Part No 67933
Sno–Konette
Instruction Manual
Deluxe – Model #1002S, 1002-01-100
Standard – Model #1003S, 1003SX
DC Model #1009S
Cincinnati, OH 45241-4807 USA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Sno-Konette 1002S and is the answer not in the manual?

Questions and answers

Summary of Contents for Gold Medal Sno-Konette 1002S

  • Page 1 Part No 67933 Sno–Konette Instruction Manual Deluxe – Model #1002S, 1002-01-100 Standard – Model #1003S, 1003SX DC Model #1009S Cincinnati, OH 45241-4807 USA...
  • Page 2: Safety Precautions

    Sno-Konette SAFETY PRECAUTIONS DANGER Machine must be properly grounded to prevent electrical shock to personnel. Failure to do so could result in serious injury, or death. DO NOT immerse any part of this equipment in water. DO NOT use excessive water when cleaning. Keep cord and plug off the ground and away from moisture.
  • Page 3 This machine is NOT to be operated by minors. 007_010914 Note: Improvements are always being made to Gold Medal’s equipment. This information may not be the latest available for your purposes. It is critical that you call Gold Medal’s Technical Service Department at 1-800-543-0862 for any questions about your machine operations, replacement parts, or any service questions.
  • Page 4: Installation Instructions

    Read and understand the operator’s manual and all other safety instructions before using this equipment. To order copies of the operator’s manual go to gmpopcorn.com or write to Gold Medal Products Co., 10700 Medallion Drive, Cincinnati, OH 45241 USA 1-(800)-543-0862.
  • Page 5: Electrical Requirements

    4. DO NOT use a grounded to un-grounded receptacle adapter (where applicable). 5. Install the unit in a level position. CAUTION If the supply cord is damaged, it must be replaced by Gold Medal Products Co., its service agent or similarly qualified persons in order to avoid a hazard. 039_080614...
  • Page 6: Operating Instructions

    Sno-Konette Operating Instructions To Operate the Sno-Konette: Fill the hopper to within an inch from the top with ice cubes or block ice (no larger than 3 to 4 inches). The larger the pieces, the better the snow. Switch the motor on, and wait for it to reach full speed (this will take a minute or so). Press the pusher handle down against the ice in the hopper.
  • Page 7: Care And Cleaning

    Sno-Konette Care and Cleaning DANGER Machine must be properly grounded to prevent electrical shock to personnel. DO NOT immerse in water. Always unplug the equipment before cleaning or servicing. 025_020314 WARNING This machinery contains sharp blades. Keep hands and body parts clear at all times.
  • Page 8: Maintenance Instructions

    Sno-Konette MAINTENANCE INSTRUCTIONS DANGER Machine must be properly grounded to prevent electrical shock to personnel. Failure to do so could result in serious injury, or death. DO NOT immerse any part of this equipment in water. DO NOT use excessive water when cleaning. Keep cord and plug off the ground and away from moisture.
  • Page 9: Blade Replacement

    Sno-Konette Installing New Shaver Blades WARNING This machinery contains sharp blades. Keep hands and body parts clear at all times. 037_103114 The section describes the procedure to replace the shaver blades. ALWAYS turn the machine OFF and unplug unit from the power supply prior to blade inspection or replacement. Use a flashlight to examine the blades in the shaver body.
  • Page 10 Sno-Konette 13. The shaver head set screws must be on the flat side of the motor shaft. Once aligned, fasten set screws securely. 14. Adjust the motor to realign with guide mark made on the cabinet in Step 3, then refasten motor mounting bolts (if unit has a hopper support and guide, it must also be reinstalled).
  • Page 11: Ordering Spare Parts

    4. Please include your model number, serial number, and date of manufacture (located on the machine nameplate/data plate) with your order. 5. Address all parts orders to: Parts Department Gold Medal Products Co. 10700 Medallion Drive Cincinnati, Ohio 45241-4807 Or, place orders by phone or online:...
  • Page 12 Sno-Konette Switch, Toggle SPST (1002S) P/N 47201 Pusher Handle Assy. P/N 22005 Rocker Switch (1003S) P/N 42798 30 AMP Toggle Switch Momentary Switch P/N 38971 (1009S) P/N 43141 View of DC Model 1009S Plastic Sno Pan P/N 22072 Strain Relief Lamp Holder P/N 87810 P/N 49837...
  • Page 13 Sno-Konette Set Screw 5/16-18 x 3/8 (x2) Shaver Head P/N 74127 P/N 22015 2 Hole Blade Set P/N 22017 (includes blade mounting screws) Drain Pan, Counter P/N 12061 Ice Scoop P/N 39068 Snow Dipper P/N 1088 Models #1002S Series, 1003S Series, 1009S...
  • Page 14: Parts List

    Sno-Konette PARTS LIST Model # Model # Model # Model # Model # 1002S 1002-01-100 1003S 1003SX 1009S Description Part No. Part No. Part No. Part No. Part No. 47201 47201 42798 42798 Rocker Switch Switch 43141 30 AMP TOGGLE SWITCH 13140 13015 ROCKER SW.
  • Page 15 Sno-Konette ELECTRICAL SCHEMATIC – MODEL #1002S Models #1002S Series, 1003S Series, 1009S...
  • Page 16 Sno-Konette ELECTRICAL SCHEMATIC – MODEL #1003S Models #1002S Series, 1003S Series, 1009S...
  • Page 17 Sno-Konette ELECTRICAL SCHEMATIC – MODEL #1003SX Models #1002S Series, 1003S Series, 1009S...
  • Page 18 Sno-Konette ELECTRICAL SCHEMATIC – MODEL #1002-01-100 Models #1002S Series, 1003S Series, 1009S...
  • Page 19 Sno-Konette ELECTRICAL SCHEMATIC – MODEL #1009S Models #1002S Series, 1003S Series, 1009S...
  • Page 20: Warranty

    © 2015 – The text, descriptions, graphics, layout, and other material in this publication are the exclusive property of Gold Medal Products Co. and shall not be used, copied, reproduced, or published in any fashion, including website display, without its express written consent.
