Zaxcom RX12
Left Side
1. QRX212 Module Position 2
2. QRX212 Module Position 1
3. UHF Antenna B Loop through RF Out – The RF out is after the 35MHz filter and has 3dB of gain.
4. QRX212 Module Position 3
5. QRX212 Module Position 4

Rear

1. Vent Fan
1
4
2
5
1
6
Left Side / Rear
3
