVERLAP through HEATING/COOLING OUTPUT
(available only with PID oe PI - CntF <> onoF (miSC group of configuration)) with at least one output
set as cooling)
Upper Display
Lower Display
Negative values indicate dead band, positive values indicate overlap.
Range
-20 ↔ 50
rC
Actual value
oLAP
Valore attuale.
pag. 41 di 121
