M30850T-EPB
Emulation Probe for M32C/80, 84, 85 and 86 Groups
User's Manual
Rev.2.00
April 1, 2004
REJ10J0345-0200Z

Advertisement

Table of Contents
loading

Related Manuals for Renesas Emulation Probe M30850T-EPB

Summary of Contents for Renesas Emulation Probe M30850T-EPB

  • Page 1 M30850T-EPB Emulation Probe for M32C/80, 84, 85 and 86 Groups User's Manual Rev.2.00 April 1, 2004 REJ10J0345-0200Z...
  • Page 2 • These materials are intended as a reference to assist our customers in the selection of the Renesas Technology product best suited to the customer's application; they do not convey any license under any intellectual property rights, or any other rights, belonging to Renesas Technology Corporation, Renesas Solutions Corporation or a third party.

  • Page 3: Precautions For Safety

    Preface The M30850T-EPB is an emulation probe for M32C/80, 84, 85 and 86 Groups MCUs. The M30850T-EPB is used by connecting to the PC7501 emulator main unit. This user's manual mainly describes specifications of the M30850T-EPB emulation probe and how to setup it.

  • Page 4: Table Of Contents

    Contents Chapter 1. Precautions for Safety ... 7 1.1 Safety Symbols and Meanings ... 9 Chapter 2. Preparation ... 19 2.1 Terminology ... 20 2.2 Package Components ... 21 2.3 Other Tool Products Required for Development ... 21 2.4 Name of Each Part ... 22 2.5 When Using the Emulator for the First Time ...
  • Page 5 4.2 Downloading Firmware ... 50 (1) When It is Necessary to Download Firmware ... 50 (2) Downloading Firmware in Maintenance Mode ... 50 4.3 Starting Up the Emulator Debugger (Setting the EMEM Dialog Box) ...51 (1) Setting the Debug Monitor Bank Address ... 52 (2) Selecting a Processor Mode ...
  • Page 6 MEMO ( 6 / 76 )

  • Page 7: Chapter 1. Precautions For Safety

    Chapter 1. Precautions for Safety This chapter describes precautions for using this product safely and properly. For precautions for the emulator main unit and the emulator debugger, refer to each user's manual included with your product. 1.1 Safety Symbols and Meanings ... 9 Warning for Handling This Product ...
  • Page 8 Note on Downloading Programs ... 17 Notes on Service-Life of the MCU's Internal Flash ROM ... 17 Note on Voltage Detect Circuit... 17 Notes on A-D Conversion ... 18 Note on Protect Resistor ... 18 Note on Applicable MCUs... 18 Note on Final Evaluation ...

  • Page 9: Safety Symbols And Meanings

    Chapter 1. Precautions for Safety In both the user's manual and on the product itself, several icons are used to insure proper handling of this product and also to prevent injuries to you or other persons, or damage to your properties. This chapter describes the precautions which should be taken in order to use this product safely and properly.

  • Page 10: Warning For Installation

    • If the emulator malfunctions because of interference like external noise, do the following to remedy the trouble. (1) Press the RESET switch on the emulator upper panel. (2) If normal operation is not restored after step (1), shut OFF power to the emulator once and then reactivate it.

  • Page 11: Important

    MCU. (7) Port P15 As one of I/O ports (P15) is connected to the target system through the analog switch circuit, electric characteristics slightly differ from those of an actual MCU.

  • Page 12: Notes On Target System

    • If using this product when the voltage of VCC1 is higher than that of VCC2, set the JP1 to VCC1>2. For the switch JP1, refer to "3.5 Setting Switches" (page 31). • When the JP1 is set to VCC1>2, the voltage of VCC2 on the target system should be 3.3 V or more.

  • Page 13: Notes On Clock Supply To An Mcu

    Notes on Clock Supply to an MCU: • Clock can be supplied to the evaluation MCU in one of the following three ways. This is determined by emulator debugger clock selection. (1) When Internal is selected: The clock generated by the oscillation circuit in the PC7501 is supplied to the evaluation MCU.

  • Page 14: Notes On Emem Dialog Box

    Notes on EMEM Dialog Box: Observe the following when setting up EMEM dialog box of the emulator debugger. (1) Debug Monitor Bank Address • When "F0" is specified, 64 KB of area starting from F00000h are allocated for use by the debug monitor.

