Gamry Interface 5000 Operator's Manual

Potentiostat/galvanostat/zra
Hide thumbs Also See for Interface 5000:
Table of Contents

Advertisement

Quick Links

Download this manual
Interface 5000
Potentiostat/Galvanostat/ZRA
Operator's Manual
Copyright  2015–2018 Gamry Instruments, Inc.
Revision 6.7
January 18, 2018
Gamry P/N 988-00034

Advertisement

Table of Contents
loading

Related Manuals for Gamry Interface 5000

Summary of Contents for Gamry Interface 5000

  • Page 1 Interface 5000 Potentiostat/Galvanostat/ZRA Operator’s Manual Copyright  2015–2018 Gamry Instruments, Inc. Revision 6.7 January 18, 2018 Gamry P/N 988-00034...
  • Page 3 If you have problems in installation or use of a system containing an Interface 5000, please try to call from a phone next to your computer, where you can type and read the screen while talking to us.

  • Page 4: Limited Warranty

    Limited Warranty Gamry Instruments, Inc. warrants to the original user of this product that it shall be free of defects resulting from faulty manufacture of the product or its components for a period of two years from the original shipment date of your purchase.
  • Page 5 Interface 5000, Reference 600, ECM8, Gamry Framework, and Gamry are trademarks of Gamry Instruments, Inc. No part of this document may be copied or reproduced in any form without the prior written consent of Gamry Instruments, Inc. Swagelok is a registered trademark of Swagelok Company. Windows, Vista, and Excel are registered trademarks...

  • Page 6: Table Of Contents

    Firmware Update ......................26 The Interface 5000 Customization Label ................27 Introduction to the Interface 5000 Customization Label ........27 Label Sheet Provided with Each Interface 5000 ............ 28 How to Change the Label on an Interface Family Potentiostat ....... 28 Chapter 4: Calibration ........................
  • Page 7 Error Messages and Limitations ..................71 Appendix E: CE Certificate ......................73 Declaration of Conformity ....................73 Appendix F: Heat in Interface 5000 Multichannel Systems ............. 77 Introduction to Device Power-dissipation ................. 77 Potentiostat/Galvanostat Power Model ................77 Discharging a Battery ......................78 Single Interface 5000 ......................
  • Page 8 Interface Power Hub Systems .................... 79 Appendix G: Optional Interface 5000 Monitor Board ..............81 Introduction ........................81 Connectors ........................81 EXT SIG IN ......................81 AUX IN ........................ 81 E Monitor ......................82 I Monitor ......................82 RTD........................82 Input (unlabeled) ....................

  • Page 9: Chapter 1: Safety Considerations

    AC mains voltage to 48 V DC, which is used to power the Interface 5000. If your Interface 5000 is not installed in an Interface Power Hub (IPH), use the AC adapter (power brick) supplied with your Interface 5000 to supply DC power to the instrument. If your Interface 5000 is installed in an IPH, the IPH provides its power.

  • Page 10: Grounding In The Interface 5000

    The Interface 5000 is normally provided with an AC line cord suitable for your location. This AC line cord connects the AC mains to the AC power adapter. If your Interface 5000 has been provided without an AC line cord, or a cord that is not compatible with your local AC mains socket, obtain a line cord certified for use in your country.

  • Page 11: Operation With Earth-Grounded Cells And Auxiliary Apparatus

    ±28 V. In the worst case this can cause catastrophic failure of the system. Do not connect an Interface 5000 to a cell in a battery or fuel cell stack when the cell voltage is far from earth ground.

  • Page 12: Defects And Abnormal Stresses

    It has been dropped or subjected to severe transport stress, • It has been subjected to environmental stress (corrosive atmosphere, fire, etc.). Do not use your Interface 5000 or any other apparatus if you think it could be hazardous. Have it checked by qualified service personnel. Environmental Limits Note that there are environmental limit conditions on the storage, shipping and operation of this equipment.

