- Page 1 REG10J0017-0200 Renesas Starter Kit RSKM16C6NK User’s Manual RENESAS SINGLE-CHIP MICROCOMPUTER M16C FAMILY Rev.2.00 Renesas Technology Europe Ltd. Revision date： www.renesas.com 30.OCT.2007...
-
Page 2: Table Of Contents
Table of Contents Chapter 1. Preface ...1 Chapter 2. Purpose ...2 Chapter 3. Power Supply ...3 3.1. Requirements ...3 3.2. Power – Up Behaviour ...3 Chapter 4. Board Layout ...4 4.1. Component Layout ...4 4.2. Board Dimensions ...5 Chapter 5. Block Diagram ...6 Chapter 6. -
Page 3: Chapter 1. Preface
Cautions This document may be, wholly or partially, subject to change without notice. All rights reserved. Duplication of this document, either in whole or part is prohibited without the written permission of Renesas Technology Europe Limited. Trademarks All brand or product names used in this manual are trademarks or registered trademarks of their respective companies or organisations. -
Page 4: Chapter 2. Purpose
This RSK is an evaluation tool for Renesas microcontrollers. Features include: • Renesas Microcontroller Programming. • User Code Debugging. • User Circuitry such as Switches, LEDs and potentiometer(s). • User or Example Application. • Sample peripheral device initialisation code. The RSK board contains all the circuitry required for microcontroller operation. -
Page 5: Chapter 3. Power Supply
When the RSK is purchased the RSK board has the ‘Release’ or stand alone code from the example tutorial code pre-programmed into the Renesas microcontroller. On powering up the board the user LEDs will start to flash. After 200 flashes, or after pressing a switch the LEDs... -
Page 6: Chapter 4. Board Layout
Chapter 4. Board Layout 4.1. Component Layout The following diagram shows the top layer component layout of the board. E8a Header Figure 4-1: Board Layout... -
Page 7: Board Dimensions
4.2. Board Dimensions The following diagram gives the board dimensions and connector positions. All through hole connectors are on a common 0.1” grid for easy interfacing. Short Board = 85 mm 50.80 mm 43.18 mm 35.56 mm 27.00mm Other Serial D9 45.00mm 120.00mm 115.00mm... -
Page 8: Chapter 5. Block Diagram
Chapter 5. Block Diagram Figure 5-1 is representative of the CPU board components and their connectivity. Application Board Headers Microcontroller Pin Headers Debug Header Option Serial Connector Option Figure 5-2 is representative of the connections required to the RSK. Power Jack Option Boot mode pins Microcontroller RESn... -
Page 9: Chapter 6. User Circuitry
6.1. Switches There are four switches located on the RSK. The function of each switch and its connection are shown in Table 6-1. Switch When pressed the RSK microcontroller is reset. SW1/BOOT* Connects to an IRQ input for user controls. The switch is also used in conjunction with the RES switch to place the device in BOOT mode when not using the E8a module. -
Page 10: Serial Port
6.4. Serial port The microcontroller programming serial port 1 is connected to the RS232 connector. A serial port can be used by moving option resistors and fitting the D connector. This can be connected to serial channel 1 if the E8a is disabled from using channel 1; or serial channel 0 while the E8a is enabled. -
Page 11: Option Links
Circuit Net Name Ground No Connection R/W (Wired to Write only) No Connection No Connection DLCD4 DLCD6 6.6. Option Links Table 6-6 below describes the function of the option links associated with Power configuration. The default configuration is indicated by BOLD text. - Page 12 Table 6-7 below describes the function of the option links associated with Clock configuration. The default configuration is indicated by BOLD text. Reference Function External Oscillator R100 External Oscillator External Oscillator R103 External Subclock Oscillator R105 External Subclock Oscillator R106 External Subclock Oscillator Option Link Settings...
- Page 13 Table 6-8 below describes the function of the option links associated with Serial configuration. The default configuration is indicated by BOLD text. Reference Function Programming Serial Port Programming Serial Port Programming Serial Port Programming Serial Port Programming Serial Port RS232 Driver RS232 Driver Serial Connector Serial Connector...
- Page 14 Table 6-9 below describes the function of the option links associated with Analog configuration. The default configuration is indicated by BOLD text. Reference Function Analogue Power Analogue Power R109 VREF R110 VREF Table 6-10 below describes the function of the option links associated with microcontroller pin function select configuration. The default configuration is indicated by BOLD text.
- Page 15 Reference Function Microcontroller pin Connects microcontroller pin function select 28 to IICSDA Microcontroller pin Connects microcontroller pin 28 function select to TXD2 pin Microcontroller pin Connects microcontroller pin function select 27 to IICSCL Microcontroller pin Connects microcontroller pin 27 function select to RXD2 R114 Microcontroller pin...
- Page 16 Reference Function R128 Microcontroller pin function select R130 Microcontroller pin function select R118 Microcontroller pin function select R116 Microcontroller pin function select R131 Microcontroller pin function select R129 Microcontroller pin function select R117 Microcontroller pin function select R119 Microcontroller pin function select Microcontroller pin function select...
