Lock Relay Connection
Device Sharing Power with the Lock
485B RJ45-6
485A RJ45-3
GND RJ45-2
TXD RJ45-1
RXD
GND
WD1
WD0
GND
+12V
DESCRIPTION
AL+
AL-
NC1
COM1
NO1
BUT
GND
SEN
BELL+
BELL-
GND
AUX
ProCapture-T & ProRF-T and ZKBioSecurity 3.0 Quick Start Guide
1
12
WIRE
Red
Black
Gray
Black
White
Blue
Red
Yellow
Orange
Green
Purple
Brown
Do not use
COM1
Sensor
NC1
GND
GND
Normally Closed Lock
1
+12V
7
+
-
FR107
Diode
