Avaya 4610 Phone User Guide
1 Voice Message Light: When lit, indicates
you have a message waiting on your voice
messaging system.

3 Line/Feature buttons

Twelve Line/Feature buttons provide both call
appearances (lines for incoming and outgoing
calls) and application-specific functionality.
Each line may display any of the icons shown
immediately below, depending on the current
state of the phone.

5 Phone/Exit

Displays the Phone application main screen
or, if applicable, exits the current call
server-based feature and normalizes the
display.

7 Page Right/Left

Shifts from one page to another in the same
2 Display Information displayed varies
according to the application/function currently
active. When the phone is idle, the top area
displays the current date and time; when
someone is calling you, the name/phone
number of that person displays there. The
display has eight lines (six lines of which are
devoted to the current application, one line
showing softkey labels for the current
application, and one line for Help and other
procedural messages) and four grayscale
colors used to indicate activity.

4 Softkeys

Used to navigate to, or initiate
application-specific actions, such as Call a
number, Cancel the current activity, Save
entered data, and Store a speed dial label.

6 Options

Displays the Options main screen, from which
display and application settings can be
updated.
8 Speaker LED Indicator
Lights steadily when the Speakerphone is
