- Page 1 Innovative Infrastructure for Electric and Hybrid Vehicles HCS QUAD-MOUNT KIT INSTALLATION GUIDE...
- Page 2 PLEASE NOTE: , Inc. This installation guide includes the latest information at the time of printing. ClipperCreek, Inc. reserves the right to make changes to this product without further notice. Changes or modifications to this product by other than an authorized service facility may void the product warranty.
-
Page 3: Table Of Contents
, Inc. FIGURES ................................4 IMPORTANT SAFETY INSTRUCTIONS ..................... 5 INSTALLATION REQUIREMENTS ......................5 TOOLS REQUIRED FOR ASSEMBLING THE QUAD PEDESTAL KIT (HCS Series EVSE) ....6 PEDESTAL DIMENSIONS ..........................7 PACKING LISTS ............................. 8 HCS PEDESTAL KIT ..........................8 HCS QUAD-MOUNT KIT .......................... -
Page 4: Figures
HCS QUAD PEDESTAL KIT INSTALLATION GUIDE ClipperCreek FIGURES , Inc. 1. Pedestal Dimensions for Quad-Mount Installations ..................7 2. Pedestal Base Dimensions ..........................7 3. Installation Cross-Section ..........................7 4. Proper Distance from the Curb ........................10 5. Bolt Pattern Template Knockout ........................10 6. Pedestal Post Mounting by Pattern ......................11 7. -
Page 5: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS ClipperCreek , Inc. ClipperCreek Electric Vehicle Supply Equipment (EVSE) is designed with the safety concerns of the end user as an utmost priority; however, the following safety precautions must be read and followed: • The EVSE and electrical wiring should be installed by a qualified electrician in accordance with local electrical codes and ordinances. -
Page 6: Tools Required For Assembling The Quad Pedestal Kit (Hcs Series Evse)
ClipperCreek TOOLS REQUIRED FOR ASSEMBLING THE QUAD , Inc. PEDESTAL KIT (HCS Series EVSE) The following tools are required for the installation and assembly of the pedestal components. • L-shape T27 Torx Driver, in a variety of lengths for faster assembly. (Alternatively, a ratcheting driver can be used. -
Page 7: Pedestal Dimensions
HCS QUAD PEDESTAL KIT INSTALLATION GUIDE ClipperCreek , Inc. PEDESTAL DIMENSIONS Figure 1: Pedestal Dimensions for Quad-Mount Installations HCS Quad Two Front-Facing EVSEs Four EVSEs 33.5” 15” 9.5” 28” 20” 48” 3” 14” 14” 14” 23.75” Figure 2: Pedestal Base Dimensions... -
Page 8: Packing Lists
HCS QUAD PEDESTAL KIT INSTALLATION GUIDE ClipperCreek , Inc. PACKING LISTS 0300-00-033 HCS Pedestal Kit, Standard 4 Foot, Extension and Quad Kit Compatible Part Number QTY Description 1003-0014 Pedestal Metalwork, Cap with Rear Flange NOTE: This item may already be attached to the top of the pedestal. -
Page 9: Hcs Quad-Mount Kit
HCS QUAD PEDESTAL KIT INSTALLATION GUIDE ClipperCreek , Inc. PACKING LISTS (continued) 0300-00-031 HCS Quad-Mount Kit Part Number QTY Description 1003-0015 Pedestal Metalwork, Cap without Rear Flange 1003-0062 Pedestal Metalwork, HCS Quad Mounting Plate, Rev B 4000-0005 Machine Screw, Pan Head, 8-32, ½” Length, Phillips 4000-0011 Machine Screw, Tapered Flat Head, 1/4”... -
Page 10: Initial Pedestal Installation
HCS QUAD PEDESTAL KIT INSTALLATION GUIDE ClipperCreek INITIAL PEDESTAL INSTALLATION , Inc. 1. Concrete Pad Requirements Figure 4: Proper Distance from the Curb The location, dimensions, and composition of the concrete pad underlying the pedestal should always adhere to local building codes. -
Page 11: Mounting The Pedestal Post
HCS QUAD PEDESTAL KIT INSTALLATION GUIDE INITIAL PEDESTAL INSTALLATION (continued) ClipperCreek , Inc. 3. Mounting the Pedestal Post Figure 6: Pedestal Post Mounting by Pattern Once the concrete pad with anchor bolts has been prepared and the service conductors have been pulled... -
Page 12: Remove The Pedestal Post Cap
HCS QUAD PEDESTAL KIT INSTALLATION GUIDE ClipperCreek INITIAL PEDESTAL INSTALLATION (continued) , Inc. 5. Remove the Pedestal Post Cap Figure 8: Cap Removal A pedestal cap is provided to cover the opening to protect Remove the Cap and screws/washers the conductors and inner pedestal from the elements. It may have already been assembled on the post for protection during shipping. -
Page 13: Install The Hcs Quad Evse Mounting Plates
HCS QUAD PEDESTAL KIT INSTALLATION GUIDE INITIAL PEDESTAL INSTALLATION (continued) ClipperCreek , Inc. 7. Install the HCS Quad EVSE Mounting Plates Figure 10: The EVSE Mounting Plates An EVSE mounting plate is affixed to the front of the pedestal post to provide flat and rigid base on which the EVSEs can be mounted. -
Page 14: Install The Holsters
HCS QUAD PEDESTAL KIT INSTALLATION GUIDE INITIAL PEDESTAL INSTALLATION (continued) ClipperCreek , Inc. 8. Install the Holsters Figure 13: Mounting the Holsters The holsters, which are included with the EVSEs, are used to stow the vehicle connectors. To install, follow the steps below. -
Page 15: Connect The Wiring
HCS QUAD PEDESTAL KIT INSTALLATION GUIDE MOUNTING THE EVSES (continued) ClipperCreek , Inc. Figure 15: Mounting HCS EVSEs, Top Screws Figure 16: Mounting HCS EVSEs, Bottom Screws 3. Connect the Wiring Figure 17: Wiring and Conduit Placement The HCS has a flexible conduit extension with three conductors. -
Page 16: Final Pedestal Installation
HCS QUAD PEDESTAL KIT INSTALLATION GUIDE ClipperCreek FINAL PEDESTAL INSTALLATION , Inc. 1. Install the Pedestal Post Cap The pedestal cap is provided to cover the opening to protect the conductors and inner pedestal from the elements. Install the appropriate pedestal cap for the HCS Quad-Mount installation as described below. -
Page 17: Wrap And Stow The Vehicle Connectors
HCS QUAD PEDESTAL KIT INSTALLATION GUIDE FINAL PEDESTAL INSTALLATION (continued) ClipperCreek , Inc. 2. Wrap and Stow the Vehicle Connectors • Loosely wrap the cable around the HCS as shown in Figure 19. • Stow the Vehicle Connector in the holster. The button does not need to be pressed, simply insert until you hear the click to lock in place. -
Page 18: Customer Support
A Service Representative will call back at the earliest opportunity. Distributor Service Number Here TO CONTACT CLIPPERCREEK, INC. DIRECTLY FOR SERVICE CALL (877) 694-4194 MONDAY THROUGH FRIDAY BETWEEN 8:00AM AND 5:00PM PACIFIC TIME. Page 18... -
Page 19: Warranty Information
ClipperCreek or an authorized ClipperCreek representative or dealer has been advised of the possibility of such damages or of any claim by any other party. Some states do not allow the exclusion or limitation of incidental damages for some products, so the above limitation or exclusion may not apply to you. - Page 20 11850 Kemper Rd., Suite E Auburn, CA 95603 www.ClipperCreek.com (877) 694-4194...