  • Page 13: Service

    Safety Considerations fluid to enter the Interface 5000 enclosure. Do not immerse the Interface 5000 in any type of cleaning fluid (including water). Do not use any abrasive cleaners. Service Your Interface 5000 Potentiostat/Galvanostat/ZRA has no user-serviceable parts inside. Refer all service to a qualified service technician.

  • Page 14: Ce Compliance

    Gamry Instruments, Inc. has designed and tested the Interface 5000 to comply with these standards. The relevant CE regulations include EN 61010 and EN 61326. RoHS Compliance The Interface 5000 is built using lead-free components and lead-free solder. It is in compliance with the European RoHS initiative.

  • Page 15: Chapter 2: Introduction

    • Both analog and digital filtering. The Interface 5000 has a special feature to improve its ability to discharge batteries. See Appendix E for details. The Interface 5000 compliance voltage is normally ±6.5 V. The Framework software, when discharging a battery, lowers one side of the instrument’s compliance to 2.3 V.

  • Page 16: Software And Applications

    In this type of system, each Interface 5000 is powered by an individual AC Adapter, which, in turn, can be powered by a multiple output AC power strip. The multiple USB connections for the system can be obtained from an inexpensive commercial USB hub.

  • Page 17: Front-Panel Customization

    The Interface 5000 supports a custom labeling scheme for identifying potentiostats in a multiple-potentiostat system. A clear window in the plastic overlay on the Interface 5000’s front panel lets you create your own identification of each potentiostat in a system.
  • Page 18 Introduction...

  • Page 19: Chapter 3: Installation

    Front View of an Interface 5000 Initial Visual Inspection After you remove your Interface 5000 from its shipping carton, check it for any signs of shipping damage. If you observe any damage, please notify Gamry Instruments, Inc. and the shipping carrier immediately. Save the shipping container for possible inspection by the carrier.

  • Page 20: Computer Requirements

    An Internet download of Gamry’s software will download a self-extracting .EXE file. Running this file will extract the software and begin the same installation process as you get with a physical medium. If you have inserted the Gamry DVD or flash drive into your computer and the Gamry Setup program does not start automatically:...

  • Page 21: Reboot Your Computer After Software Installation

    DC power input jack on the rear of the Interface 5000. The external power supply provided with the Interface 5000 is rated for operation from 100 to 240 V AC, at frequencies from 47 to 63 Hz. It should therefore be useable worldwide.

  • Page 22: Power-Up Test

    This process could take as long as 15 seconds. The Interface 5000 fan runs at low speed after the PWR light stops flashing. If you do not see four or five blinks and then a steady blue color, see Appendix D for a table of blink codes.

  • Page 23: Usb Cables

    Instruments representative as soon as possible. USB Cables The Interface 5000 connects to the computer using a filtered High Speed USB A/B cable. A suitable cable was shipped with your Interface 5000. The replacement cable is Gamry Part Number 985-00131.

  • Page 24: Cell Cable Installation

    Cell Cable Installation The Cell Cables connect to two 15-pin D-type connectors located on the front of the Interface 5000 (see Figure 3-1). There are two cables: one that carries the cell current, called the Current Carrying Cable which mates with the Current Connector, and one that senses the cell voltage, called the Sense Cable, which mates with the Sense Connector.

  • Page 25: Running The Framework

    Framework Device Status Bar By default, the Gamry Framework shows a Device Status Bar under its main menu (see Figure 3-3). If you do not see the Device Status Bar when you run the Gamry Framework, it has been disabled in the Framework Options menu.

  • Page 26: Types Of Interface 5000 Instruments

    There are three separate firmware images that can be updated in the field on your Interface 5000. The first is the Instrument Firmware. This is the program that handles most of the functions of the Interface 5000. The second is the Communications Firmware.

