Summary of Contents for V-ZUG Adora TSLQ WP
-
Page 1: Operating Instructions
Operating instructions Adora TSLQ WP Tumble dryer... - Page 2 © V-ZUG Ltd, CH-6302 Zug, 2018...
-
Page 3: Table Of Contents
Contents Safety precautions 4 Favourites 20 General safety precautions ....... 4 Defining favourites.......... 20 Appliance-specific safety precautions .... 4 Changing favourites .......... 20 Instructions for use .......... 6 Deleting favourites.......... 21 Using for the first time........ 7 Starting favourites.......... 21 Note on the operating instructions .... 8 User settings 22 Appliance description... -
Page 4: Safety Precautions
Safety precautions General safety precautions conditions of overvoltage cat- egory III for full isolation, an isolating device must be in- ▪ Read the operating instruc- corporated into the perman- tions before using the appli- ently installed electrical install- ance for the first time! ation in accordance with the installation regulations. - Page 5 1 Safety precautions vaporizing medium. The use waterproof textiles, rubber of other substances may give backed articles and clothes rise to a toxic or fire risk. or pillows fitted with foam rub- ▪ The appliance has hot sur- ber pads should not be dried faces to evaporate active in the tumble dryer.
-
Page 6: Instructions For Use
1 Safety precautions from appliances burning gas inate, the hazard. or other fuels. Instructions for use ▪ Do not install the appliance Before using for the first time behind a door that locks, a ▪ The appliance must be installed and con- sliding door or a door with a nected to the electricity supply in accord- ance with the separate installation instruc-... -
Page 7: Using For The First Time
1 Safety precautions ▪ To protect your washing, follow the fabric Using for the first time care symbols and the hints and advice in The appliance must be installed and the 'Drying tips' section. connected to the electricity supply ▪ Do not operate the appliance without a by a qualified fitter/electrician in ac- door filter or with a damaged door filter. -
Page 8: Note On The Operating Instructions
Validity The product family (model number) corres- ponds to the first alphanumerics on the iden- tification plate. These operating instructions apply to: Appliance Adora TSLQ WP designation Type WTATSLQWPZ Product family 12006 Variations depending on the model are noted in the text. -
Page 9: Appliance Description
Appliance description Appliance construction Door filter with door filter mat Front grille Pivoting operating panel Identification plate / serial number (FN) Cover for door filter Ventilation grille Front filter mat Appliance door Indicator lights and button state Indicator lights Button state Illuminated: relevant function Blue background: relevant active... -
Page 10: Operating And Display Elements
2 Appliance description Operating and display elements Buntwäsche Coloureds Temperatur wählen Select programme Door opener Additional programme Normal dry 2 h 10 TouchDisplay Standard and Fabric types extra programmes Start/Pause 10 Eco (see End of programme additional functions) Favourites 11 EcoManagement Automatic programmes 12 Additional functions Automatic programmes... -
Page 11: Programme Overview
3 Programme overview Programme overview To avoid damaging the laundry, follow the fabric care symbols on garment labels: Tumble dry, medium heat Tumble dry, low heat Do not tumble dry Automatic programmes Automatic drying programmes have 3 phases: Drying The laundry is dried according to the settings. The laundry is cooled down to a temperature at which creasing is min- Cooling down / imized. -
Page 12: Fabric Types
3 Programme overview Fabric types Coloureds: Automatic programmes suitable for most tex- 1–7 kg tiles. Shirts: Fabrics are gently dried to «cupboard dry». max. 7 items Towelling: For drying thick towels and terry towelling. 1–3 kg Denim: Denim fabrics are dried to «cupboard dry». Follow 1–4 kg the fabric care symbols as denim material can shrink. -
Page 13: Additional Functions
3 Programme overview Additional functions Eco: The most energy-efficient programme, suitable for all fabrics. Provides energy savings of up to 19% depending on programme. Sprint: Quickest drying: Time saving: up to 23 minutes. Ultra care: Very gentle drying. The temperature is reduced. Particu- 1–2.5 kg larly suitable for fine textiles. -
Page 14: Operating The Appliance
4 Operating the appliance Operating the appliance Preparations ▸ Connect the mains plug into a suitable mains socket. ▸ Press the markings at the edge of door (5 dots) and open the appliance door. ▸ Loosely load wet laundry items one by one into the appliance. -
Page 15: Selecting Additional Functions
4 Operating the appliance Duration remaining indicator When the programme starts, the programme Extra dry duration at maximum load is displayed. The let- 0 h 59 ter «h» flashes for about 1 minute. During this Determining load time, the actual load is being determined and the expected duration remaining is being calcu- lated. -
Page 16: Delayed Start
4 Operating the appliance Delayed start ▸ Touch the button. Delayed start The adjacent TouchDisplay ap- pears. ▸ Enter the desired time delay before the programme starts. ▸ Touch the button. The delay before the pro- gramme starts is saved. ▸... -
Page 17: Interrupting A Programme
4 Operating the appliance Interrupting a programme Through opening the appliance door ▸ Open the appliance door. Extra dry The programme is interrupted. Pause Laundry can be added. Continue with button ▸ Close the appliance door. The adjacent TouchDisplay ap- pears. -
