3.2 PC/Other Devices to 5-Port Gigabit
802.3af PoE Switch
You can connect this switch to PCs, servers, and other
network devices using a straight-through Ethernet
cable.
3.3 Connecting a Powered Device to the
Switch Using Power over Ethernet (PoE)
Using a CAT5 cable, connect the powered device (PD)
to any of the four device ports on the switch. The
switch will detect the PD and supply 48-V power to
the device over the CAT5 cable.
NOTE: The PD must comply with the IEEE 802.3af
standard.
4. Operation
LED indicators on the 5-Port Gigabit 802.3af PoE
Switch's front panel show status.
Table 4-1. LEDs and their Functions.
LED Status Description
Green On Power to the unit is on and normal
Power
Off Power to the unit is off
Green/Yellow On Ethernet uplink port is connected
Green flashing Uplink data activity at 1000 Mbps
Uplink
Yellow flashing Uplink data activity at 100 Mbps
Flashing Uplink data activity at 10 Mbps
Green/Yellow On Ethernet uplink port is connected
Green flashing Ethernet uplink data activity at 1000 Mbps
LAN
Yellow flashing Ethernet uplink data activity at 100 Mbps
Flashing Ethernet uplink data activity at 10 Mbps
Green On PoE function is enabled
PoE
Off PoE function is disabled
724-746-5500 | blackbox.com
LPB1205A
5-Port Gigabit 802.3af PoE Switch
Black Box Tech
Support: FREE! Live.
24/7. Tech support
the way it should be.
Great tech support is just 30 seconds
away at 724-746-5500 or blackbox.com.
Customer
Order toll-free in the U.S.:
Call 877-877-BBOX
Support
(outside U.S. call 1-724-746-5500)
Information
FREE technical support
24 hours a day, 7 days a week:
Call 724-746-5500 or
fax 724-746-0746
Mailing address:
Black Box Corporation
1000 Park Drive
Lawrence, PA 15055-1018
Web site: www.blackbox.com
E-mail: info@blackbox.com
© Copyright 2011. Black Box Corporation. All rights reserved.
Black Box and the Double Diamond logo are registered trademarks of
BB Technologies, Inc. Any other trademarks mentioned in this manual
are acknowledged to be the property of the trademark owners.
LPB1205A, rev. 1
724-746-5500 | blackbox.com
Page 5
5-Port Gigabit 802.3af PoE Switch
Add 4 PoE devices to your
existing Gigabit LAN.

BLACK BOX

®
1. Specifications
Buffer Memory — 104 Kbits
Certifications — FCC Class A
Filtering/Forwarding Rates —
1000-Mbps port: 1,488,000 pps;
100-Mbps port: 148,800 pps;
10-Mbps port: 14,880 pps
MAC Address — 1 K
PoE — Supports up to 15.4 W for each PoE port,;
PoE power budget: 62 W; PD classification identify;
PoE overcurrent protection; PoE overcurrent
protection, PoE circuit sorting protection; PoE power
on RJ-45 Pins 3 and 6 for power +, Pins 1 and 2
for power -
Standards — IEEE 802.3 10BASE-T, IEEE 802.3u
100BASE-TX, IEEE 802.ab 1000BASE-TX, IEEE
802.3af Power over Ethernet
Transmission Media —
10BASE-T: CAT3, 4, 5 UTP/STP;
100/1000BASE-TX: CAT5e/6/7 UTP/STP