  • Page 27: The Interface 5000 Customization Label

    Interrupting a firmware update can cause a catastrophic failure of your system. Do not turn off the Interface 5000, do not unplug the USB cable, and do not stop the operation of the host computer when the USB LED is a continuous red color.

  • Page 28: Label Sheet Provided With Each Interface 5000

    Pstat 1 through Pstat 16 on a red background You can cut any of these labels from the sheet and insert it as the Interface 5000 Customization Label. The white labels are provided to allow you to hand-write a label.
  • Page 29 Installation Your Interface 5000 family instrument should now look like Figure 3-6 (the front bezel is removed). Notice the blue tab on the left side on the instrument. This is part of the old label; it is blue on the instrument in the photo.
  • Page 30 Installation...

  • Page 31: Chapter 4: Calibration

    Calibration can be initiated through Framework™ software, or directly through Gamry Instrument Manager (GIM). Gamry recommends calibrating the instrument at least once per year, or when the quality of your data is in question. To initiate calibration, take the following steps: Click the Calibrate in Framework button, located in the Calibration area of GIM.

  • Page 32: Cable Calibration

    • The system is being run in an environment that is very different from the previous operating environment. For example, if the Interface 5000 was calibrated at 15°C and you are now operating it at 30°C, you should recalibrate. Figure 4-1...

  • Page 33: Procedure To Calibrate The Cable

    Calibration Cable calibration is only required infrequently, if you feel that the cable capacitance is a problem for your experiments, especially if you see excessive phase glitches on high-impedance samples. Procedure to calibrate the cable 1) Connect the Chassis Ground on the back of your potentiostat to a known, good earth ground. 2) Connect the cell cable to the correct color-coded receptacles on the 2 kΩ...
  • Page 34 Calibration 4) Open Gamry Framework™ software. Select Experiment > Named Script... The Select a script to run window appears. 5) From the list of scripts, choose calcable.exp, then click the Open button. The Cable Capacitance Calibration window appears. 6) In the Cable Tag field, enter a unique name for the cable you are calibrating.
  • Page 35 Calibration 7) Make sure that all of the tips are true, then click the OK button. The Cell Required window appears. 8) Make sure that the correct Calibration Cell is attached, then click the OK button. (The screenshot shown here is a general representation, not the actual resistor’s value.) The calibration runs.
  • Page 36 Calibration...

  • Page 37: Chapter 5: Cell Connections

    Every Interface 5000 is shipped with a pair of standard shielded cell cables. The Gamry part number for a set of these two cables is cell cables is 985-00157. They are both 60 cm complex cables, with D-connectors on one end, and color-coded banana plugs and pin sockets on the other end.

  • Page 38: Normal Cell Connections

    Save Both ½ Cell modes, leave this lead open or connect it to the floating ground. The black pin jack is connected to the Interface 5000 to Floating Ground. This is the circuitry ground for the analog circuits in the Interface 5000. In most cases, leave this terminal disconnected at the cell end, but take care that its metal contact does not touch any of the other cell connections.

  • Page 39: Three-Electrode Battery Connections

    5000 chassis to earth ground. Autoclaves, stress apparatus, and field measurements may involve earth- grounded electrodes. A binding post on the rear panel of the Interface 5000 is provided for this purpose. A water pipe can be a suitable earth ground.

  • Page 40: Zra Mode Cell Connections

    ZRA Mode Cell Connections The Interface 5000 can function as a precision Zero Resistance Ammeter (ZRA). In this mode it maintains two metal samples at the same potential and measures the current flow between the samples. It can also measure the potential of the samples versus a reference electrode.

  • Page 41: Membrane Cell Connections

    A/D noise and offset will create a small potential signal with a value very close to zero. Membrane Cell Connections The Interface 5000 can be used with membrane cells. In this type of cell, a membrane separates two electrolyte solutions. Two reference electrodes are used: one in each electrolyte. Each electrolyte also contains a counter electrode.
  • Page 42 Both the counter electrode lead and the working electrode lead have fuses, rated to carry 6.3 A. Always turn off the Interface 5000 and disconnect both ends of the Counter/Working cable before checking or replacing the fuses in the cable.

