3.9 File Transfer Registers

Address Point ID Description

File Allocation Status Registers

3500,3501 File allocation map (bitmap)
3502,3503 Reserved
3504,3505 Daily profile log sections map (bitmap)
3506,3507 File memory size, Bytes
3508,3509 Free file memory size, Bytes
3510 Total number of records in the Event log file
3511 Total number of records in the Data log #1 file
3512 Total number of records in the Data log #2 file
3513 Total number of records in the Data log #3 file
3514 Total number of records in the Data log #4 file
3515 Total number of records in the Data log #5 file
3516 Total number of records in the Data log #6 file
3517 Total number of records in the Data log #7 file
3518 Total number of records in the Data log #8 file
3519-3526 Reserved
3527 Total number of records in the Waveform log #1 file
3528 Total number of records in the Waveform log #2 file
3529 Number of new records in the Event log file
3530 Number of new records in the Data log #1 file
3531 Number of new records in the Data log #2 file
3532 Number of new records in the Data log #3 file
3533 Number of new records in the Data log #4 file
3534 Number of new records in the Data log #5 file
3535 Number of new records in the Data log #6 file
3536 Number of new records in the Data log #7 file
3537 Number of new records in the Data log #8 file
3538-3545 Reserved
3546 Number of new records in the Waveform log #1 file
3547 Number of new records in the Waveform log #2 file

File Transfer Control/Status Registers

28160-28927
+0 File status (bitmap)
+1 Number of records logged in the file
E
Options/Range
F6
0
F7
1040384
0-1040384
0-65535
0-65535
0-65535
0-65535
0-65535
0-65535
0-65535
0-65535
0-65535
0
0-65535
0-65535
0-65535
0-65535
0-65535
0-65535
0-65535
0-65535
0-65535
0-65535
0-65535
0
0-65535
0-65535
F4
0 to 65535
Units Type R/W Notes
UINT32 R Bits set to 1 indicate that the
memory is allocated to the
designated files
UINT32 R
UINT32 R Bits set to 1 indicate that the
corresponding sections are allocated
in the Data log #8 file to the
designated energy/maximum
demand registers
UINT32 R
UINT32 R
UINT16 R
UINT16 R
UINT16 R
UINT16 R
UINT16 R
UINT16 R
UINT16 R
UINT16 R
UINT16 R
UINT16 R
UINT16 R
UINT16 R
UINT16 R
UINT16 R
UINT16 R
UINT16 R
UINT16 R
UINT16 R
UINT16 R
UINT16 R
UINT16 R
UINT16 R
UINT16 R
UINT16 R
1
UINT16 R
UINT16 R
