D-Link DSL-2642B User Manual

Hide thumbs Also See for DSL-2642B:
Table of Contents

Advertisement

Quick Links

Download this manual
4fu06

Advertisement

Table of Contents
loading

Related Manuals for D-Link DSL-2642B

Summary of Contents for D-Link DSL-2642B

  • Page 1 4fu06...

  • Page 2: Table Of Contents

    Advanced Settings ..................55 ..................... 97 YSTEM MAC Filtering....................56 STATUS....................... 98 ..................57 ..................... 98 ORWARDING EVICE DMZ ........................ 59 ................... 99 IRELESS LIENTS ..................59 DHCP C ....................99 ARENTAL ONTROL LIENTS Block Website..................... 60 ......................100 D-Link DSL-2642B User Manual...
  • Page 3 Table of Contents ..................... 101 TATISTICS ....................102 OUTING HELP......................... 103 TROUBLESHOOTING ..................104 NETWORKING BASICS .................. 106 IP A ................106 HECK DDRESS IP A ..............107 TATICALLY SSIGN DDRESS TECHNICAL SPECIFICATIONS ..............108 D-Link DSL-2642B User Manual...

  • Page 4: Package Contents

     One straight-through Ethernet cable  One Quick Installation Guide Note: Using a power supply with a different voltage rating than the one included with the DSL-2642B will cause damage and void the warranty for this product. System Requirements  ADSL Internet service ...

  • Page 5: Features

    This eliminates the need to reconfigure every host whenever changes in network topology occur.  Network Address Translation (NAT) – For small office environments, the DSL-2642B allows multiple users on the LAN to access the Internet concurrently through a single Internet account. This provides Internet access to everyone in the office for the price of a single user.

  • Page 6: Hardware Overview

    Ethernet LAN Power Insert Use the adapter shipped with the Router to connect to power Reset Button source To manually reset, depress button with the power on for approximately 5 to 8 seconds. D-Link DSL-2642B User Manual...

  • Page 7: Leds

    Ethernet port. Power A steady green light indicates the unit is powered on. When the device is powered off this remains dark. Lights steady red during power on self-test (POST) or the device is malfunction. D-Link DSL-2642B User Manual...

  • Page 8: Installation

    Operating Systems The DSL-2642B uses an HTML-based web interface for setup and management. The web configuration manager may be accessed using any operating system capable of running web browser software, including Windows 98 SE, Windows ME, Windows 2000, Windows XP, and Windows Vista.
  • Page 9 LAN side of the bridge, such as a PC, a server, a gateway device such as a router or similar firewall hardware. The IP address can be assigned in a number of ways. Your network service provider will give you instructions about any additional connection software or NIC configuration that may be required. D-Link DSL-2642B User Manual...

  • Page 10: Information You Will Need From Your Adsl Service Provider

    VPI and VCI as instructed by your ADSL service provider for the additional connections. This setting can be changed in the WAN Settings window of the web management interface. D-Link DSL-2642B User Manual...

  • Page 11: Information You Will Need About

    IP address used for DHCP service on the LAN when DHCP is enabled. LAN Subnet Mask for the DSL-2642B This is the subnet mask used by the DSL-2642B, and will be used throughout your LAN. The default subnet mask is 255.255.255.0. This can be changed later.

  • Page 12: Information You Will Need About Your Lan Or Computer

    Ethernet NIC If your computer has an Ethernet NIC, you can connect the DSL-2642B to this Ethernet port using an Ethernet cable. You can also use the Ethernet ports on the DSL-2642B to connect to other computer or Ethernet devices.

  • Page 13: Factory Reset Button

    You should use a crossed cable when connecting the Router to a normal (MDI-X) port on a switch or hub. Use a normal straight-through cable when connecting it to an uplink (MDI-II) port on a hub or switch. The rules governing Ethernet cable lengths apply to D-Link DSL-2642B User Manual...
  • Page 14 MDI-X ports (1x, 2x, etc.) with a crossed cable. Computer to Router Connection You can connect the Router directly to a 10/100BASE-TX Ethernet adapter card (NIC) installed on a PC using the Ethernet cable provided. D-Link DSL-2642B User Manual...

