ASI 0363 Installation Instructions

1. SPECIFICATIONS:

1. SPECIFICATIONS:
Dimensions (W x H x D) {inches (mm)}
Soap Tank Capacity {fl oz (ml)}
Battery Type Required
Battery Life Estimated
Detection Range Automatic,
manually adjustable {inches (mm)}
Room Temperature {°F (°C)}
Sensing Delay Time (msec)
Dispensing Volume {fl oz (ml)}
Applicable Viscosity Range {cP(MPas)}
Unit Net Weight empty {oz (kg)}
Operation Mode
Supply Reservoir Types
Pump Type

3. BEFORE INSTALLATION:

1.Provide vertical, clean and smooth mounting surface.
2.Make sure there is enough room above dispenser to access cover lock key.
3.Ensure there are no obstructions below unit in sensor zone.
4.Check operation of unit while holding in place by hand

4. RECOMMENDED INSTALLATION:

See No.3
4.83 x 10.63 x 4.17 (122 x 270 x 106)
30.4 (900)
Alkaline (1.5V) AA size, Qty 4
10,000 cycles or 1 year
2.40 (60) ± 1.50 (38)
41 ~ 104 (5 ~ 40)
500 ~ 1k
0.034 ~ 0.051 (1 ~ 1.5)
2000 ~ 5000
24.7 (0.7)
Automatic from Sensor Trigger
900 ml reusable (included) or 800 ml
disposable (supplied by others)
Peristaltic Tube (self contained valve/nozzle)
BEFORE permanent installation
WALL
DISTANCE
COUNTER TOP
DISTANCE (MINIMUM TYPICAL)
NORMAL COUNTER TOP
At least 7-7/8" (200)
STAINLESS STEEL COUNTER TOP
At least 11-13/16" (300)
FOR MODEL N

INSTALLATION INSTRUCTIONS

Tank cover

2. ITEM LIST:

Soap tank
Key
Lock
Nut
Valve tube
Cover
Spout nozzle
Cap
Electronic box
Hinge nut
Gate
Retainer
screw
Battery box

5.1 INSTALLATION STEPS, Tile or Dry Wall

1.Tape the installation template at the appropriate location on the mounting surface.
2.Drill four (4) holes at marked locations 1 /4" diameter (Ø6.4).
3.Insert four (4) plastic anchors (supplied) into drilled holes; remove template (fig. 1).
4.Insert two (2) screws (supplied) into top plastic anchors and leave 1/8" (3) space from
the wall under head (fig. 2 and fig. 3) for hanging dispenser.
5.Hang the dispenser on the two (2) screws through the keyhole slots at backplate top.
6.Use key to unlock and pull forward the housing cover (fig. 4 )
7.Remove soap reservoir and lock dispenser to wall with remaining two (2) screws
(supplied) through the holes at backplate bottom. Tighten all screws
¯6.4
SOAP DISPENSE R MOUNTIN G TEMPLATE 1/4" ( )
Item 5
fig.1

5.2 INSTALLATION STEPS, Adhesive on Mirror

1.Clean mounting surface in area to be installed with isopropyl alcohol.
2.Mark outline of dispenser on mirror with masking tape.
3.Remove paper liners from self-adhesive pads on dispenser backplate.
4.Place unit on mounting surface with even steady pressure and hold for 1 minute.
5.Let tape cure for 10 hours prior to filling dispenser with soap for use.
0362/0363
S
Illustration Q'ty
No. Description No.
Key on
1 2 6
ring
Installation
2 1 7
Instructions
Base plate
Installation
3 1 8
Template
Soap
9
4 1set
Dispenser
Plastic
4 10
5
Anchor
11
Hinge screw
Items all included in item 4
.
( fig. 5).
Item 6
fig.2
Illustration Q'ty
Description
Mounting
4
screw
Battery
1
box
Replacement
1
soap
tank
Lock
1
Nut
Repla cement
cover 1
only
Repla cement
electronic
1
box only
w/o battery
box
1/8" (3)
fig.3
fig. 4
fig. 5
