CD Automation srl
11 Functions
11.1 Special Functions
By pressing for 3 sec the keys UP and MAN and the lower display, if enabled, the load current.
The next press the same button for 3 seconds will return to the SetPoint
By pressing the F U NC key for 3 seconds, you can see on the lower display in the following order:
• A character A followed by the value of the load current output.
• A character b followed by the leakage current value of output.
• A character H followed by the output value of heating (0-100%)
•A character C followed by cooling output value (0 - 100%)
• A t character followed by the value of the cold junction temperature detected
• A v character followed by the firmware version
Some information is only available if the instrument is properly configured.
The display returns to normal operating mode by pressing the MAN.
Pressing the ▲ + F UN C for 3 seconds activates the lamp test: all segments of all digits of the display
and front LEDs are switched on and off with 1 Hz frequency (duty-cycle 50%) until next keypress MAN.
pag. 24 di 121