  • Page 15: Configuration

    Section 3 – Configuration Configuration This section will show you how to set up and configure your new D-Link Router using the Web-based configuration utility. Web-based Configuration Utility Connect to the Router To configure the WAN connection used by the Router it is first necessary to communicate with the Router through its management interface, which is HTML-based and can be accessed using a web browser.

  • Page 16: Quick Setup

    Router including how to change IP settings and DHCP server setup. QUICK SETUP Click the Setup Wizard button in the middle of the main window of the Router’s opening page to launch a series of setup windows. D-Link DSL-2642B User Manual...
  • Page 17 QUICK SETUP – CHANGE DEVICE LOGIN PASSWORD This window of the Setup Wizard is used to change the Router password. D-Link recommends to help secure your network, the user change the Current Password from the factory default “admin.” The New Password should be between 1 and 16 alphanumeric characters.
  • Page 18 Select Automatically synchronize with Internet time servers to select first and second NTP (Network Time Protocol) server. Click Copy Your computer’s Time Settings to synchronize the Router’s time with your computer. Click the Next button to continue. D-Link DSL-2642B User Manual...
  • Page 19 Quick Setup windows. The available Protocol modes are: PPPoE, PPPoA, Dynamic IP, Static IP and Bridge. Select PPPoE or PPPoA in the Protocol drop-down list to see the following items. D-Link DSL-2642B User Manual...
  • Page 20 PPPoE/PPPoA protocol, the available connection and encapsulation types are VC-Mux and LLC. Tick the Enable Firewall check box to enable the firewall function of this connection. Select Dynamic IP in the Protocol drop-down list to see the following items. D-Link DSL-2642B User Manual...
  • Page 21 Connection Type from the drop-down menu. The available connection and encapsulation types are LLC and VC-Mux. Tick the Enable Firewall check box to enable the firewall function of this connection Select Static IP in the Protocol drop-down list to see the following items. D-Link DSL-2642B User Manual...
  • Page 22 Select the specific Connection Type from the drop-down menu. The available connection and encapsulation types are LLC, and VC-Mux. Tick the Enable Firewall check box to enable the firewall function of this connection Select Bridge in the Protocol drop-down list to see the following items. D-Link DSL-2642B User Manual...
  • Page 23 The Internet connection cannot function if these values are incorrect. Select the specific Connection Type from the drop-down menu. The available connection and encapsulation types are LLC and VC-Mux. Click the Next button to continue. D-Link DSL-2642B User Manual...
  • Page 24 Level is set to None. There are 3 security options the user can choose: WEP, WPA-PSK or WPA2-PSK. After selecting the Security mode, enter the security key below. Deselect Enable your Wireless Network for skipping the wireless configurations. Click the Next button to go to the last step. D-Link DSL-2642B User Manual...
  • Page 25 Back button. QUICK SETUP – DSL ROUTER REBOOT The window opens to indicate the rebooting process of the Router. Once the rebooting process is completed, it will go back to the main web page. D-Link DSL-2642B User Manual...

  • Page 26: Internet Setup

    In this page, all available WAN connection displays in the table. Click the corresponding button to edit the connection. Click the corresponding button to delete the connection. Click the Add button to see the window in the next page for adding a WAN connection. D-Link DSL-2642B User Manual...

  • Page 27: Ppp Over Ethernet (Pppoe)

    Select WAN service type: Choose the appropriate WAN Service Type here. Click the PPP over Ethernet (PPPoE) radio button to configure PPPoE mode. Enter Service Description: This field will display an automated service description. Enable IPv6 for this service: Tick this option to enable IPv6. D-Link DSL-2642B User Manual...
  • Page 28 Bridge PPP Frames Between WAN and Local Ports: Tick this option to bridge PPPoE frames between WAN and local ports. Enable IGMP Multicast: Tick this option to allow IGMP packets to go through the WAN interface in both directions. D-Link DSL-2642B User Manual...
  • Page 29 User the following Static DNS IP address: click the radio button to manually enter the Primary and Secondary DNS Server IP addresses for this connection. Click the Apply button to accept these changes. Click the Cancel button to discard these changes. D-Link DSL-2642B User Manual...

