CONTACT TACHOMETER RPM MEASUREMENTS
1.
Install one of the RPM contact tips on the contact shaft.
2.
Move the Function switch to the CONTACT position.
3.
Press the Measure button while lightly pressing the contact tip
against the center of a rotating shaft.
4.
Release the Measure button when the display stabilizes
(approx. 2 seconds).
CONTACT LINEAR SURFACE SPEED (m/min ft/min) MEASUREMENTS
1.
Install the Linear speed wheel on the contact shaft.
2.
Slide the Function Switch to SURFACE SPEED "ft/min" or
"m/min" position.
3.
Press the Measure button and hold the surface speed wheel
against the moving surface being measured.
4.
Release the Measure button when the display stabilizes
(approx. 2 seconds).
www.ponpe.com
5
RPM Contact
Tips
Linear Speed
Wheel
RPM10-EU-EN-V2.2-3/11