Page 18: End Of Programme
4 Operating the appliance 4.10 End of programme Display Depending on whether «EcoManagement» has been activated, information on the energy con- sumption is displayed when a programme ends. With «EcoManagement» The indicator light for the Extra dry button flashes. 0 h 00 The adjacent TouchDisplay ap- End of programme - Clean door filter pears. -
Page 19: Ecomanagement Statistics
4 Operating the appliance Each time after use ▸ Clean door filter (see page 25). ▸ Close appliance door. 4.11 EcoManagement statistics Energy consumption can be displayed before a programme starts or after a programme ends. Displaying the last programme ▸... -
Page 20: Favourites
5 Favourites Favourites Simple start to frequently used programmes. Defining favourites Note: The appliance door has to be open to define a favourite. ▸ Touch the button. ▸ Touch one of the favourite buttons. empty ▸ Select programme and ad- ditional functions. -
Page 21: Deleting Favourites
5 Favourites Deleting favourites ▸ Touch the button. ▸ Select the favourite programme to be deleted. extra dry ▸ Touch the button. Clear The favourite programme is deleted. Starting favourites ▸ Close the appliance door. ▸ Touch the button. ▸ Select the desired favourite programme. extra dry ▸... -
Page 22: User Settings
6 User settings User settings Providing no programme is running and no error message is displayed, the user settings can be changed with the appliance door open or closed. Preparations ▸ Touch the button. Extra The adjacent TouchDisplay ap- pears. Standard Airing ▸... -
Page 23: Childproof Lock
6 User settings EcoManagement When this function is activated, expected consumption values appear at the start of the programme and actual consump- Off tion values appear at the end of the pro- gramme. The stored consumption values Statistics can be deleted as well. Info ReversePlus When this function is activated, the wash-... - Page 24 6 User settings Background image The background image of the TouchDis- Background play can be turned off. In this case, the image background appears black. Off 6.10 Button tone The button tone can be turned on and off. The button tone for the buttons cannot be turned off.
-
Page 25: Care And Maintenance
7 Care and maintenance Care and maintenance To minimize the risk of fire hazard regularly clean the filters! A thick coating of fluff can trigger the «A9 Clean filter and mats» (see page 27) error mes- sage. Cleaning the door filter and door filter mat Cleaning the door filter (each time after tumble drying) ▸... -
Page 26: Cleaning The Front Filter Mat (Annually)
7 Care and maintenance Cleaning the front filter mat (annually) If the «A9 Clean filter and mats» error message still appears after the door filter and the door filter mat have been cleaned, the front filter mat must also be carefully cleaned. ▸... -
Page 27: Cleaning The Appliance
8 Trouble-shooting ▸ Clean the temperature sensor 2 with a damp cloth. ▸ Put back the front grille 1. Cleaning the appliance ▸ Wipe the outside of the appliance from time to time with a damp cloth and wipe dry. Trouble-shooting You may be able to trouble-shoot the following errors yourself. -
Page 28: Other Possible Problems
8 Trouble-shooting Display Possible cause Solution Insert front mat ▪ The front filter mat is ▸ Insert front filter mat correctly. not inserted correctly. ▸ Press the button. ▸ Restart the programme. FXX/EXX see in- ▪ Various situations can ▸ Press the button. - Page 29 8 Trouble-shooting Problem Possible cause Solution The laundry is ▪ The load contains ▸ Select a longer programme. not dry enough. mixed fabrics. ▸ Select the programme. ▸ Change the level of dryness. ▸ Check the mains plug, lead and fuses. ▪...
-
Page 30: Spare Parts
9 Spare parts Spare parts Please give model number and exact designation when ordering parts. Door filter Door filter mat Front grille Front filter mat Technical data Dimensions Ambient conditions Height 85 cm Permissible room temperature when appliance is in operation: Width 59.5 cm 5 °C to 35 °C... -
Page 31: Consumption Values
10 Technical data Data for the standard programme Load capacity Programme Energy Energy con- duration star rating sumption hrs./mins. 3h30 1.40 10.2 Consumption values The stated values for the programme duration and energy apply for the maximum stated ca- pacity with a wash spun at around 1200 rpm (corresponds to a moisture level of around 60%). -
Page 32: Drying Tips
11 Drying tips Towelling 1–3 -1 to 1 1h30 0.90 Drying tips 11.1 Saving energy ▪ Spin the washing in the washing machine at a high spin speed before tumble drying. Mech- anical draining in the washing machine is much more efficient than water evaporation in the tumble dryer. -
Page 33: Disposal
12 Disposal Disposal 12.1 Packaging Never allow children to play with packaging material due to the danger of injury or suffocation. Store the packaging material in a safe location or dispose of it in an environmentally-friendly way. 12.2 Safety Render the appliance unusable to prevent accidents caused by improper use (e.g. through children playing): ▸... -
Page 34: Notes
Notes... -
Page 36: Quick Instructions
You will find them on the identifica- V-ZUG will be happy to help you with any tion plate of your appliance. general administrative or technical queries, to accept your orders for accessories and spare parts and to inform you about our progressive service agreements.