-
Page 17: Oscillator Sources
6.7.Oscillator Sources A crystal oscillator is fitted on the RSK and used to supply the main clock input to the Renesas microcontroller. oscillators that are fitted and alternative footprints provided on this RSK: 6.8. Reset Circuit The CPU Board includes a simple latch circuit that links the mode selection and reset circuit. This provides an easy method for swapping the device between Boot Mode, User Boot Mode and User mode. -
Page 18: Chapter 7. Modes
The RSK supports Boot mode and Single chip mode. Details of programming the FLASH memory is described in the M16C/6NK Group Hardware Manual. 7.1. Boot mode The boot mode settings for this RSK are shown in Table 7-1: Boot Mode pin settings below: The software supplied with this RSK only supports Boot mode using an E8a and HEW. -
Page 19: Chapter 8. Programming Methods
Chapter 8. Programming Methods The board is intended for use with HEW and the supplied E8a module. Refer to the M16C/6NK Group Hardware Manual for details of programming the microcontroller without using these tools. -
Page 20: Chapter 9. Headers
9.1. Microcontroller Headers Table 9-1 to Table 9-4 show the microcontroller pin headers and their corresponding microcontroller connections. The header pins connect directly to the microcontroller pins. * Marked pins are subject to option links. Circuit Net Name CAN1OUT TXD2 CLK3 E8_CNVSS CON_XCOUT... - Page 21 Circuit Net Name A19_LED3 A17_LED1 A15_IO7 A13_IO5 A11_IO3 A9_IO1 A8_IO0 A7_DLCD7 A5_DLCD5 A1_DLCDE Circuit Net Name AN7_CAN1STBn AN5_CAN0STBn ADPOT_AN0 CON_AVCC Device Circuit Net Name A18_LED2 A16_LED0 A14_IO6 A12_IO4 A10_IO2 UC_VCC2 GROUND A6_DLCD6 A4_DLCD4 A0_DLCDRS Table 9-3: J3 Device Circuit Net Name AN6_CAN1EN AN4_CAN0EN AVss...
-
Page 22: Application Headers
9.2. Application Headers Table 9-5 and Table 9-6 below show the standard application connections. * Marked pins are subject to option links. Generic Header Name RSK Signal Regulated Supply 1 Regulated Supply 2 Analogue Supply AVcc Analogue Reference AVref ADC0 ADPot_AN0* ADC2 DAC0... - Page 23 Table 9-7 to Table 9-9 below show the optional generic header connections. * Marked pins are subject to option links. Header Name RSK Signal CSan A23_CS0n CScn CS2n HWRn WRHn CASn Device Name CSbn SDCLK LWRn RASn Table 9-7: JA3 Optional Generic Header Header Name RSK Signal Name...
- Page 24 Header Name RSK Signal ADC4 AN4* ADC6 AN6* CAN0OUT CAN1OUT Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Header Name Host Serial SCIdTX Serial Port Serial Port Synchronous Serial Port Synchronous Reserved Reserved Reserved Reserved Reserved Reserved Reserved Device Name ADC5 ADC7 Reserved...
- Page 25 Table 9-10 below shows the CAN connections Function CAN0 Positive GROUND CAN0 Negative Function CAN1 Positive GROUND CAN1 Negative Table 9-10: CAN Headers Signal Name Device Pin CAN0H CAN0L Signal Name Device Pin CAN1H CAN1L...
-
Page 26: Chapter 10. Code Development
Chapter 10. Code Development 10.1. Overview Note: For all code debugging using Renesas software tools, the RSK board must be connected to a PC USB port via an E8a. An E8a is supplied with the RSK product. 10.2. Mode Support HEW connects to the Microcontroller and programs it via the E8a. -
Page 27: Memory Map
10.4. Memory Map Figure 10-1: Memory Map... -
Page 28: Chapter 11.Component Placement
Chapter 11.Component Placement Figure 11-1: Component Placement... -
Page 29: Chapter 12. Additional Information
For information about the M16C/6NK assembly language, refer to the M16C SeriesSoftware Manual. Online technical support and information is available at: Technical Contact Details America: techsupport.rta@renesas.com Europe: tools.support.eu@renesas.com Japan: csc@renesas.com General information on Renesas Microcontrollers can be found on the Renesas website at: http://www.renesas.com/renesas_starter_kits http://www.renesas.com/... - Page 30 Renesas Starter Kit for M16C/6NK User's Manual Publication Date Rev.02.00 30.OCT.2007 Published by: Renesas Technology Europe Ltd. Duke’s Meadow, Millboard Road, Bourne End Buckinghamshire SL8 5FH, United Kingdom ©2007 Renesas Technology Europe and Renesas Solutions Corp., All Rights Reserved.
- Page 31 Renesas Starter Kit for M16C/6NK User's Manual Renesas Technology Europe Ltd. Duke’s Meadow, Millboard Road, Bourne End Buckinghamshire SL8 5FH, United Kingdom...