  • Page 15: Notes On Address-Match Interrupt

    Notes on Address-Match Interrupt: • Do not single-step an address where an address-match interrupt occurs. • When using an address-match interrupt, do not check the box of "Enable the Address Match Interrupt Break Function" in the MCU tab of the Init dialog box. When not using an address-match interrupt, check the box.

  • Page 16: Notes On Stack Area

    Notes on Stack Area: • With this product, a maximum 20 bytes of the user stack is consumed as a work area. • If the user stack does not have enough area, do not use areas which cannot be used as stack (SFR area, RAM area which stores data, or ROM area) as work area.

  • Page 17: Note On Dma Transfer

    Note on DMA Transfer: • With this product, the user program is stopped with a loop program to a specific address. Therefore, if a DMA request is generated by a timer or other source while the user program is stopped, DMA transfer is executed.

  • Page 18: Note On Final Evaluation

    I/O port. When setting the register above, port P15 cannot be used as an I/O port even if A-D conversion is halting. For the switch SW5, refer to "3.5 Setting Switches" (page 31). • When setting the register below to use multi-port sweep mode, you need to set the direction register of port P15 for a pin that performs A-D conversion to "input".

  • Page 19: Chapter 2. Preparation

    This chapter describes the package components, the system configuration and the preparation for using this product for the first time. 2.1 Terminology ... 20 2.2 Package Components ... 21 2.3 Other Tool Products Required for Development ... 21 2.4 Name of Each Part ... 22 (1) System Configuration ...

  • Page 20: Terminology

    Chapter 2. Preparation 2.1 Terminology Some specific words used in this user's manual are defined as follows: Emulator system This means an emulator system built around the PC7501 emulator. The PC7501 emulator system is configured with an emulator main unit, emulation probe, host machine and emulator debugger. Emulator main unit (Hereafter PC7501) This means an emulator main unit for M16C Family MCUs.

  • Page 21: Package Components

    2.2 Package Components The M30850T-EPB package consists of the following items. When unpacking, check to see if your M30850T-EPB contains all of these items. Table 2.1 Package components M30850T-EPB emulation probe M30800T-PTC converter board for 100-pin LCC IC61-1004-051 100-pin LCC socket made by Yamaichi Electronics Co., Ltd. OSC-3 (32 MHz) oscillator circuit board OSC-2 oscillator circuit board (bare board) Hardware tool user registration FAX sheet (English)

  • Page 22: Name Of Each Part

    2.4 Name of Each Part (1) System Configuration Host machine Figure 2.1 System configuration • Emulation probe M30850T-EPB This emulation probe contains an evaluation MCU. • Converter board M30800T-PTC This is a converter board for connecting to the target system (for 100-pin 0.65-mm-pitch LCC socket).
  • Page 23 (1) System Status LEDs The system status LEDs indicate the emulator PC7501's power supply, firmware operating status, etc. Table 2.3 lists the definition of each system status LED. Table 2.3 Definition of the system status LEDs Name Status POWER Emulator system power supply is turned ON. Emulator system power supply is turned OFF.

  • Page 24: When Using The Emulator For The First Time

    For more information, see each user's manual of the emulator debugger and the PC7501. Within 2 seconds of turning the power ON, press the RESET switch of the PC7501 and check maintenance mode is accessed. Download firmware using the emulator debugger.

  • Page 25: Chapter 3. Setting Up

    This chapter describes switch settings required for using this product and how to connect this product to the PC7501 and the target system. 3.1 Selecting Clock Supply ... 26 3.2 Using an Internal Oscillator Circuit Board ... 27 (1) Kinds of Oscillator Circuit Boards ... 27 (2) Replacing an Oscillator Circuit Board ...

  • Page 26: Selecting Clock Supply

    Chapter 3. Setting Up 3.1 Selecting Clock Supply There are two ways to supply a clock to the MCU, using the oscillator circuit of the emulator or using the oscillator circuit on the target system. Table 3.1 lists the factory-settings of each clock supply. Table 3.1 Clock supply to the MCU Display of emulator debugger Clock...

