Fluke Biomedical ASM-990 Operator's Manual

Asm-990 series
Hide thumbs
Table of Contents

Advertisement

Quick Links

ASM-990 Series
Advanced Survey Meter
Operators Manual
March 2005
Manual No. 1100001000 Rev. 3
©2004, 2005 Fluke Corporation, All rights reserved. Printed in U.S.A.
All product names are trademarks of their respective companies

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ASM-990 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Fluke Biomedical ASM-990

Summary of Contents for Fluke Biomedical ASM-990

  • Page 1 ASM-990 Series Advanced Survey Meter Operators Manual March 2005 Manual No. 1100001000 Rev. 3 ©2004, 2005 Fluke Corporation, All rights reserved. Printed in U.S.A. All product names are trademarks of their respective companies...
  • Page 2 Fluke Biomedical Radiation Management Services 6045 Cochran Road Cleveland, Ohio 44139 440.498.2564 www.flukebiomedical.com/rms...

  • Page 3: Table Of Contents

    Table of Contents Section 1: General Information................... 1-1 Product Specification ................... 1-1 Warning Labels.................... 1-3 Section 2 Operation....................2-1 Membrane Switch/Front Panel Overview............. 2-1 Basic Operation ................... 2-2 Operating Modes ..................2-12 Data Logging ..................... 2-13 Messages Display..................2-15 Probe Selection ..................2-15 Keypad Lock Feature.................
  • Page 4 (Blank page)

  • Page 5: General Information

    Geiger-Mueller (GM) and scintillation probes, proportional counting probes and neutron probes. The ASM-992 is identical to the ASM-990 with the addition of a second, internal GM tube and supporting circuitry. The ASM-993 contains both an internal GM tube, as well as an internal pancake probe.
  • Page 6 ANSI N42.17A, paragraph 8.7.1 and 8.7.2.) Power Requirements The ASM-990 series operates on two “D” size batteries, internally connected in a series array to create a +3 VDC power level to the unit. Recommended battery types are nickel metal hydride (NiMH) rechargeable, or alkaline.

  • Page 7: Warning Labels

    General Information Warning Labels 1.2 Warning Labels WARNING Un-insulated high voltage present CAUTION Do not touch connector while power is on ADVERTENCIA Voltaje peligroso: riesgo de chaque electrico CUIDADO No tocar conectador mientras este encendido AVERTISSEME Non isole’ haute tension CAUTION Ne pas toucher cable coaxial quand en marche WARNUNG...
  • Page 8 ASM-990 Series Operators Manual NOTE If this device is used in a manner not specified by Fluke Biomedical, the protection by the device may be impaired. CAUTION There are no user serviceable parts for this unit. Should unit require service, please contact Fluke...

  • Page 9: Operation

    Operation 2.1 Membrane Switch/Front Panel Overview Figure 2-1 illustrates the membrane keypad of the ASM-990 series. The function of each key is summarized below: The “ON/OFF” key is used to apply power to, or remove power from, the unit. If the unit is off when this key is pressed, then the unit will turn on.

  • Page 10: Basic Operation

    ASM-990 Series Operators Manual Figure 2-1. Membrane Keypad 2.2 Basic Operation When power is initially applied, by pressing the “ON/OFF” switch, a screen displaying “Victoreen Advanced Survey Meter” will appear. It will remain for approximately five seconds. After the five-second interval is over, the unit will display information regarding the previously selected probe (see Figure 2-2).
  • Page 11 Operation Basic Operation PROBE INFO PROBE SELECTION MODEL #: 489-50 PROBE #1 SERIAL #: 002132 PROBE #2 CAL DATE: 09/06/02 PROBE #3 CAL CYCLE: 12 mos. “ CAL DUE: 09/06/03 “ IS PROBE CORRECT? PROBE #N NOT LISTED Figure 2-2. Probe Information Figure 2-3.

