Snow Performance Boost Cooler
CAUTION
:
You must completely read through these instructions before installing and operating
this product. Failure to do so can result in damage to this product and the vehicle.
Congratulations on your purchase of a Snow Performance Boost Cooler® Gas Water-Methanol
Injection kit! Keep these instructions for reference. First locate the part# of your injection system
which can be found on the front of the Boost Cooler® box. Use this number to identify which set of
Required Tools Needed For Install:
Phillips/Flat Head Screwdriver
Power Drill
Razor Blade
Preferred Electrical Connectors (Crimping/Stripping Tools, Blue Butts, Eye Hooks, Posi-Taps,
Fuse Taps, Soldering Supplies etc)
Spare 16 Gauge Wire (Optional Depending On Install)
Open End Wrench / Socket Set
1/8" – 27 NPT Tap (Optional Depending On Install)
Average Install Time: 4-6 Hours
Locate the wiring diagram for your injection kit further in these instructions beginning
on page 8 for overview of system layout before attempting install.
Gas Water-Methanol Injection Kit Instructions
®
(Part #'s 20010/20010-BRD & 212/212-BRD)
Version: 1.0
electrical and setting instructions to follow.
Page | 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Boost Cooler 20010-BRD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Snow Performance Boost Cooler 20010-BRD

  • Page 1 Failure to do so can result in damage to this product and the vehicle. Version: 1.0 Congratulations on your purchase of a Snow Performance Boost Cooler® Gas Water-Methanol Injection kit! Keep these instructions for reference. First locate the part# of your injection system which can be found on the front of the Boost Cooler®...
  • Page 2 Step 1 Self Sealing Low Level Sensor Install (Optional) Although not required for kit operation, the low level sensor and yellow led are a great way to monitor the level of your water-meth tank. The level sensor is designed to turn on the led or alert the controller in some kits as soon as the level inside the reservoir reaches the level of the sensor.
  • Page 3: Step 2 Tank Install

    Step 2 Tank Install OPTIONAL: If desired you can use the stock windshield washer fluid tank as the tank for your water- meth system. Simply drill and tap a 3/8” NPT hole in desired feed spot for system and install the 3/8” NPT fitting into the tank using E-6000 sealant on threads/around area.
  • Page 4 Step 3 Pump Install Braided Line Kits Only- Install (2) 3/8” NPT to 4AN Straight fittings into the pump inlet and outlet using E6000® sealant on the threads. Do not overtighten as damage to the pump housing can occur. Quick Connect Kits Only-Remove the blue rubber plugs from the quick-connect fittings by first pushing the plug toward the pump, hold the grey collar against the pump, and gently pull the...
  • Page 5 **The end of the nozzle with the fine mesh screen should be inserted into the nozzle holder** **Teflon sealants are not compatible with methanol, and should not be used with the install of your Snow Performance Boost Cooler ** Page | 5...
  • Page 6 Step 5 Nozzle Mounting Typical nozzle placement is approximately 6” or less before the throttle body inlet on the vehicle but the nozzle can be installed anywhere on the intake pipe after an intercooler outlet/supercharger outlet/turbo outlet. The nozzles should always be placed after an intercooler due to the possibility of the narrow passages and loss of air velocity leading to puddling.
  • Page 7 Braided line kits - Fit the NPT thread to 4AN adapters in each side of the check valve using E-6000 sealant on the NPT threads only. Connect the 5 foot section of braided line from the pump outlet to check valve inlet and the 1’...
  • Page 8: Wiring Diagram

    Part #’s 20010/20010-BRD & 212/212-BRD Wiring Diagram Step 1 VC-30 Wiring/Boost Source 1. Plug your MAP Sensor/Controller connector into the VC-30. 2. Connect your MAP sensor to the wire strand with the (Green, White, Black) wires. 3. Connect your Controller to the wire strand with the (Green, Black, Red, Blue) wires. 4.
  • Page 9: Controller Operation

    Controller Operation Once the controller has 12V positive power it will turn on (We recommend to wire in your power source to a • switch so you have the ability to turn on/off your system at your own will. This controller is progress able to 30 PSI, but will operate at 100% after the 30 PSI. •...
  • Page 10 When you press the MODE button three times the screen will change to your Max Boost reference screen. • At this boost level you will be injecting 100%. (Max is 30psi, anything above 30psi will continue at 100%) If you have any questions about your controller please feel free to contact our technical support at: •...
  • Page 11: Maintenance

    This is a high performance product – use at your own risk. Snow Performance Inc., Its agents, employees or owners shall not be under any liability whether in contract or otherwise whether or not resulting from our negligence or contents of information supplied for any damage or loss resulting from such information.
  • Page 12 Return Policy: All returns must be called in for RMA #. Snow Performance will not take used kits or parts for refund. If you are returning an unused kit there is a 15% restocking fee minus shipping/handling. All returns must be made within 30 days of purchase date. No exceptions.
