Summary of Contents for Saramonic SR-WM4C

  • Page 1 SR-WM4C System VHF Wireless Microphone System...
  • Page 2: Specifications

    Product Introduction General Introductions The Saramonic SR-WM4C system is a compact and lightweight VHF wireless microphone system. Providing a perfect audio solution for recording free from the limit of distance. It is very helpful in film making, broadcast interview and business presentations.
  • Page 3 LR6/AA size alkaline battery (not included) Battery life 5 hours SR-WM4C: L102*W62*H44.7 mm Dimensions SR-HM4C: L100.5*W43*H35mm SR-XLR4C: L105*W42*H35mm SR-WM4C: 80g (2.8 oz) without battery Weight SR-HM4C: 137g (4.8 oz) without battery SR-XLR4C: 139g (4.9 oz) without battery Receiver Operating Frequencies 203-216MHz...
  • Page 4 Current Consumption 150 mA Battery Life 5 hours Dimensions 102 x 62.0 x 44.7 mm Antenna Length 178mm Weight 80 g (2.8 oz) without battery Product Structure Body-pack Transmitter Receiver...
  • Page 5 1. Antenna 8. Volume Control Wheel 2. Power Indicator 9. Power Indicator 10. Audio Output Jack 3. Microphone Input Jack 4. Power Switch 11. Power Switch 5. Belt Clip 12. Channel Selector Switch 6. Channel Selector Switch 13. Antenna 7. Headphone Jack 14.
  • Page 6 Hand-held Transmitter SR-HM4C Battery indicator Solid Green: Sufficient battery level. Solid Red: Low battery Power / Mute button ON, MUTE, OFF Antenna...
  • Page 7 Battery compartment Operates on two AA batteries (not included). You could use alkaline, lithium or nickel metal hydride batteries. Switchable 4 channels (A, B, C, D) XLR Plug-on Transmitter SR-XLR4C XLR audio input jack Connects to an XLR microphone or audio devices with line output.
  • Page 8 MUTE indicator Blinking Green: Audio is muted (i.e., disabled). Channel indicator (A, B, C, D) Power / Mute button Turns the power or mute function to on or off. Function Operation Power ON Press button for one second or longer Power OFF Press button until it turns off Mute ON...
  • Page 9: Install Battery

    Insert the battery according to the indicator as shown. Slide the drawer closed until it clicks into place. NOTE: If the SR-WM4C will not be used for a long time, please remove the batteries to prevent product damage due to battery leakage.
  • Page 10 4. Transmitter and receiver pairing. Both transmitter and receiver must be set to same channel (A, B, C, D). If the selected channel is noisy, please switch both the transmitter and receiver to other channels until you could get a very clear sound.
  • Page 11: Packing List

    Packing List SR-WM4C One SR-WM4C transmitter One SR-WM4C receiver One 1/8”(3.5 mm) signal transmission cable Two antennas One omnidirectional lavalier microphone One pop shield Two belt clips One cold shoe mount adapter User manual Warranty Card SR-HM4C One handheld transmitter...
  • Page 12 The Saramonic logo is trademark which is registered and owned by Saramonic International. COPYRIGHT 2011-2021 SARAMONIC INTERNATIONAL ( A brand of DSQN ) Email: info@saramonic.com...