  • Page 27: Using An Internal Oscillator Circuit Board

    3.2 Using an Internal Oscillator Circuit Board (1) Kinds of Oscillator Circuit Boards The PC7501 comes with an oscillator circuit board OSC-3 (30 MHz). And an oscillator circuit board OSC-3 (32 MHz) is included with this product. If you use the internal oscillator circuit board of the PC7501 as a main clock, choose "Internal"...
  • Page 28 2. Unscrew the screw of the oscillator circuit board of the PC7501 and replace it (see Figure 3.2). Figure 3.2 Replacing oscillator circuit boards 3. Reinstall the upper cover once removed and secure the four screws of the PC7501. When Removing the Upper Cover: •...

  • Page 29: Using The Oscillator Circuit Bare Board

    (3) Using the Oscillator Circuit Bare Board The oscillator circuit board OSC-3 (for 30 MHz) is preinstalled to the emulator main unit. To use it at 32 MHz, replace the board with the included OSC-3 (for 32 MHz). To use it at a frequency other than 30 or 32 MHz, build a desired oscillator circuit on the included OSC-2 oscillator circuit bare board.

  • Page 30: Using The Oscillator Circuit On The Target System

    3.3 Using the Oscillator Circuit on the Target System To operate this product with an oscillator circuit of the target system, input the oscillator output at 50% duty (within the operating range of the evaluation MCU) into pin X Pin X should be open.

  • Page 31: Using The Internal Oscillator Circuit

    Notes on External Clock: 3.5 Setting Switches Figure 3.7 shows the positions of the switches of the M30850T-EPBM. Table 3.2 lists how to set each switch. Figure 3.7 Positions of the switches IMPORTANT • The internal generator circuit is equipped for temporary debugging purposes.
  • Page 32 Table 3.2 Switch settings of the M30850T-EPBM (JP1, SW1 to SW4) Signal Switch VCC1 (Factory-setting) VCC2 AVCC AVSS AVCC (Factory-setting) AVSS AVCC AVSS (Factory-setting) XCIN (Factory-setting) XCOUT (Factory-setting) XOUT Setting 3.0 V ≤ VCC1 = VCC2 ≤ 5.5 V 4.8 V ≤ VCC1 ≤ 5.2 V and 3.3 V ≤ VCC2 < VCC1 Connects pins AVCC and AVSS of the MCU to the target system.
  • Page 33 Table 3.3 lists the examples of setting the switch SW5. It is necessary to change the setting when using the analog input port selection function of the A-D converter. By setting the SW5, it is possible to set each analog input pin when selecting an analog input port.
  • Page 34 Notes on Switch JP1: • If using this product when the voltage of VCC1 is higher than that of VCC2, set the JP1 to VCC1>2. • When the JP1 is set to VCC1>2, the voltage of VCC2 on the target system should be 3.3 V or more.

  • Page 35: A-D Conversion Bypass Capacitor

    3.6 A-D Conversion Bypass Capacitor There is a foot pattern on the M30850T-EPBM board for mounting bypass capacitors for the A-D conversion circuit. Mount applicable bypass capacitors as occasion demands. Figure 3.8 shows where they are installed. Figure 3.8 Foot pattern for the A-D conversion bypass capacitor Note on the A-D Converter: IMPORTANT •...

  • Page 36: Connecting The Pc7501

    3.7 Connecting the PC7501 Figure 3.9 shows how to connect the PC7501 and the emulation probe. Note: Connect the PCA7501EPBA board side to the M3T-FLX160-EPB. Figure 3.9 Connecting the PC7501 and emulation probe Note on Connecting the Cable: CAUTION • When connecting the emulation probe, be sure to hold the both sides of the emulation probe horizontally and insert it directly.

  • Page 37: Connecting The Target System

    3.8 Connecting the Target System There are eight ways available to connect the emulator to target systems as shown in Figure 3.10. Figure 3.10 Connecting the target system CAUTION Note on Connecting the Target System: • Take care not to attach the converter board in a wrong direction. It may cause a fatal damage to the emulator.

  • Page 38: Connecting To A 100-Pin Lcc Socket

    (1) Connecting to a 100-pin LCC Socket When connecting the emulation probe to a 100-pin LCC socket (Yamaichi Electronics Co., Ltd.: IC61-1004-051 etc.) on the target system, following the procedure below. (1) Attach the CN2 side of the M30850T-EPB to the CN2 side of the M30800T-PTC. (2) Attach the M30800T-PTC to the 100-pin LCC socket.

