- Page 1 OPERATORS MANUAL & ILLUSTRATED PARTS LIST WL18000VE/B 60706-175...
-
Page 2: Table Of Contents
COPY YOUR MODEL AND SERIAL NUMBER HERE the operating instructions in this manual. No other WINCO generator has the same serial number as Should you experience a problem please follow the yours. It is important that you record the number and other “Things To Check”... -
Page 3: Specification & Wiring Diagram
UNIT SPECIFICATIONS WL18000VE/B GENERATOR Rotating Field W/External RECEPTACLES Voltage regulation Nema 5-20R GFCI (120V) 2 (20A Duplex) Surge Watts 18,000 Nema L5-20R GFCI Protected (120V) Continuous Watts 15,000 2 (20A Twistlock) Volts 120/240 Nema 5-50R (120V) 1 (50A Straight Blade) Amps 125/62.5 Nema L6-30R (240V) -
Page 4: Guide To Product Safety
This engine generator set has been designed and Keep a fire extinguisher nearby and know its manufactured to allow safe, reliable performance. Poor proper use. Fire extinguishers rated ABC by maintenance, improper or careless use can result in potential NFPA are appropriate. deadly hazards;... -
Page 5: Intended Uses
INTENDED USES UNIT PREPARATION These engine generator sets have been designed primarily Before your engine generator was shipped from our factory it for portable use. Both 120, 240 and 120/240 volt AC was fully checked for performance. The generator was load receptacles are provided in the 'control panel' to plug in your tested to its full capacity, and the voltage and frequency were loads (lights, portable tools, and small appliances). -
Page 6: Battery Installation
WARNING: FIRE DANGER 4 WHEEL DOLLY KIT Gasoline and its fumes are VERY explosive The WL18000 ships with a 4 wheel dolly kit as standard when proper precautions are not taken. equipment. The dolly kit comes with instructions and parts Never use fuel that has been stored for an extended period of list. -
Page 7: Stopping And Storage
Hot weather LOAD vs. OUTPUT __________________________________________________________________________________________________________________ Use the proper oil for the temperature Generator Frequency Voltage expected. Load Speed 120V Use only summer blended gasoline. Using Applied* (RPM) (HZ) Recpt. gasoline left over from winter may cause the __________________________________________________________________________________________________________________ None 3690 61.5 120V... -
Page 8: Wiring
Grounding 3. Many homes and construction sites are wired for at least 100 Amp entrance service, much greater than the All units must be grounded. Drive a 3/4 or 1" copper pipe or capacity of these portable generators. When installing rod into the ground close to the engine-generator set. -
Page 9: Generator Care
Cartridge Air Cleaner CLEANING Remove and clean cartridge yearly or after every 400 hours, Remove dirt and debris with a cloth or brush. DO NOT use whichever occurs first. Service more often if necessary. high pressure spray to clean either the engine or the Do not use petroleum solvents, such as kerosene, to attempt generator. -
Page 10: Engine Generator Assembly
98806-000 Flat Washer 3/8” 300430-1 Battery Tray 16250-000 Flangenut 3/8” 300143-2 Battery Hold Down Kit 91658-011 Hex Head Bolt 3/8” 98478-000 Decal, Winco 20604-000 Flat Washer 3/8” 15209-000 Warning Decal 16133-001 Leather Washer 63941-001 Hot Warning Decal 5210-20 Page 8... -
Page 11: Generator Assembly
Generator Assembly REF Part Number QTY Description REF Part Number QTY Description 16428-401 Generator Cover 16428-409 16428-402 Terminal Block 16428-410 Rear Bearing 16428-403 End Bracket & Housing 16428-411 Voltage Regulator 16428-404 Stator Assembly 16428-412 Stator Bolts 16428-405 Engine Adapter Bracket 16428-413 Air Screens 16428-406... -
Page 12: Month Warranty
To the extent permitted by law, any and all warranties, including those of merchantability and fitness for a particular purpose, are limited to 24 months from date of purchase. In no event is WINCO liable for incidental or consequential damages.