  • Page 43: Testing For Open Fuses

    A Gamry Framework test checks for blown fuses without having you remove the fuses. A simple Potentiostatic test is run on the Calibration Cell on the Interface 5000 Calibration Cell. Run the test using the SET A VOLTAGE.EXP script in the Framework’s Utilities package. Utility Package scripts do not require an Authorization Code, so every Framework installation can run this test.
  • Page 44 If the fuse test indicates an open fuse, and the fuses both check out a good with an ohmmeter, some other problem has occurred in the cables or the instrument. Contact Technical Support at Gamry Instruments as soon as possible.

  • Page 45: Chapter 6: Panel Indicators And Connectors

    Power Button The Power button is on the far right side of the Interface 5000 Front Panel. It is a push-push switch: push once to turn the instrument on and push again to turn the instrument off. The switch’s button latches: the button is closer to the front panel when the instrument is on than when it is off.

  • Page 46: Cell Connectors

    Panel Indicators and Connectors When the Interface 5000 is first turned on, the PWR LED will glow steadily for a second or two, blink three times, and then enter its normal continuous blue output. When the PWR LED is off, these are possible causes: •...

  • Page 47: Monitor Connector

    The USB LED indicates a continuous red in one special condition: when a firmware update occurs. Interrupting a firmware update can cause a catastrophic failure of your system. Do not turn off the Interface 5000, do not unplug the USB cable, and do not stop the operation of the host computer when the USB LED is a continuous red color.

  • Page 48: Cell On Led

    Overload LED The Overload LED is just below the Cell On LED. The Overload LED is normally unlit. When it glows red, some circuit in the Interface 5000 has exceeded its normal operating limit. Conditions that generate Overloads include: •...

  • Page 49: Personalization Label Area

    Personalization Label Area The left side of the Interface 5000 front panel has a transparent area in its plastic overlay. A paper label behind this area allows a custom appearance. This is especially important when the instrument is in a multiple-...

  • Page 50: Rear Panel

    Rear Panel Power In Jack The Power In jack is a 4-pin power DIN connector. The Interface 5000 derives all its power from +48 V DC input through the Power In jack. The input current is less than 1.8 A.

  • Page 51: Usb Port

    USB Port The USB port on the rear panel of the Interface 5000 is a Type B connector as defined in Revision 1.1 and 2.0 of the USB Specification. Use a standard, shielded, Type A/B cable to connect this port to a computer’s USB port or a USB hub (preferably an externally powered hub).

  • Page 52: User I/O Connector

    Panel Indicators and Connectors User I/O Connector The User I/O connector contains digital signals used to connect external devices to the Interface 5000. All of its signals are referenced to earth ground so their connection does not compromise the Interface 5000 ground isolation.

  • Page 53: Chapter 7: Instrument Circuitry

    The following figures are partly schematic diagrams and partly block diagrams. They are intended to show the basic principles of the Interface 5000 without the confusion of the full circuitry details. The complexity of the Interface 5000 can be quite daunting: the Interface 5000 circuit boards contain more than 2000 components connected by almost 5000 circuit nets.
  • Page 54 Instrument Circuitry Figure 6-4 Interface 5000 Potentiostat Board in Potentiostat Mode Notes for Figure 6-4 • Only Potentiostat Mode connections are shown in this figure. In this mode the voltage difference between the Reference and Working Sense leads (called Esig) is fed back into the control amplifier.
  • Page 55 The high-pass filter provides AC-coupling to prevent drift in the DDS’s offset entering the applied signal. In practice, Gamry EIS software uses the DDS to apply sine waves with frequencies from 100 Hz to 1 MHz. It uses the Scan DAC to generate sine signals at frequencies below 100 Hz.
  • Page 56 Instrument Circuitry Figure 6-6 One A/D Signal Chain in the Interface 5000 Notes for Figure 6-6: • This diagram shows one of three identical ADC channels. One channel is dedicated to measurement of the potentiostat’s current signal, another is used to measure the voltage signal, and the third is switched between several functions.
  • Page 57 The Interface 5000 has local non-volatile data storage to save calibration data and board-revision information. Interface 5000 calibration data is stored in the instrument, not in a data file. When an Interface 5000 is moved from one computer to another, its calibration remains valid.
  • Page 58 Interface 5000 or a Gamry-supplied alternative. Other power sources may void the performance and/or safety characteristics of the Interface 5000. Power input voltages less than 40 V or greater than 52 V can damage the Interface 5000’s power supply.