  • Page 39: Connecting To A 100-Pin 0.65-Mm-Pitch Foot Pattern (Part 1)

    (2) Connecting to a 100-pin 0.65-mm-pitch Foot Pattern (Part 1) Figure 3.12 shows how to connect the emulation probe to a 100-pin 0.65-mm-pitch foot pattern on the target system with the M3T-DUMMY100S (not included), and here following is its procedure. For details on the M3T-100LCC-DMS and M3T-DUMMY100S, refer to each user's manual.

  • Page 40: Connecting To A 100-Pin 0.65-Mm-Pitch Foot Pattern (Part 2)

    (3) Connecting to a 100-pin 0.65-mm-pitch Foot Pattern (Part 2) Figure 3.13 shows how to connect the emulation probe to a 100-pin 0.65-mm-pitch foot pattern on the target system with the M3T-DIRECT100S (not included), and here following is its procedure. For details on the M3T-100LCC-DMS and M3T-DIRECT100S, refer to each user's manual.

  • Page 41: Connecting To A 100-Pin 0.65-Mm-Pitch Foot Pattern (Part 3)

    (4) Connecting to a 100-pin 0.65-mm-pitch Foot Pattern (Part 3) Figure 3.14 shows how to connect the emulation probe to a 100-pin 0.65-mm-pitch foot pattern on the target system with the M3T-FLX-100NRB (not included), and here following is its procedure. For details on the M3T-100LCC-DMS and M3T-FLX-100NRB, refer to each user's manual.

  • Page 42: Connecting To A 100-Pin 0.5-Mm-Pitch Foot Pattern (Part 1)

    (5) Connecting to a 100-pin 0.5-mm-pitch Foot Pattern (Part 1) Figure 3.15 shows how to connect the emulation probe to a 100-pin 0.5-mm-pitch foot pattern on the target system with the M3T-100LCC-QSD (not included), and here following is its procedure. For details on the M3T-100LCC-QSD, refer to its user's manual.

  • Page 43: Connecting To A 100-Pin 0.5-Mm-Pitch Foot Pattern (Part 2)

    (6) Connecting to a 100-pin 0.5-mm-pitch Foot Pattern (Part 2) Figure 3.16 shows how to connect the emulation probe to a 100-pin 0.5-mm-pitch foot pattern on the target system with the M3T-FLX-100NSD (not included), and here following is its procedure. For details on the M3T-100LCC-DMS and M3T-FLX-100NSD, refer to each user's manual.

  • Page 44: Connecting To A 100-Pin 0.5-Mm-Pitch Foot Pattern (Part 3)

    (7) Connecting to a 100-pin 0.5-mm-pitch Foot Pattern (Part 3) Figure 3.17 shows how to connect the emulation probe to a 100-pin 0.5-mm-pitch foot pattern on the target system with the M3T-F160-100NSD (not included), and here following is its procedure. For details on the M3T-F160-100NSD, refer to its user's manual.

  • Page 45: Connecting To A 144-Pin 0.5-Mm-Pitch Foot Pattern

    (8) Connecting to a 144-pin 0.5-mm-pitch Foot Pattern Figure 3.18 shows how to connect the emulation probe to a 144-pin 0.5-mm-pitch foot pattern on the target system with the M3T-FLX-144NSD (not included), and here following is its procedure. For details on the M3T-FLX-144NSD, refer to its user's manual. (1) Attach the NQPACK144SD included with the M3T-FLX-144NSD to the target system.
  • Page 46 MEMO ( 46 / 76 )

  • Page 47: Chapter 4. Usage

    This chapter describes from turning on the power of this product to starting up the emulator debugger. 4.1 Turning On the Power ... 48 (1) Checking the Connection of the Emulator System ... 48 (2) Turning ON/OFF the Power ... 48 (3) LED Display When the Emulator Starts Up Normally...

  • Page 48: Turning On The Power

    Chapter 4. Usage 4.1 Turning On the Power (1) Checking the Connection of the Emulator System Before turning the power ON, check the connection of the interface cable with host machine, PC7501, emulation probe, and target system. (2) Turning ON/OFF the Power •...

  • Page 49: Led Display When The Emulator Starts Up Normally

    (3) LED Display When the Emulator Starts Up Normally Figure 4.1 shows upper panel LED lighting status when the emulator started up properly. Check it when starting up the emulator system. • If this LED does not light, check the voltage of the target system. •...

