1-Second Phase Values; 1-Second Total Values - Satec PM172P Reference Manual

Address Point ID Description
+28,29 0x108E I3 Current angle
+30,31 0x108F Not used
13952-14017

1-Second Phase Values

+0,1 0x1100 V1/V12 Voltage
+2,3 0x1101 V2/V23 Voltage
+4,5 0x1102 V3/V31 Voltage
+6,7 0x1103 I1 Current
+8,9 0x1104 I2 Current
+10,11 0x1105 I3 Current
+12,13 0x1106 kW L1
+14,15 0x1107 kW L2
+16,17 0x1108 kW L3
+18,19 0x1109 kvar L1
+20,21 0x110A kvar L2
+22,23 0x110B kvar L3
+24,25 0x110C kVA L1
+26,27 0x110D kVA L2
+28,29 0x110E kVA L3
+30,31 0x110F Power factor L1
+32,33 0x1110 Power factor L2
+34,35 0x1111 Power factor L3
+36,37 0x1112 V1/V12 Voltage THD
+38,39 0x1113 V2/V23 Voltage THD
+40,41 0x1114 V3/V31 Voltage THD
+42,43 0x1115 I1 Current THD
+44,45 0x1116 I2 Current THD
+46,47 0x1117 I3 Current THD
+48,49 0x1118 I1 K-Factor
+50,51 0x1119 I2 K-Factor
+52,53 0x111A I3 K-Factor
+54,55 0x111B I1 Current TDD
+56,57 0x111C I2 Current TDD
+58,59 0x111D I3 Current TDD
+60,61 0x111E V12 Voltage
+62,63 0x111F V23 Voltage
+64,65 0x1120 V31 Voltage
14336-14343

1-Second Total Values

+0,1 0x1400 Total kW
+2,3 0x1401 Total kvar
+4,5 0x1402 Total kVA
+6,7 0x1403 Total PF
+8,9 0x1404 Total PF lag
+10,11 0x1405 Total PF lead
2
Options/Range Units
-1800-1800 ×0.1º
0-Vmax U1
0-Vmax U1
0-Vmax U1
0-Imax U2
0-Imax U2
0-Imax U2
-Pmax-Pmax U3
-Pmax-Pmax U3
-Pmax-Pmax U3
-Pmax-Pmax U3
-Pmax-Pmax U3
-Pmax-Pmax U3
0-Pmax U3
0-Pmax U3
0-Pmax U3
-1000-1000 ×0.001
-1000-1000 ×0.001
-1000-1000 ×0.001
0-9999 ×0.1%
0-9999 ×0.1%
0-9999 ×0.1%
0-9999 ×0.1%
0-9999 ×0.1%
0-9999 ×0.1%
10-9999 ×0.1
10-9999 ×0.1
10-9999 ×0.1
0-1000 ×0.1%
0-1000 ×0.1%
0-1000 ×0.1%
0-Vmax U1
0-Vmax U1
0-Vmax U1
-Pmax-Pmax U3
-Pmax-Pmax U3
0-Pmax U3
-1000-1000 ×0.001
0-1000 ×0.001
0-1000 ×0.001
2
Type R/W Notes
INT32 R
INT32 R
UINT32 R 1
UINT32 R 1
UINT32 R 1
UINT32 R
UINT32 R
UINT32 R
INT32 R
INT32 R
INT32 R
INT32 R
INT32 R
INT32 R
UINT32 R
UINT32 R
UINT32 R
INT32 R
INT32 R
INT32 R
UINT32 R 1 3-sec value
UINT32 R 1 3-sec value
UINT32 R 1 3-sec value
UINT32 R 3-sec value
UINT32 R 3-sec value
UINT32 R 3-sec value
UINT32 R 3-sec value
UINT32 R 3-sec value
UINT32 R 3-sec value
UINT32 R 3-sec value
UINT32 R 3-sec value
UINT32 R 3-sec value
UINT32 R
UINT32 R
UINT32 R
INT32 R
INT32 R
UINT32 R
INT32 R
UINT16 R
UINT16 R
36
