- Page 1 INSTALLATION INSTRUCTIONS FOR PART #20010 WATER / METHANOL INJECTION SYSTEMS © 2009, Snow Performance, Incorporated...
-
Page 2: Table Of Contents
Contact Us…………………………………………………….21 Have a question? Technical FAQ: www.snowperformance.net/faqs.php CAUTION You must completely read though these instructions before installing and operating this product. Failure to due so can result in damage to this product and the vehicle. © 2009, Snow Performance, Inc... -
Page 3: Kit Contents
2.5 Gallon Reservoir Solenoid Required Tools Hose Adaptor or Bung Electric Drill w/ Drill Bits Level Switch Utility Knife SafeInjection® Screwdriver – Phillips Nitrobooster® Assorted Wrenches Dual Nozzle 1/8” – 27 NPT Tap Carburetor Plate Boost Juice © 2009, Snow Performance, Inc... -
Page 4: Introduction
The contents of this document are subject to change without prior notice. No part of or this entire document may be reproduced in any form without prior written permission of Snow Performance, Inc under the copyright except for private use. -
Page 5: Installation - Mechanical
The pump is a pusher type by design so it needs to be mounted as close to the reservoir as possible. Because the pump is oversized, injection pressure will not be affected. A Solenoid Upgrade is recommended for rear mounted reservoirs. © 2009, Snow Performance, Inc © 2009, Snow Performance, Inc... - Page 6 Ensure there are no kinks in the tubing and insert tubing into quick disconnects at pump and reservoir until fully seated. Keep the pump within 2 feet of the reservoir. © 2009, Snow Performance, Inc © 2009, Snow Performance, Inc...
- Page 7 Warranty Policy Assemble desired nozzle into nozzle holder using E6000® sealant. The Snow Performance, Inc. warrants that the Product shall conform to end of the nozzle with the fine mesh screen is to be inserted into and perform in accordance with published technical specifications the nozzle holder.
- Page 8 This is a high performance product – use at your own risk. Snow Performance Inc., Its agents, employees or owners shall not be under any liability whether in contract or otherwise whether or not resulting from our negligence or contents of The nozzle is mounted using its external 1/8 NPT threads.
- Page 9 Connect the second BLACK wire to a secure chassis ground location. © 2009, Snow Performance, Inc © 2009, Snow Performance, Inc...
-
Page 10: Installation - Electrical
The YELLOW wire at position 2 is not used in boost referenced applications. Always have a good electrical ground connection. A poor ground will result in erratic operation of controller. © 2009, Snow Performance, Inc © 2009, Snow Performance, Inc... -
Page 11: Variable Controller Tuning
• For best performance, cooling, and system life it is recommend that Adjust the START boost Snow Performance Boost Juice™ (#40008) be the exclusive fluid level first by turning dial clockwise to ½ to 1/3 the engines max boost. This sets the boost pressure required to activate the injection used in the system. -
Page 12: Testing The System
Pump should be off at this point, apply light air pressure into vacuum tube connection on back of controller. Pump should activate while low pressure is applied but not enough to completely atomize fluid. © 2009, Snow Performance, Inc © 2009, Snow Performance, Inc...