  • Page 59: Appendix A: Interface 5000 Specifications

    Appendix A: Interface 5000 Specifications All specifications are at an ambient temperature of 22C, with the Interface 5000 powered using the external power supply shipped with the unit, a standard shielded 60 cm cell cable, and the cell enclosed in a Faraday shield.
  • Page 60 Appendix A: Interface 5000 Specifications Current to Voltage Converter Maximum Full-scale Range ±5 Note 13 Minimum Full-scale Range ±50 µA Note 13 ±500 (after 100× gain) Voltage across Rm ±100 mV at Note 14 full scale Output Voltage (at Monitor and ADC in) ±3.0...

  • Page 61: Temperature Measurement

    Appendix A: Interface 5000 Specifications Galvanostatic Mode Maximum Full Scale Current ±5 Minimum Full Scale Current ±50 µA Accuracy Dominated by current-to-voltage converter accuracy shown above Sig Gen Voltage for Full Scale Current ±3.0 V Temperature Measurement Measurement range –50 to 600 °C...
  • Page 62 Cell resistor 90 Ω connected between the counter and working electrode leads, in potentiostatic mode. 5. The A/D and signal-processing chain in the Interface 5000 allows measurement of voltage signals as large as ±6.5536 V. The voltage on the Work Sense lead can be as high as ±0.51 V when measuring 5A using a 60 cm cell cable.
  • Page 63 500 µA scale. 1 µV of voltage noise creates a current of 1 µA. The filters in the ADC Chain for the I Signal are used to limit the bandwidths as shown in the specifications. Signal averaging via Gamry DSP mode further reduces the measured noise.
  • Page 64 Appendix A: Interface 5000 Specifications...

  • Page 65: Appendix B: Interface 5000 Cell Connectors

    Multiple pins assigned to the same signal are connected together on the Interface 5000’s Potentiostat board. If you must connect this using a special cell cable, you need a wire connected to any one of the D-connector pins.
  • Page 66 Appendix B: Interface 5000 Cell Connectors Table B-2 Sense Connector Pin(s) Signal Name CBL_ID2 One of four cable ID bits. Used to identify the type of cell cable attached to the unit. Pull to a logic High through a resistor. Ground to set the bit low.

  • Page 67: Appendix C: I/O Connectors

    The details of these connectors are described here. User I/O Connector This connector contains a number of signals, used to interface the Interface 5000 to external apparatus. It is the miniature 15-pin female D-shaped connector on the rear panel of the Interface 5000.

  • Page 68: Monitor Connector

    Monitor Connector The Monitor Connector is located on the Interface 5000 Front Panel. It is a 9-pin round mini-DIN connector. One possible mating connector is from CUI Inc., part number MD-90. The pin-out signals of the Monitor...

  • Page 69: I Monitor Signal

    The positive input of the differential Aux ADC Input I Monitor Signal The I Monitor signal represents the output of the Interface 5000 current measurement circuit. It can be treated as a two-wire differential signal with the negative side connected to the Interface 5000 Signal Ground. With the exception of the filtering described below, it is the raw signal with no offset or gain applied.

