Selftune - CD Automation Revo TC User Manual

CD Automation srl
14.4 Control Group ( Cntr
PROPORTIONAL BAND
Upper Display
Lower Display
Range
No selftune with O2Fn ≠ Cool
1.0% ↔ 100.0% dello span
No selftune with O2Fn = Cool
1.5% ↔ 100.0% dello span
Selftune with O2Fn ≠ Cool
LPb2 ↔ HPb
Selftune with O2Fn = Cool
LPb1 ↔ HPb
HYSTERESIS
(available only with ON/OFF – CntF = onoF (miSC group of configuration))
Upper Display
Lower Display
Range
0.1% ↔ 10.0% of span or 1LSD
INTEGRAL TIME
(available only with PID or PI - CntF <> onoF (miSC group of configuration))
Upper Display
Lower Display
Range
00.01 ↔ 20.00 mm.ss
Beyond the maximum value, on display the integral action is excluded.
With selftune activated, the lower limit is given by Lti
Cntr ) Cntr Cntr
Pb
Actual value
HYS
Actual value for ON/OFF
ti
Actual value
pag. 39 di 121