  • Page 50: Downloading Firmware

    Download the firmware in maintenance mode as explained here following. The target system must not be connected when downloading the firmware. (1) Set the interface select switch on the rear panel of the PC7501 to the LPT side and connect the LPT parallel interface cable to the PC7501 and the host machine.

  • Page 51: Starting Up The Emulator Debugger (Setting The Emem Dialog Box)

    4.3 Starting Up the Emulator Debugger (Setting the EMEM Dialog Box) The EMEM dialog box will appear after setting the Init dialog box by starting up the emulator debugger or completing downloading the firmware. Here explains how to set a processor mode of the target MCU, allocate the emulation memory and set the emulator work area.

  • Page 52: Setting The Debug Monitor Bank Address

    (1) Setting the Debug Monitor Bank Address With this product, consecutive 64 KB of the emulator's work area are allocated to the debug monitor. When "F0" is specified, 64 KB starting from address F00000h are allocated for use by the debug monitor.

  • Page 53: Setting Emulation Memory

    (3) Setting Emulation Memory This product has two kinds of emulation memory and how to allocate is different depending on which processor mode is selected. Table 4.2 shows how to set the emulation memory for each processor mode. Table 4.2 Setting the emulation memory Processor mode Internal flash memory F000h--FFFFh, F80000h--FFFFFFh...
  • Page 54 Notes on Using Emulation Memory for Expansion: • When single-chip mode or memory expansion mode is set as a processor mode, internal ROM area is automatically allocated to the internal flash ROM. Therefore, it is not necessary to deliberately specify emulation memory as expansion area in order to allocate the internal ROM area.

  • Page 55: Referring Mcu Status

    LEDs will change as shown in Figure 4.4. (1) If the target system is connected, disconnect it. (2) Within 2 seconds of activating power to the emulator, press the system reset switch on the emulator upper panel to switch the emulator to maintenance mode.
  • Page 56 POWER POWER SAFE CLOCK ERROR RESET WARNING SYSTEM TARGET STATUS STATUS Maintenance mode started ERROR 1 SAFE and ERROR flash ERROR 2 SAFE flashes and ERROR lights ERROR 3 SAFE and ERROR light alternately ERROR 4 SAFE goes out and ERROR lights Figure 4.4 Self-check procedure POWER...

  • Page 57: Chapter 5. Specifications

    Chapter 5. Specifications This chapter describes specifications of this product. 5.1 Specifications ... 58 5.2 Connection Diagrams ... 59 5.3 External Dimensions ... 61 (1) External Dimensions of the Emulation Probe... 61 (2) External Dimensions of Converter Board M30800T-PTC ... 62 (3) External Dimensions of Converter Board M3T-F160-100NSD ...

  • Page 58: Specifications

    Chapter 5. Specifications 5.1 Specifications Table 5.1 lists the specifications of the M30850T-EPB. Table 5.1 Specifications of the M30850T-EPB Emulator Applicable MCU Usable mode Emulation memory Maximum operating frequency Clock supply Operating voltage Operating temperature Storage temperature Power supply to emulator Connection to target system (see "3.8 Connecting the Target System"...

  • Page 59: Connection Diagrams

    5.2 Connection Diagrams Figures 5.1 and 5.2 show the connection diagrams of the M30850T-EPB. These connection diagrams mainly show the interface section. The signals not shown in Figures 5.1 and 5.2 are connected to the evaluation MCU in the emulation probe and the target system directly. The circuits not connected to the target system such as the emulator's control system are omitted.
  • Page 60 Figure 5.2 Connection diagram (2/2) Table 5.2 Electrical characteristics of the 74HC4066 Symbol Parameter ON resistor ON resistor difference Switch input leak current Measuring condition Min. 12.0 ( 60 / 76 ) Standard values Unit Standard Max. Ω ±100...

