modway EEI -1328 Assembly Instructions/Use And Care Manual page 4

EEI -1328
DESK
STEP 2:
Place 1pc Center Drawer Front (J1),1pc Center Drawer Back (J4),1pc Center Left Drawer Side (J2),
1pc Center Right Drawer Side (J3) and 1pc Center Drawer Bottom (J5) together as shown.
Attach them by 1pc Cam Post (a), 1pc Cam (b), 4pcs Screw (c), tighten the Screws (c) and Cam (b)
Attach 2pcs Knob (e) to the Center Drawer Front (H1) by using 2pcs Pull Screw (d).
Fully tighten Cams (b), Screws (c), Pull Screws (d) with Phillips Head Screw Driver (not included).
ax2 bx2
STEP 3:
Place the assembled Center Drawer upside down on a carpeted or padded surface.
Attach the 6pcs Drawer Bottom Holder (n) to the bottom of the assembled Center Drawer by using 6 pcs Screw (g) as shown.
Use Phillips Head Screwdriver (not included) to tighten the Screws (b) clockwise until secure.
Phillips Head Screwdriver
gx6 nx6
Customer Service 908-368-1025︱ ︱ ︱ ︱ www.modwayfurniture.com
e
J4
e
cx4 dx2 jx2
g
J2
g
n
J1
( not included)
J3
b
a
d
J5
d
a
b
J2
Phillips Head Screwdriver
Hardware & Tools required
( not included)
g
J4
g
n
J5
Hardware & Tools required
j
J1
j
g
n
J3
Page 4 of 8
