- Page 1 OPERATOR'S MANUAL SC Setting Tool (Applicable model: SC-33) www.furuno.com...
-
Page 3: Important Notices
• The operator of this equipment must read and follow the descriptions in this manual. Wrong op- eration or maintenance can cancel the warranty or cause injury. • Do not copy any part of this manual without written permission from FURUNO. • If this manual is lost or worn, contact your dealer about replacement. -
Page 4: Table Of Contents
TABLE OF CONTENTS FOREWORD ........................iii OPERATIONAL OVERVIEW ..................1 1.1 Minimum PC Requirements ..................1 1.2 Connection between PC and NMEA2000 Network............1 Destination to Save ...................... 2 1.4 How to Start and Close the SC Setting Tool ..............2 ™ 1.4.1 How to connect a PC to the SATELLITE COMPASS ......... -
Page 5: Foreword
NMEA2000 network. Use this software for the initial setting after the in- stallation, setting adjustment or performance check in the maintenance. This software is available for the SC-33. This software can be downloaded from FURUNO Tech-Net. Standards Used in this Manual ®... -
Page 6: Operational Overview
OPERATIONAL OVERVIEW Minimum PC Requirements The following table shows the minimum specifications required to run the SC setting tool: Item Requirements 1 GHz or more 1 GB for 32bit; 2 GB for 64bit Screen Resolution 1280 720 or more Operating System (OS) ®... -
Page 7: Destination To Save
Destination to Save Download the SC setting tool from FURUNO Tech-Net in advance and save the executable file of the SC setting tool (file name: "SC_Setting_Tool.exe") in the following location (folder). The SC setting tool does not require installation. - Page 8 1. OPERATIONAL OVERVIEW ™ 2. Turn the power on the SATELLITE COMPASS that you want to setup. ™ Note: When multiple SATELLITE COMPASS are connected in the same NMEA2000 net- ™ work, the SC setting tool cannot find and connect to the SATELLITE COMPASS correctly.
-
Page 9: How To Close The Sc Setting Tool
To delete the SC setting tool, delete the executable file and folder for the SC setting tool. The folder location for the SC setting tool is shown as follows: • For 32 bit OS: C:\Program Files\Furuno\SC_Setting_Tool • For 64 bit OS: C:\Program Files(x86)\Furuno\SC_Setting_Tool Note: If you created a short cut for the SC setting tool, delete the short cut file. -
Page 10: How To Setup The Menu
HOW TO SETUP THE MENU Display Layout ™ Note: If connection between the PC and SATELLITE COMPASS is interrupted or stopped (PC battery, cable connection issues, etc), some or all settings may not be applied to the SATELLITE ™ COMPASS . -
Page 11: Gnss Setup] Tab
2. HOW TO SETUP THE MENU Name Remarks [Apply All] button Click this button to apply the settings on all tabs. The [Apply], [Apply All] and [Disconnect] buttons are grayed out while applying the set- tings. [Disconnect] button ™ Disconnect from the SATELLITE COMPASS and go back to the [Se- lect Device] dialog box. -
Page 12: Sensor Setup] Tab
2. HOW TO SETUP THE MENU [Sensor Setup] Tab ™ Enter the ship’s information and installation location of the SATELLITE COMPASS and adjust the sensor offset values on the [Sensor Setup] tab. Menu Item Remarks Sensor Offset HDG Offset the heading angle. When the heading angle is skewed right, enter a negative value. - Page 13 2. HOW TO SETUP THE MENU Menu Item Remarks Dimensions/ CALC-SPD-POSN Y1 Set the bow-stern location for calculating the 3-axis CCRP speed. Ship’s speed can be measured at two locations CALC-SPD-POSN Y2 in addition to the antenna position. Enter the backward distance from the reference position (center of the bow) to the position where you want to measure the ship’s speed.
-
Page 14: Pgn Setup] Tab
2. HOW TO SETUP THE MENU [PGN Setup] Tab ™ You can enable/disable PGN output from the SATELLITE COMPASS and adjust transmission rate on the [PGN Setup] tab. How to set the transmission rate ™ All PGNs that the connected SATELLITE COMPASS can output are shown on the [PGN Setup] tab. -
Page 15: Sky Plot] Tab
2. HOW TO SETUP THE MENU Simple diagnostic test Click the [Stat Diagnostic] button on the [Simple Diagnostic] tab to start the simple diagnostic test. ™ The simple diagnostic test checks the performance of the SATELLITE COMPASS . The following table shows the test result of the simple diagnostic test: Test Result Remarks... - Page 16 Select the antenna number to show the satellite information ([Anten- na 1] to [Antenna 4]). Note: [Antenna 1] and [Antenna 2] are available for SC-33. However you can select [Antenna 3] and [Antenna 4], the satellite information is not displayed.
-
Page 17: Menu Tree
APPENDIX 1 MENU TREE [SC_Setting_Tool] dialog box Default settings are GNSS Setup Disable SV GPS (Off, 1 to 32) shown in bold italic. Disable All (Unchecked) GLONASS (Off, 1 to 24) Disable All (Unchecked) Galileo (Off, 1 to 36) Disable All (Unchecked) QZSS (Off, 193 to 197) Disable All (Unchecked) SV ELEV (5 to 90°;... - Page 18 APPENDIX 1 MENU TREE 130577 (Direction Data) (Off, 20, 25, 100, 200, 1000, 2000 msec) 130316 (Temperature, Extended Range) (Off, 1000, 2000 msec) 130578 (Vessel Speed Components) (Off, 200, 250, 1000, 2000 msec) 130833 (Device Position and Ship Dimension Report) (Not used.) 130834 (Position of Speed Measurement) (Not used.) 130842 (Six Degrees of Freedom Movement) (Not used.) 130843 (Heel Angle, Roll Information) (Off, 20, 25, 50, 100, 200 msec)
