- Page 1 UHF Wireless Microphone System UwMic10 User Manual...
- Page 2 Statement This user manual is available for these packages: • UwMic10 RX10+TX10, a portable receiver and a body-pack transmitter. • UwMic10 RX10+TX10+TX10, a portable receiver and two body-pack transmitters. • UwMic10 HU10, a hand-held microphone transmitter. • UwMic10 TX10, a body-pack transmitter.
-
Page 3: Table Of Contents
CONTENTS General Introduction ............2 Portable Receiver UwMic10-RX10 ........2 Introduction ............... 2 Product Structure .............. 2 Attaching Accessories ............4 LCD Display Operation Guide ..........5 Body-pack Transmitter UwMic10-TX10 ......8 Introduction ............... 8 Product Structure .............. 8 Attaching Accessories ............. 10 LCD Display Operation Guide .......... -
Page 4: General Introduction
General Introduction The Saramonic UwMic10 UHF wireless microphone system is intended for portable wireless operation and can be used in several environments for applications such as DSLR video, field recording, broadcast TV, electronic news gathering (ENG), on-the-spot interviews, and more. - Page 5 ① Antennas ② Power button Press to turn on or off the RX10. ③ SET button Long press the SET button to enter the displayed menu. Then, short press the SET button to confirm your option or long press again to exit without saving. ④ ...
-
Page 6: Attaching Accessories
Attaching Accessories Connect the supplied cable to the output jack. ① P lug the supplied cable into the OUTPUT jack. ② ② For a secure connection, turn to lock the connector. ① Attach a belt clip. Please Refer to “Attaching Accessories" (page 10). -
Page 7: Lcd Display Operation Guide
LCD Display Operation Guide ① ② ① ② ③ ④ ⑤ ⑥ Home screen. If no operation is performed for 20 seconds on the other screens, the display will automatically return to the home screen. ① Group icon Indicates the power of group A is turned off. Indicates the power of group A is turned on. - Page 8 Note: If the batteries are removed and reinserted while the power key is set to Locked, the lock state of the Power key will not be changed. You can turn on the receiver by long pressing the power button. Power of the Group. When you only use one group signal, please turn off the other group to save battery.
- Page 9 Auto scan function. Automatically scan an available and clear channel. Details of operation, please refer to "Using the auto scan function" (page 17). Group ettings Group ettings Matc h with TX Matc h with TX Infrared matching function. Match the receiver and transmitter via infrared.
-
Page 10: Body-Pack Transmitter Uwmic10-Tx10
Serial Number. Body-pack Transmitter UwMic10-TX10 Introduction This transmitter is a compact transmitter that employs a crystal-controlled PLL synthesizer. It is equipped with a muting function and a BMP-type microphone input connector. The RF power output can be switched among high, middle and low. - Page 11 ① Antenna ② AUDIO indicator / IR (infrared detector) AUDIO indicator: Indicates the audio input level. IR (infrared detector): Gets the frequency from the receiver Solid Green: Audio input level is appropriate. Flashing Red: Audio is muted (i.e., disabled). For details on setting the mute function, please refer to "Set Mute key"...
-
Page 12: Attaching Accessories
Attaching Accessories Attach a belt clip. Insert one end of the belt clip into one of two holes on either side of the transmitter, and then insert the other end into the hole on the other side. Connect the mcirophone. For a secure connection, turn to lock the connector. -
Page 13: Lcd Display Operation Guide
LCD Display Operation Guide ① ② ③ ④ ⑤ ⑥ ⑦ Home screen. If no operatIon is performed for 20 seconds on the other screens, the display will automatically return to the home screen. ① RF transmission power indicator Indicates the current transmission power level. For details on setting the level, please see “Select RF power level”... - Page 14 Select Channel. There are 96 channels with carrier frequency ranging from 614MHz to 696MHz. Default is “Channel 01” and “614.560MHz.” Select Group. You can choose “A” or “B” channel group. Each group has 96 channels. Default is “Group A.” Select RF power level. You can set the transmitted RF power to High, Middle or Low.
- Page 15 IR Match. Set to match with the receiver. The screen will display “Matching” when in process. After successful matching, it will indicate “Match finished.” Set Backlight. Select ON, OFF or Delay 10 / 30 /60 seconds. Default is “Delay 10s.” Restore default setting. Version of the UwMic10-TX10. Serial Number. / 13...
-
Page 16: Hand-Held Microphone Uwmic10-Hu10
Hand-held Microphone UwMic10-HU10 Introduction Saramonic HU10 is a handheld wireless UHF microphone transmitter features a compact metallic body, an easy-to-read LCD display, a RF power switch and a PLL synthesizer. The broadcast quality microphone will capture crystal clear and rich sound. It has a built-in antenna, a muting function and power lock function. -
Page 17: Setup Guide
(Option) Set the RF power to HIGH or LOW. The transmit power level varies depending on the model. Press the power button to turn on the HU10. Turn on the receiver UwMic10-RX10 and sync with the transmitter HU10. Details of operation, please refer to "For HU10" (page 19). -
Page 18: Operation Guide
Operation Guide Install the batteries. ① UwMic10-RX10 and UwMic10-TX10: • Long press the Power key to turn the unit off. • Slide the two catches inward and pull out the battery compartment. • Insert two AA size batteries according to the polarity indicators and close the compartment. - Page 19 Connect the receiver to the mic jack of a camera, camcorder or mixer with the supplied cable. Turn on the receiver by long pressing the power button. Set the channel of the receiver by two ways: ① Using the auto scan function •...
- Page 20 ② Manually setting the receiver channel. • Use the + or – button to display the channel menu on the receiver. • Long press the SET button to select the menu. • Use the + or – button to select the desired channel and confirm it by short pressing the SET button.
- Page 21 • Both long press the SET button to select the menu and short press it to confirm. • Place the infrared transmitter port on the receiver near the infrared detector on the transmitter. • If “Match finished” displayed on the LCD screen, the frequency for use on the transmitter is set.
-
Page 22: Specification
② M anually setting the transmitter channel (Only available on the UwMic10-TX10). • Turn on the transmitter by long pressing the power button. • Use the + or – button to display the channel setting menu on the transmitter. • Long press the SET button to select the menu. -
Page 23: Transmitter Tx10 And Hu10
Spur suppression -60 dB Weight Approx. 218.7g (excluding batteries) Battery Two AA size batteries Dimensions 170.9 × 63.5 × 30.0 mm Operating temperature 0 °C to 50 °C Storage temperature –20 °C to +55°C Transmitter TX10 and HU10 Channel number Channel group A or B Oscillator type... -
Page 24: Packing List
Packing list TX10 • Body-pack transmitter: TX10 • Omni-directional lavalier microphone • Microphone holder clip • Wind screen • Belt clip / 22... - Page 25 RX10 • Portable receiver: RX10 • Shoe mount adapter • Belt clip • XLR-BMP audio output cable • 3.5mm plug-bmp audio cable HU10 • Hand-held microphone: HU10 Warranty card User manual / 23...
- Page 26 / 24...
- Page 28 The Saramonic logo is trademark which is registered and owned by Saramonic International. COPYRIGHT 2011-2021 SARAMONIC INTERNATIONAL ( A brand of DSQN ) Email: info @ saramonic.com...
