Intelect® Neo Clinical Therapy System

COMPONENTS

Throughout these instructions the terms "left" and "right"
referring to the machine sides are from the perspective of
a user standing in front of the unit.
The Intelect® Neo Clinical Therapy System allows
installation of optional modality modules (except Vacuum
module) by the user. Speci cally designed for use with
the Intelect® Neo Clinical Therapy System, these modules
con gure the system to meet virtually every therapeutic
need that a clinician may have. The components of the
Intelect® Neo Clinical Therapy System are shown below.
NOTE: The Intelect® Neo Clinical Therapy System, when
ordered as a Tabletop System, without cart, is assembled
with Base, as shown below. The only user assembly
required is the installation of the desired Modules
described on page 7. Installation of the Vacuum module
is required by DJO-Authorized Service Persons.
Head
Cart
Modules
• Stimulation Channel 1/2
• Stimulation Channel 1/2 + sEMG
• Stimulation Channel 3/4
• Laser
• Ultrasound
• Vacuum (Shown in Cart above)
Base
3

SETUP

Cart with Vacuum Module
installed
