OPERATOR'S MANUAL
SATELLITE COMPASS
SC-33
Model
www.furuno.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SC-33 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Furuno SC-33

Summary of Contents for Furuno SC-33

  • Page 1 OPERATOR'S MANUAL SATELLITE COMPASS SC-33 Model www.furuno.com...
  • Page 3 How to discard a used battery Some FURUNO products have a battery(ies). To see if your product has a battery, see the chapter on Maintenance. Follow the instructions below if a battery is used. Tape the + and - terminals of bat- tery before disposal to prevent fire, heat generation caused by short circuit.

  • Page 4: Safety Instructions

    The voltage rating appears on the inlet of power. A warning label is attached to the equipment. Do not remove the label. If the label is missing or illegible, contact a FURUNO agent or dealer about replacement. CAUTION WARNING Observe the following compass safe To avoid electrical shock, do not remove cover.

  • Page 5: Table Of Contents

    TABLE OF CONTENTS FOREWORD ......................... iv SYSTEM CONFIGURATION ..................v MOUNTING ......................1 1.1 Equipment Lists......................1 1.2 Mounting Considerations .................... 3 1.3 Mounting Procedure....................8 WIRING ......................... 10 2.1 NMEA 2000 Network Connection ................10 2.2 NMEA 0183 Network Connection ................11 2.2.1 How to connect the Cable Assembly (FRU-NMEA-NFF-R15/30)......

  • Page 6: Foreword

    FOREWORD A Word to the Owner of the SC-33 Congratulations on your choice of the FURUNO SC-33 Satellite Compass. We are confident you will see why the FURUNO name has become synonymous with quality and reliability. Since 1948, FURUNO Electric Company has enjoyed an enviable reputation for quality marine electronics equipment.

  • Page 7: System Configuration

    SYSTEM CONFIGURATION SC-33 Satellite Compass NavNet Series, etc,. NMEA2000 Marine Instrument Junction Box IF-NMEASC Video Plotter NMEA0183 IF-NMEASC Radar INTERFACE UNIT Autopilot Current Indicator Scanning Sonar Video Sounder : Standard supply : Optional supply : Local supply 12-24 VDC...

  • Page 8: Mounting

    MOUNTING Equipment Lists Standard supply Name Type Code No. Remarks Satellite SC-33 Compass CP20-04400 000-035-094 For NavNet Series, etc,. With cable FRU-NMEA-PMMFF-060 (6 m) and Installation materials CP20-04401 Installation CP20-04410 000-035-095 For connecting IN-NMEASC, Materials (Select) With cable FRU-NMEA-NFF-R15 (15 m)
  • Page 9 1. MOUNTING Optional supply Name Type Code No. Remarks See OME-72651-x attached to Interface Unit IF-NMEASC the Interface Unit. FRU-NMEA-NFF-R15 001-507-080 For IF-NMEASC, 15m, φ6.7 Cable Assembly For IF-NMEASC, 30m, φ6.7 FRU-NMEA-NFF-R30 001-507-090 Replacement kit for SC-30 (MJ-A10SPF0015-xxxC) Contents - Waterproof relay box (JPBS 06) - 120 Ω...

  • Page 10: Mounting Considerations

    General considerations Mount the satellite compass above radar mast As shown in the figure below, mount the SC-33 satellite compass above a radar mast. This pro- vides an unobstructed path between the satellite compass and the satellite, regardless of vessel heading.
  • Page 11 • Separate the SC-33 at least 3 m from an open-type radar antenna. • If the SC-33 cannot be separated at least 3 meter from an open-type radar antenna, install it at least 80 cm above the top of the radar antenna.
  • Page 12 CONDITION 5: Select a stable location with minimal or no vibrations from engines or waves Install the SC-33 in a stable location. The SC-33 contains highly sensitive GNSS and angular speed sensors. Therefore, try to install it where shock, vibration, etc. are minimal.
  • Page 13 The deck is flat and metallic, or the area around the installation site is metallic • If metallic surface is wider than the area of the top view of the SC-33, install the SC-33 at least 800 mm above the deck.
  • Page 14 1. MOUNTING Installation examples for a pleasure boat No tuna tower Fixing holes should "surround" the sensor. Further, fix the mounting pole at a right angle. The recommended dimensions Fixing hole for the pole are: Sensor fixed to Diameter: more than φ80 mm a platform Length: less than 500 mm...

  • Page 15: Mounting Procedure

    1. MOUNTING Mounting Procedure Note 1: The bird-repellent fixtures (optional supply) can be attached to the antenna cover to pre- vent birds from landing on the cover. If it is more convenient to attach the bird-repellent fixtures before securing the antenna unit to the mounting location, do step 6 below before fixing the an- tenna unit.
  • Page 16 1. MOUNTING Note: Fasten the double nuts as Note: Fasten the double nuts as shown in the figure to the shown in the figure to the right. Use spanners with a right. Use spanners with a length of approx. 200 mm. length of approx.