  • Page 12: Section 3: Calibration

    ASM-990 Series Operators Manual MAIN MENU SWITCH TO INTG MODES SETUP DATA REVIEW IrDA COMMUNICATION Figure 2-5. Main Menu Display Modes Sub-Menu To select a different mode, use the “UP” arrow key to highlight “MODES;” then press the “SEL” key. The screen will now appear as in Figure 2-6.
  • Page 13 Operation Basic Operation Figure 2-7. Rate Unit Sub-Menu Integrate Sub-Menu If “INTEGRATE” is selected from the “MODES SUB-MENU,” the operating mode is then set to “INTEGRATE” and “INTG UNIT SUB-MENU” will appear on the screen (see Figure 2-8). The integrate unit selections are identical to those for the rate unit setting.
  • Page 14 ASM-990 Series Operators Manual Figure 2-10. Scaler Mode Sub-Menu SCALER UNIT SUB-MENU COUNTS Figure 2-11. Scaler Unit Sub-Menu METHOD SUB-MENU COUNT UP COUNT DOWN Figure 2-12. Scaler Value Setup SCALER VALUE SETUP COUNTS ##### Figure 2-13. Scaler Method Sub-Menu Peak Hold When “PEAK HOLD”...
  • Page 15 Operation Basic Operation To start the timer, press the “START/STOP/RST/SAVE” key. After the preset time interval has expired, the highest (peak) reading measured (during that time interval) will be displayed on the screen. It will remain until the unit is taken out of the “PEAK HOLD” mode, or until the process is repeated. PEAK HOLD INTERVAL MODIFY SETTINGS Figure 2-14.
  • Page 16 ASM-990 Series Operators Manual a “TONE,” highlight “SWITCH TO TONE” then press “SEL.” Following the same procedure will then switch the audio output back to “TICK.” LCD CONTRAST ADJ Figure 2-17. LCD Contrast Setup The “##” under the “POWER DOWN INTERVAL” menu is equal to a number from 0 to 99 hours. Entering “0”...
  • Page 17 Operation Basic Operation If the “SURVEY” mode is to be selected the user must download the sequence information from a PC, including the location of each successive measurement point, before starting to log data. Failure to do this will cause the message “NO SURVEY DEFINED” to be displayed. If the user then presses the “SEL” key, the “SURVEY SUB-MENU”...
  • Page 18 ASM-990 Series Operators Manual SURVEY SUB-MENU (sequence name #1) (sequence name #2) (sequence name #3) Figure 2-20. Survey Sub-Menu SHOW LOCATION LIST? Figure 2-21. Location List Prompt LOG DATA LOCATIONS (location #1) (location #2) (location #3) “ “ (location #n) Figure 2-22.
  • Page 19 Operation Basic Operation Date/Time Adjustment When the “Date/Time” adjustment mode is entered, the display will appear as in Figure 2-24. The “MM” will be highlighted first. If the user takes no action in five seconds, the “DD” will then be highlighted. Similarly, the “YY”, “HH”...

  • Page 20: Operating Modes

    “over-range” value, the alarm level will automatically default to the “over-range” value instead. Also, when the user sets an alarm value in units (other than “cpm”) the ASM-990, ASM-992, and ASM-993 automatically convert those units to the approximate “cpm” value. The conversion accuracy, in this case, is +/- 1% of the set point.

  • Page 21: Data Logging

    Operation Data Logging 2.4 Data Logging Logging Data – Non Survey Mode The “START/STOP/RST/SAVE” key is used for manually logging data and for reading a barcode. When this key is pressed, the instrument then displays the message “SPACE AVAILABLE XX” for one second, while the current reading is being logged.
  • Page 22 ASM-990 Series Operators Manual DATA REVIEW SUB-MENU SESSION SUB-MENU MANUAL -> 12/16/02 4:09 PM (survey sequence name #1) -> 12/16/02 5:22 PM (survey sequence name #2) -> 12/17/02 9:02 AM (survey sequence name #3) “ “ (survey sequence name #10)

  • Page 23: Messages Display

    Operation Message Display 2.5 Messages Display Messages such as “LOW BATTERY,” “OVERRANGE,” and the location of the next survey (if enabled) are one line in length and will be displayed near the lower edge of the LCD. The message “HV FAULTS” is one line in length and will be displayed near the lower-center portion of the LCD.