  • Page 30: Ip Over Ethernet (Ipoe)

    Select WAN service type: Choose the appropriate WAN Service Type here. Click the IP over Ethernet radio button to configure IPoE mode. Enter Service Description: This field will display an automated service description. Enable IPv6 for this service: Tick this option to enable IPv6. D-Link DSL-2642B User Manual...
  • Page 31 IP for the connection. WAN IP Address: Enter the static IP address for the connection. WAN Subnet mask: Enter the subnet mask of the static IP address. WAN gateway IP Address: Enter the gateway of the static IP address. D-Link DSL-2642B User Manual...
  • Page 32 Tick this option to enable Fullcone NAT for this connection. Enable Firewall: Tick this option to enable firewall for this connection. Enable IGMP Multicast: Tick this option to allow IGMP packets to go through the WAN interface in both directions. D-Link DSL-2642B User Manual...
  • Page 33 User the following Static DNS IP address: click the radio button to manually enter the Primary and Secondary DNS Server IP addresses for this connection. Click the Apply button to accept these changes. Click the Cancel button to discard these changes. D-Link DSL-2642B User Manual...

  • Page 34: Bridging

    Enter Service Description: This field will display an automated service description. Enable IPv6 for this service: Tick this option to enable IPv6. Click the Apply button to accept these changes. Click the Cancel button to discard these changes. D-Link DSL-2642B User Manual...

  • Page 35: Ppp Over Atm (Pppoa)

    Click the PPPoA radio button to configure PPPoA mode. Service Category: Choose the appropriate Service Category here. Enable Quality of Service: Tick this option to enable Quality of Service. Enter Service Description: This field will display an automated service description. D-Link DSL-2642B User Manual...
  • Page 36 IPv4 Address: The option appears when Use Static IPv4 Address is selected. Enter the Static IP version 4 address used here. Enable IGMP Multicast: Tick this option to allow IGMP packets to go through the WAN interface in both directions. D-Link DSL-2642B User Manual...
  • Page 37 User the following Static DNS IP address: click the radio button to manually enter the Primary and Secondary DNS Server IP addresses for this connection. Click the Apply button to accept these changes. Click the Cancel button to discard these changes. D-Link DSL-2642B User Manual...

  • Page 38: Ip Over Atm (Ipoa)

    Enable Quality of Service: Tick this option to enable Quality of Service. Enter Service Configureation: Choose the appropriate WAN Service Type here. WAN IP Address: Enter the WAN IP address used here. WAN Subnet Mask: Enter the subnet of the WAN IP address. D-Link DSL-2642B User Manual...
  • Page 39 Primary/Secondary DNS server: Enter the Primary and Secondary DNS Server IP addresses for this connection. Click the Apply button to accept these changes. Click the Cancel button to discard these changes. D-Link DSL-2642B User Manual...
  • Page 40 Peak Cell Rate: Here the user can enter the Peak Cell Rate used. Sustainable Cell Rate: Here the user can enter the Sustainable Cell Rate used. Maximum Burst Size: Here the user can enter the Maximum Burst Size used. D-Link DSL-2642B User Manual...

  • Page 41: Wireless Settings

    It has two subcategories: Wireless Basics and Wireless Security. You can either point to the Wireless Settings on the left window and click one of the submenus, or click one of the buttons in the Wireless Settings window. D-Link DSL-2642B User Manual...

  • Page 42: Wireless Basics

    Channels available for wireless LAN communication are subject to regional and national regulation. 6. Select a wireless protocol in the 802.11 Mode drop-down list. 7. Click Apply to save the settings. D-Link DSL-2642B User Manual...

