- Page 1 Instruction Manual Hawaii’s Finest Model No. 1027HD, 1027HDX 10700 Medallion Drive, Cincinnati, Ohio 45241-4807 USA Part No.12644...
-
Page 2: Safety Precutions
Hawaii’s Finest Model No. 1027HD, 1027HDX SAFETY PRECUTIONS DANGER Machine must be properly grounded to prevent electrical shock to personnel. Failure to do so could result in serious injury, or death. DO NOT immerse any part of this equipment in water. - Page 3 Gold Medal’s Technical Service Department at 1-800-543-0862 for any questions about your machine operations, replacement parts, or any service questions. (Gold Medal Products Co. does not assume any liability for injury due to careless handling and/or reckless operation of this equipment.) gmpopcorn.com...
- Page 4 Hawaii’s Finest Model No. 1027HD, 1027HDX General Operating Safety when using a Foot Switch WARNING Always use a grounded plug or cable. DO NOT cut off the ground prong and be sure to ground the foot switch with the ground screw provided.
-
Page 5: Installation Instructions
Hawaii’s Finest Model No. 1027HD, 1027HDX INSTALLATION INSTRUCTIONS Inspection of Shipment After unpacking, check thoroughly for any damage which may have occurred in transit. Claims should be filed immediately with the transportation company. The warranty does not cover damage that occurs in transit, or damage caused by abuse, or consequential damage due to the operation of this machine, since it is beyond our control (reference warranty in back of manual). -
Page 6: Electrical Requirements
4. DO NOT use a grounded to un-grounded receptacle adapter (where applicable). 5. Install the unit in a level position. CAUTION If the supply cord is damaged, it must be replaced by Gold Medal Products Co., its service agent or similarly qualified persons in order to avoid a hazard. 039_080614 gmpopcorn.com... -
Page 7: Controls And Their Functions
Hawaii’s Finest Model No. 1027HD, 1027HDX OPERATING INSTRUCTIONS Controls and Their Functions MAIN SWITCH Turns shaver motor “ON” or “OFF”. RESET SWITCH Motor overload switch. BLADE ADJUSTMENT KNOB Adjusts the blade height to change the ice texture. Main Switch Blade Adjustment... -
Page 8: Care And Cleaning
Hawaii’s Finest Model No. 1027HD, 1027HDX Care and Cleaning DANGER Machine must be properly grounded to prevent electrical shock to personnel. DO NOT immerse in water. Always unplug the equipment before cleaning or servicing. 025_020314 WARNING This machinery contains sharp blades. Keep hands and body parts clear at all times. -
Page 9: Maintenance Instructions
Hawaii’s Finest Model No. 1027HD, 1027HDX MAINTENANCE INSTRUCTIONS DANGER Machine must be properly grounded to prevent electrical shock to personnel. Failure to do so could result in serious injury, or death. DO NOT immerse any part of this equipment in water. -
Page 10: Blade Replacement
Hawaii’s Finest Model No. 1027HD, 1027HDX Blade Replacement WARNING This machinery contains sharp blades. Keep hands and body parts clear at all times. 037_103114 This section describes the steps to replace the shaver blade and to disassemble the impeller. ALWAYS turn the machine OFF and unplug unit from the power supply prior to disassembly or replacement. - Page 11 Hawaii’s Finest Model No. 1027HD, 1027HDX To Disassemble the Impeller 1. Turn machine OFF, and unplug the unit from the power supply. 2. Remove lid by removing the wing nut and hinge pin. 3. Remove the four plastic button screws that hold the top hopper cover, then lift and roll over.
-
Page 12: Ordering Spare Parts
Hawaii’s Finest Model No. 1027HD, 1027HDX ORDERING SPARE PARTS 1. Identify the needed part by checking it against the photos, illustrations, and/or parts list. 2. When ordering, please include part number, part name, and quantity needed. 3. Please include your model number, serial number, and date of manufacture (located on the machine nameplate) with your order. - Page 13 Hawaii’s Finest Model No. 1027HD, 1027HDX Cabinet Exterior Assembly Part Number Item Part Description Qty. 1027HD 1027HDX TOP COVER DOOR 12119W 12119W TOP COVER 12557W 12557W WING NUT 6-32 STL ST 12152 12152 ICE SHAVER DECAL 12155 12155 ICE CHUTE WELD ASSEMBLY...
- Page 14 Hawaii’s Finest Model No. 1027HD, 1027HDX Cabinet Exterior Assembly 1, 2, 3, 4, 5 13, 14, 15 Part Number Item Part Description Qty. 1027HD 1027HDX SWITCH MOUNTING BRACKET 12136 12136 DOOR SAFTEY SWITCH 12116 12116 1/2 OD X 1/2 T MAGNET...
- Page 15 Hawaii’s Finest Model No. 1027HD, 1027HDX Shaver Assembly Part Number Item Part Description Qty. 1027HD 1027HDX BLADE ADJUSTMENT KNOB 12111 12111 SET SCREW 8-32 X 1/8 S.S. 12165 12165 BLADE ADJUSTMENT SCREW ASSEMBLY 12125 12125 ICE CHUTE WELD ASSY 12683...
- Page 16 Hawaii’s Finest Model No. 1027HD, 1027HDX Cabinet Internal Assembly Part Number Item Part Description Qty. 1027HD 1027HDX STRAIN RELIEF-WATER TIGHT 12149 12149 SPST ROCKER SWITCH 12115 SPST ROCKER SWITCH 12115EX RESET SWITCH 12316 12316 MOTOR SUPPORT PLATE 12514 12514 DIRVE MOTOR...
-
Page 17: Cabinet Bottom Assembly
Hawaii’s Finest Model No. 1027HD, 1027HDX Cabinet Bottom Assembly 1, 2 Part Number Item Part Description Qty. 1027HD 1027HDX 1/4-20 X 1 HX HD C S 18-8 12185 12185 5/16 FLAT WASHER, 18-8 12184 12184 BOTTOM COVER STAINLESS 12294 12294 1/2 ID SILCON TUBING 1.3'... - Page 18 Hawaii’s Finest Model No. 1027HD, 1027HDX Wiring Diagram 1027HD gmpopcorn.com Page 18...
- Page 19 Hawaii’s Finest Model No. 1027HD, 1027HDX Wiring Diagram 1027HDX gmpopcorn.com Page 19...
- Page 20 © 2015 – The text, descriptions, graphics, layout, and other material in this publication are the exclusive property of Gold Medal Products Co. and shall not be used, copied, reproduced, or published in any fashion, including website display, without its express written consent.