  • Page 24: Keypad Lock Feature

    ASM-990 Series Operators Manual 2.7 Keypad Lock Feature In order to prevent inadvertent key actuation, the keyboard may be locked. This is accomplished by first pressing the “ON/OFF” key to turn the unit on; then simultaneously pressing the “AUDIO” and “LIGHT”...

  • Page 25: Calibration

    Calibration Calibration Section 3 Calibration 3.1 Calibration Probe calibration parameters (probe profiles) are NOT operator accessible through the front panel. Rather, they will be downloaded, through the usage of PC based calibration software, via the IrDA port. Parameters for each calibrated probe are then stored/saved in the unit’s non-volatile memory (EEPROM). The user may then select from one of the previously stored probe data calibration parameters.
  • Page 26 ASM-990 Series Operators Manual (Blank page)

  • Page 27: Maintenance

    4.3 Storage Storage of Fluke Biomedical instruments must comply with Level B storage requirements as outlined in ANSI N45.2.2 (1972), Section 6.1.2 (.2). The storage area shall comply with ANSI N45.2.2 (1972), Section 6.2 Storage Area, paragraphs 6.2.1 through 6.2.5.

  • Page 28: Battery Replacement

    ASM-990 Series Operators Manual 4.4 Battery Replacement The low battery indicator (icon) will appear on the display approximately two (2) hours prior to the instrument becoming inoperable. To ensure that the instrument operates to specification, it is recommended that the batteries be changed within one (1) hour after the low battery icon appears.

  • Page 29: Recalibration And Service Information

    Maintenance Replaceable Parts Information 4.5 Replaceable Parts Information Fluke Biomedical maintains a complete inventory of all normal replaceable parts. To place an order, or to obtain information concerning replaceable parts, contact the Fluke Biomedical at 440.498.2564, or by Fax: 440.542.3682.
  • Page 30 ASM-990 Series Operators Manual (Blank page)

  • Page 31: Appendix A: Asm-992, Asm-993 Directional Dependence

    Appendix Asm-992, ASM-993 Directional Dependence Appendix A ASM-992, ASM-993 Directional Dependence A.1 ASM-992, ASM-993 Polar Response for Internal 1R Energy Compensated GM Tube...
  • Page 32 ASM-990 Series Operators Manual (Blank page)

  • Page 33: Appendix B: Asm-992, Asm-993 Energy Dependence

    Appendix Asm-992, ASM-993 Energy Dependence Appendix B ASM-992, ASM-993 Energy Dependence B-1. ASM-992, ASM-993 Energy Dependence Typical Energy Dependence Internal 1R Energy Compensated Detector 1.4000 1.2000 1.0000 0.8000 0.6000 0.4000 0.2000 0.0000 1000 10000 Energy (keV)

  • Page 34: Asm-993 Energy Dependence, Internal Pancake Gm Detector

    ASM-990 Series Operators Manual B-2. ASM-993 Energy Dependence, Internal Pancake GM Detector Typical Energy Dependence Model 993 Internal Pancake GM Detector Energy (keV) NOTE Protective cover open...

  • Page 35: Appendix C: Asm-992, Asm-993 Internal Energy Compensated 1R Gm Tube

    Appendix Asm-992, ASM-993 Internal Energy Compensated 1R GM Tube Appendix C ASM-992, ASM-993 Internal Energy Compensated 1R GM Tube C-1. Location Diagram - Internal Energy Compensated 1R GM Tube...
  • Page 36 Fluke Biomedical Radiation Management Services 6045 Cochran Road Cleveland, Ohio 44139 440.498.2564 www.flukebiomedical.com/rms...

This manual is also suitable for:

Asm-992Asm-993