  • Page 70: External Signal In

    The input impedance of this signal is 2 kΩ. Temperature Monitor Signal The Interface 5000 offers temperature testing in the range of –50 to 600°C. A 1000 Ω (at 0°C) platinum RTD (resistance temperature detector) according to European standard (DIN/IEC 60751 or simply IEC751) is used for the temperature measurement.

  • Page 71: Appendix D: Power Led Blink Codes And Error Messages

    If you receive one of the above codes, please call Gamry Instruments Service Department for assistance. Error Messages and Limitations The Interface 5000 has a subtype, Interface 5000P, which may generate error messages under certain run-time conditions. Error Message This instrument is not authorized for Freq= The Interface 5000P is able to perform EIS at frequencies 20 kHz or lower.
  • Page 72 Appendix D: Power LED Blink Codes and Error Messages...

  • Page 73: Appendix E: Ce Certificate

    Declaration of Conformity According to ISO/IEC Guide 22 and CEN/CENELEC EN 45014 Manufacturer's Name and Location: This declaration is for the Gamry Instruments product: Interface 5000 Potentiostat/Galvanostat/ZRA. The declaration is based upon compliance with the following directives: EMC Directive 2004/108/EC...
  • Page 74 Appendix E: CE Certificate--Declaration of Conformity Low Voltage Certificate of Conformance...
  • Page 75 Appendix E: CE Certificate--Declaration of Conformity RFI Certificate of Conformance...
  • Page 76 Appendix E: CE Certificate--Declaration of Conformity...

  • Page 77: Appendix F: Heat In Interface 5000 Multichannel Systems

    Appendix F: Heat in Interface 5000 Multichannel Systems--Introduction to Device Power-dissipation Appendix F: Heat in Interface 5000 Multichannel Systems Introduction to Device Power-dissipation All electronic devices require power to operate. In most cases, this power generates heat within the device. The simplest model for device power assumes the device can be modeled as a simple resistor across the power supply inputs.

  • Page 78: Discharging A Battery

    You can only recover from this state by turning off the power on the Interface 5000, waiting for the device to cool, and turning the power back on.

  • Page 79: Single Interface 5000

    Single Interface 5000 Gamry tested a single Interface 5000 operating at its most extreme working condition: discharge of a 6.5 V cell at 5 A current. The unit was run in its normal horizontal position, with 5 A cell current, and a 6.5 V cell voltage.
  • Page 80 Appendix F: Heat in Interface 5000 Multichannel Systems--Interface Power Hub Systems...

  • Page 81: Appendix G: Optional Interface 5000 Monitor Board

    The AUX IN BNC connector allows you to measure a voltage from outside the Interface 5000 using the Interface 5000’s internal A/D. The scaling is 3 V in equals 30 000 A/D counts. This is a resolution of 100 µV per bit.

  • Page 82: E Monitor

    BNC. Its output impedance is approximately 200 Ω in parallel with 220 pF. The RTD jack is used to connect an RTD to the Interface 5000. The Interface 5000 continually samples the RTD input during experiments when you select a stop-at test using a temperature variable.

  • Page 83: Index

    --Connectors Index AC adapter ..........9, 16 Experiment drop-down menu ......31 AC line cord ........... 10 External Signal ..........70 ADC channels ..........56 fan speed ............11 air-cooling ............11 Faraday shield ..........39 alligator clip ............ 39 filters ..............
  • Page 84 --Connectors radio frequency..........13 support ............3 red cell lead ........... 38 Sync port ........... 16, 52, 67 reference electrode ........38, 66 telephone assistance ........3 RF interference ..........13 temperature ........... 11 RoHS Compliance .......... 14 Universal Dummy Cell ....... 39, 41, 43 safety ...............
  • Page 86 734 Louis Drive Warminster PA 18974 Tel: 215 682 9330 Fax: 215 682 9331 www.gamry.com info@gamry.com...