  • Page 61: External Dimensions

    5.3 External Dimensions (1) External Dimensions of the Emulation Probe Unit: mm Figure 5.3 External dimensions of the emulation probe ( 61 / 76 )

  • Page 62: External Dimensions Of Converter Board M30800T-Ptc

    (2) External Dimensions of Converter Board M30800T-PTC Figure 5.4 shows the external dimensions of the pitch converter board M30800T-PTC for 100-pin QFP (100P6S). Figure 5.4 External dimensions of pitch converter board M30800T-PTC ( 62 / 76 )

  • Page 63: External Dimensions Of Converter Board M3T-F160-100Nsd

    (3) External Dimensions of Converter Board M3T-F160-100NSD Figure 5.5 shows the external dimensions and the sample foot pattern of the converter board M3T- F160-100NSD for 100-pin LQFP (100P6Q). Figure 5.5 External dimensions of pitch converter board M3T-F160-100NSD (4) External Dimensions of Converter Board M3T-FLX-144NSD Figure 5.6 shows the external dimensions and the sample foot pattern of the pitch converter board M3T-FLX-144NSD for 144-pin LQFP (144P6Q).
  • Page 64 MEMO ( 64 / 76 )

  • Page 65: Chapter 6. Troubleshooting

    Chapter 6. Troubleshooting This chapter describes how to troubleshoot when this product does not work properly. 6.1 Flowchart to Remedy the Troubles ... 66 6.2 When the Emulator Debugger Does Not Start Up Properly ... 67 (1) When the LED Display of the PC7501 is Abnormal ... 67 (2) EMEM Dialog Box is Not Displayed at Debugger Startup (Target Connected)...

  • Page 66: Flowchart To Remedy The Troubles

    Figure 6.1 shows the flowchart to remedy the troubles from when power to the emulator is activated until the emulator debugger starts up. Check this while the target system is disconnected. For the latest FAQs visit the Renesas Tools Homepage. http://www.renesas.com/eng/products/mpumcu/toolhp/faq/m16c80/m16c80_e.htm...

  • Page 67: When The Emulator Debugger Does Not Start Up Properly

    6.2 When the Emulator Debugger Does Not Start Up Properly (1) When the LED Display of the PC7501 is Abnormal Table 6.1 LED's abnormal display and its checkpoints Error LEDs do not light up. All LEDs remain lit. The POWER LED of "STATUS OF TARGET"...

  • Page 68: Emem Dialog Box Is Not Displayed At Debugger Startup (Target Connected)

    (2) EMEM Dialog Box is Not Displayed at Debugger Startup (Target Connected) Table 6.2 Checkpoints of errors when starting up the emulator debugger (target is connected) Error Communication error occurred. Data was not sent to the target. Target system cannot be properly built. M3T-PD308F version is not the same version as the firmware in the target.

  • Page 69: Emem Dialog Box Is Not Displayed At Debugger Startup (Target Not Connected)

    (3) EMEM Dialog Box is Not Displayed at Debugger Startup (Target Not Connected) Table 6.3 Checkpoints of errors when starting up the emulator debugger (target is not connected) Error Communication error occurred. Data was not sent to the target. Target system cannot be properly built. M3T-PD308F version is not the same version as the firmware in the target.

  • Page 70: How To Request For Support

    6.3 How to Request for Support After checking the items in "Chapter 6 Troubleshooting", fill in the text file the installer of the emulator debugger generates in the following directory and email to your local distributor. \SUPPORT\product name\SUPPORT.TXT For prompt response, please specify the following information: (1) Operating environment •...

  • Page 71: Chapter 7. Maintenance And Guarantee

    Chapter 7. Maintenance and Guarantee This chapter describes how to maintenance, repair provisions and how to request for repair. 7.1 Maintenance... 72 7.2 Guarantee ... 72 7.3 Repair Provisions ... 72 7.4 How to Request for Repair ... 73 ( 71 / 76 )

  • Page 72: Maintenance

    Chapter 7. Maintenance and Guarantee 7.1 Maintenance If dust or dirt collects on any equipment of your emulation system, wipe it off with a dry soft cloth. Do not use thinner or other solvents because these chemicals can cause the equipment's surface coating to separate.

  • Page 73: How To Request For Repair

    After checking the contents of fault, the distributor should please send the faulty product along with the Repair Request Sheet to Renesas Solutions Corp. When the faulty product is repaired, it will be returned to the customer at the earliest convenience.
  • Page 74 MEMO ( 74 / 76 )
  • Page 75 M30850T-EPB User's Manual Rev.2.00 April 1, 2004 REJ10J0345-0200Z COPYRIGHT ©2003-2004 RENESAS TECHNOLOGY CORPORATION AND RENESAS SOLUTIONS CORPORATION ALL RIGHTS RESERVED...