  • Page 17: Wiring

    Using the supplied cable assembly, connect the SC-33 pigtail cable (Micro style connector) to the NMEA2000 network backbone. The SC-33 connects to the devices in an NMEA 2000 network with a drop cable, which is connected to a backbone cable w/T-type connectors. The backbone cable can be light or heavy type.

  • Page 18: Nmea 0183 Network Connection

    2. WIRING Guideline for Connecting Follow these guidelines when selecting a mounting location. • Where the cable connectors and CAN bus/NMEA2000 connectors are subjected to moisture or water spray, waterproof the connectors as shown below. 1. Wrap the connection point with a single layer of vinyl tape. 2.

  • Page 19: How To Connect The Cable Replacement Kit (Op20-50)

    2.2.2 How to connect the Cable Replacement Kit (OP20-50) Use a waterproof relay box (JPBS06) to relay connection when connecting to the SC-33 with the MJ-A10SPF0015-150C/300C cable used in SC-30. 1) Unfasten four washer head screws on the top of the waterproof relay box to remove the cover.
  • Page 20 2. WIRING 3) Fabricate the FRU-NMEA-PFF-060 cable as follows. 1) On the end of the side without the FRU connector, cut into the one end part of the FRU connector. Expose inner vinyl sheath by approx. 40 mm. Be careful not to damage inner shield and cores.
  • Page 21 2. WIRING 4) Connect the cables to the waterproof relay box. Connect the CAN cable ( FRU-NMEA-PFF-060 ) included to the cable replacement kit and the cable for SC-30 ( MJ-A10SPF0015-150C/300C ) to the internal terminal box. MJ-A10SPF0015-150C/300C MJ-A10SPF0015-150C/300C FRU-NMEA-PFF-060 FRU-NMEA-PFF-060 Waterproof Relay Box (JPBS06) Waterproof Relay Box (JPBS06)

  • Page 22: How To Secure And Waterproof The Cable Connections

    2. WIRING 2.2.3 How to secure and waterproof the cable connections Cable connection for the waterproof relay box, whether exposed to weather or otherwise, should be waterproofed and secured after making the connection. 1) Wrap the cap with several layers of self-bonding tape (supplied), to reduce the height differ- ence between the cap and the box.

  • Page 23: Adjustments

    Operator’s Manual for PC tools (SC_Setting_Tool: OME-72851). Once a heading has been found, the following items may need setting or adjustment. Also, when rebooting the SC-33, re-connecting of menu is required to operate from the TZTL12F/ 15F (V6. and after).
  • Page 24 3. ADJUSTMENTS Ship Size, ANT Position Set the installation location, antenna position and ship size. Menu Item Description Setting Range Ship’s Width Set the ship’s width. 1.0 m to 999.9 m Ship’s Length Set the Ship’s length. 1.0 m to 999.9 m Ship’s Height Set the Ship’s height.
  • Page 25 3. ADJUSTMENTS Setup the PGN data output. Select [0] to disable output, or select the required output cycle. Output Cycle MENU ITEM (ms) 065280 Heave 0 to 1000 126992 System Time 0 to 2000 126993 Heartbeat 0 to 60000 127250 Vessel Heading 0 to 6000 127251...
  • Page 26 3. ADJUSTMENTS Simple Diagnostic Test Run a diagnostic test. Menu Item Result Setting Range Start Diagnostic Set to carry out the easy self-test Start The following table lists the items which are tested, along with a description and the possible test results.
  • Page 27 3. ADJUSTMENTS Menu Item Description Result Magnetic Sensor Status Sub IMU Magnetic Sensor Status OK, NG, -- (no set) (Sub IMU board) test result Pressure Sensor Status Sub IMU Pressure Sensor Status OK, NG, -- (no set) (Sub IMU board) test result Antenna 1 Test Antenna 1 test result OK, NG, -- (no set)

  • Page 28: Nmea 2000 I/O Data

    NMEA 2000 I/O DATA The SC-33 handles the NMEA 2000 I/O data PGNs listed below. The LEN (Load Equivalency Number) is 11. (LEN is the amount of current a device draws from the NMEA 2000 network. 1 LEN = 50 mA.)

  • Page 29: Output Data

    Other setting change is possible other than the above used Furuno proprietary PGN. Name 126720 Variable Sensor Calibration Control Status NMEA-Command Group 130817 FURUNO GNSS Control Status 126208 Function 130818 Heading & Attitude Sensor Control Status 130819 Motion Sensor Control Status...
  • Page 30 250 ms - Proprietary PGN 130816 Self Test Report - Output for Self Test Group Function received. 130817 Furuno GNSS Control Status Note 2 - Proprietary PGN 130818 Heading & Attitude Sensor Control Status Note 2 - Proprietary PGN 130819...
  • Page 31 4. NMEA 2000 I/O DATA Note 1: PGN to output independently when “PGN: 059904” or “PGN: 126028” requested. Note 2: PGN to output independently when “PGN: 126028” requested. Note 3: PGN to output regularly when “PGN: 126028” requested.

