Understanding your AT&T Business in a Box® Equipment
AT&T Business in a Box® NextGen Base Unit Router
Ethernet LAN Ports
1GigE ports
3
© 2014 AT&T Intellectual Property. All rights reserved. AT&T, Globe logo and other marks are trademarks of AT&T Intellectual Property.
Ethernet WAN Ports
Electrical and Optical
Survivability Ports (2)
RJ11
T1 Ports (4)
Grey Cables from Smartjack to port.
Red cables for PRI
Analog voice port (22)
Customer Provided Cable to
Amphenol connector or to Breakout
Box.
