INSTALLATION INSTRUCTIONS
of January 1, 2010. Note that this information is subject to change.
Please refer to www.snowperformance.net for current information.
FOR PART #20001
FORCED INDUCTION
BOOST COOLER® WATER /
METHANOL INJECTION
SYSTEMS
© 2010, Snow Performance, Inc
© 2010, Snow Performance, Incorporated
Advertisement
Related Manuals for Snow Performance 20001
Summary of Contents for Snow Performance 20001
- Page 1 The contents of this document are subject to change without prior notice. No part of or this entire document may be reproduced in any form without prior written permission of Snow Performance, Inc under the copyright except for private use.
- Page 2 Snow Performance, Inc installing and operating this product. Failure to do so can 1017-A East Highway 24 result in damage to this product and the vehicle. Woodland Park, CO 80863 © 2010, Snow Performance, Inc © 2010, Snow Performance, Inc...
- Page 3 Parts Snow Performance, Inc. warrants that the Product shall conform to and perform in UHO (Ultra High accordance with published technical specifications and shall be free of defects in materials Output) Pump and workmanship for 90-days providing: 3 Qt Reservoir 1.
- Page 4 This is a high performance product – use at your own risk. Snow Performance Inc., Its agents, employees or owners shall not be under any liability whether in contract or otherwise whether or not resulting from our negligence or contents of information supplied for any damage or loss resulting from such information.
- Page 5 Connect the second BLACK reservoir and pump. wire to a secure chassis ground location. © 2010, Snow Performance, Inc © 2010, Snow Performance, Inc...
- Page 6 2 feet of the reservoir. Connect other black wire from level switch to white wire from • LED. Connect red wire from LED to +12 volt key on power source. • © 2010, Snow Performance, Inc © 2010, Snow Performance, Inc...
- Page 7 For best performance, cooling and system life it is recommend that end of the nozzle with the fine mesh screen is to be inserted into Snow Performance Boost Juice™, part #40008, be the exclusive the nozzle holder. Torque 1/2 turn past finger tight. Do not use Teflon fluid used in the system.
- Page 8 NOTE: If nozzle is mounted lower then the reservoir, a Solenoid Upgrade (#40060) must be used to prevent draining. #20001 Set Boost Switch Activation Point At the factory setting, the boost switch will start injection at about 10 psig boost. Adjusting the set screw clockwise will increase the boost pressure needed to activate injection.
- Page 9 (including use of a carb spacer plate) or below the reservoir, a Solenoid Upgrade (#40060) must be used to prevent siphoning at idle or gravity feed. © 2010, Snow Performance, Inc © 2010, Snow Performance, Inc...
- Page 10 CAUTION: Do not route wires near hot or moving parts. Use the tubing and make a fresh cut using a razor blade. corrugated wire loom and tie wraps (supplied) to protect and route wires. © 2010, Snow Performance, Inc © 2010, Snow Performance, Inc...