  • Page 32: Maintenance, Troubleshooting

    MAINTENANCE, TROUBLE- SHOOTING This chapter provides the information for keeping your unit in good working order. NOTICE Do not apply paint, anti-corrosive sealant or contact spray to coating or plastic parts of the equipment. Those items contain organic solvents that can damage coating and plastic parts, especially plastic connectors.
  • Page 33 • Check that terminators (120 ohm) are attached at each end of the NMEA 2000 network. • Check that the input voltage to the SC-33 is between 9 to 32 VDC. • Check that all devices connected to the NMEA 2000 bus are within the current capacity of the bus.
  • Page 34 For SC-33, the detailed setting of the sensor is available from the TZTL12F/15F (V6.0 and after) via the NMEA network. Also, when rebooting SC-33, re-connecting of menu is required to operate from the TZTL12F/15F (V6.0 and after). Refer to the OPERATOR’S MANUAL for each models.

  • Page 35: Menu Tree

    APPENDIX 1 MENU TREE Bold Italic Default [Input / Output] PGN: 065280 (Heave) Set range (0 to 1000; 100) 0: Disable output PGN: 126992 (System Time) Set range (0 to 2000; 1000) 0: Disable output PGN: 126993 (Heartbeat) Set range (0 to 60000; 60000) 0: Disable output PGN: 127250 (Vessel Heading) Set range (0 to 1000;...
  • Page 36 APPENDIX 1 MENU TREE Bold Italic Default [System] System Information Main PCB Sub IMU PCB * Fixed “--” when the SUB_IMU board is not installed. MAIN CPU OS Version MAIN CPU Application Version GNSS1 * Displays “--” when the version is invalid. GNSS2 * Displays “--”...
  • Page 37 APPENDIX 1 MENU TREE Bold Italic Default [Advanced Sensor Setting] Rate Gyro Main X Percent Indication range (-8.0 to 8.0; 0.0) Main Y Percent Indication range (-8.0 to 8.0; 0.0) Main Z Percent Indication range (-8.0 to 8.0; 0.0) Main X Offset Indication range (-1999 to 1999;...

  • Page 38: What Is Sbas

    APPENDIX 2 WHAT IS SBAS? A satellite based augmentation system, or SBAS (Satellite Based Augmentation System), is an augmentation system that uses additional messages from satellite broadcasts to support regional and wide area augmentation. SBAS provides GPS signal corrections to SBAS users, for even bet- ter position accuracy, through the GPS error corrections that are widely broadcasted from the geo- stationary satellite.

  • Page 39: Specifications

    FURUNO SC-33 SPECIFICATIONS OF SATELLITE COMPASS SC-33 GENERAL Frequency L1 1575.42MHz (GPS/Galileo/QZSS), 1602.5625MHz (GLONASS) Tracking code C/A (GPS/QZSS), E1B (Galileo), 10F (GLONASS) Attitude accuracy Heading/ Roll/ Pitch: 0.4° rms Follow-up 45°/sec Heave accuracy 30 cm Attitude setting time 90 s approx.
  • Page 45 When a claim is made, FURUNO has a right to choose whether with other electronic devices. The imported product may also be to repair the product or replace it.
  • Page 46 24 months from installation date provided the work is done by Furuno U.S.A., Inc. or an AUTHORIZED Furuno dealer during normal shop hours and within a radius of 50 miles of the shop location.
  • Page 47 Цялостният текст на ЕС декларацията за съответствие може да се намери на следния интернет адрес: Spanish Por la presente, Furuno Electric Co., Ltd. declara que el tipo de equipo radioeléctrico arriba mencionado es conforme con la Directiva 2014/53/UE. (ES) El texto completo de la declaración UE de conformidad está disponible en la dirección Internet siguiente:...
  • Page 48 Az EU-megfelelőségi nyilatkozat teljes szövege elérhető a következő internetes címen: Maltese B'dan, Furuno Electric Co., Ltd., niddikjara li msemmija hawn fuq-tip ta' tag mir tar-radju huwa konformi mad-Direttiva 2014/53/UE. (MT) It-test kollu tad-dikjarazzjoni ta' konformità tal-UE huwa disponibbli f'dan l-indirizz...
  • Page 52 7KH SDSHU XVHG LQ WKLV PDQXDO LV HOHPHQWDO FKORULQH IUHH )85812 $XWKRUL]HG 'LVWULEXWRU'HDOHU  $VKLKDUDFKR 1LVKLQRPL\D  -$3$1 $  0$5  3ULQWHG LQ -DSDQ $OO ULJKWV UHVHUYHG 3XE 1R 20($ 0,68 6&           ...
