Installation instructions
Heat pump dryer
One-family household
Validity
The installation instructions apply to the models: 12011–12013
Warnings
For Service and Spare Part Information please contact: V-ZUG AUSTRALIA Pty. Ltd. Tel +61 7 3209 6822
The appliance should be installed by qualified personnel only.
Each step must be carried out and checked in full in the order specified.
Check the appliance for visible damage. Do not use the appliance if it is damaged in any way.
Transport the appliance in an upright position only! Transporting it in any other position will result in damage to the
appliance! When carried carefully without being shaken, the appliance may be tilted a maximum of 90° to the left
(viewed from the front).
The appliance must not be supplied through an external switching device, such as a timer, or connected to a circuit
that is regularly switched on and off by a utility.
Room size, room climate and ventilation
Keep all ventilation slits on the appliance clear and unobstructed. Otherwise an adequate supply of air is not guaran-
teed.
▸
Ventilate the room well. Ensure that the temperature of the room is between 5–35 °C.
▸
The room temperature must be kept between the range of 15–25 °C to ensure the economic running of the appliance.
Room size <10 m² (<20 m³)
▸
Room must be ventilated: There
must be air inlet and outlet openings
to the adjacent room or to the out-
side, e.g. open window/door, ventil-
ation grille or slits in the door or
ventilation system.
1068340-06
Room size ≥10 m² (≥20 m³)
1
1068340-06
03/10/2022
▸
Condensation may form on thermal
bridges! The room must therefore
be aired after running several con-
secutive drying programmes, e.g.
by opening a window or door to the
room.