  • Page 43: Wireless Security

    2. Select a wireless security mode in the Network Authentication drop-down menu. Network Authentication methods are Open, Shared, 802.1X, WPA, WPA-PSK, WPA2, WPA2-PSK, Mixed WPA2/WPA and Mixed WPA2/WPA-PSK. 3. Configure the security information below. 4. Click the Apply button to save the settings. D-Link DSL-2642B User Manual...
  • Page 44 PIN to start connecting the wireless connections with WPS function. Device PIN: The pin number that is used to have wireless connection with WPS station. WPS Add External Registrar: Click the button to search for the external registrar. D-Link DSL-2642B User Manual...
  • Page 45 Encryption Strength. Enter 13 ASCII characters or 26 hexadecimal digits for 128-bit encryption keys Enter 5 ASCII characters or 10 hexadecimal digits for 64-bit encryption keys. Click the Apply button to save the settings. D-Link DSL-2642B User Manual...
  • Page 46 WPA known as WPA-Enterprise and WPA-Personal. Use the Network Authentication drop-down menu to select WPA-Enterprise/WPA only. Specify a Radius Server IP Address, Radius Server Port and a Radius Key. Click the Apply button to save the settings. D-Link DSL-2642B User Manual...
  • Page 47 Use the Network Authentication drop-down menu to select WPA-Personal/WPA only. Specify a Pre-Shared Key. Note that there is NO Radius Server settings required when configuring WPA-PSK. Enter the Group Key Interval and Encryption if needed. Click the Apply button to save the settings. D-Link DSL-2642B User Manual...
  • Page 48 WPA2 known as WPA2-EAP (Enterprise) and WPA2- PSK (Personal). Use the Network Authentication drop-down menu to select WPAA-Enterprise/WPA2 only Specify a Radius Server IP Address, Radius Server Port and a Radius Key. Click the Apply button to save the settings. D-Link DSL-2642B User Manual...
  • Page 49 Use the Network Authentication drop-down menu to select WP-Personal/WPA2 only. Specify a Pre-Shared Key. Note that there is NO Radius Server settings required when configuring WPA2-PSK. Enter the Group Key Interval and Encryption if needed. Click the Apply button to save the settings. D-Link DSL-2642B User Manual...
  • Page 50 WPA2 to WPA. Use the Network Authentication drop-down menu to select WPA-Enterprise/Auto. Specify a Radius Server IP Address, Radius Server Port and a Radius Key. Click the Apply button to save the settings. D-Link DSL-2642B User Manual...
  • Page 51 Use the Network Authentication drop-down menu to select WPA-Personal/Auto. Specify a Pre-Shared Key. Note that there is NO Radius Server settings required when configuring Mixed WPA2/WPA-PSK. Enter the Group Key Interval and Encryption if needed. Click the Apply button to save the settings. D-Link DSL-2642B User Manual...

  • Page 52: Local Network

    Configure the second IP Address and Subnet Mask for LAN Interface: Tick this option to enable the use of a second IP address for this device. IP Address: Enter the device’s new second IP here. Subnet Mask: Enter the device’s new second subnet mask here. D-Link DSL-2642B User Manual...
  • Page 53 DHCP Reservation List section. Number of Dynamic DHCP Clients: Here the number of dynamic DHCP clients will be listed. Information shown is Computer Name, MAC Address, IP Address and Expire Time. D-Link DSL-2642B User Manual...

  • Page 54: Time And Date

    Year, Month, Day, Hour, Minute and Second in the Set the Date and Time Manually system, or just click Copy Your Computer’s Time Settings button to synchronize the time with the computer. When you are finished, click the Apply button to take effect. D-Link DSL-2642B User Manual...

  • Page 55: Advanced

    It has two subcategories: Advanced Settings, and MAC Filtering. You can either point to the Advanced Wireless on the left window and click one of the submenus, or click one of the buttons in the Wireless Settings window. D-Link DSL-2642B User Manual...

  • Page 56: Advanced Settings

    RTS threshold, set the wakeup interval for clients in power-save mode, set the beacon interval for the access point, set XPress mode and set whether short or long preambles are used and more. D-Link DSL-2642B User Manual...

  • Page 57: Mac Filtering

    Click Add at the bottom of the window to enter MAC address. Click Apply at the bottom of the page to add the MAC address to the wireless MAC filtering list. Click Apply to take effect. D-Link DSL-2642B User Manual...

  • Page 58: Port Forwarding

    PC. To remove an Active Port Forwarding entry in the table, click the corresponding button. To modify a table entry, click the corresponding button, make the desired changes, and then click the Apply button. D-Link DSL-2642B User Manual...
  • Page 59 Advanced -> Schedules, and enter the Server IP Address. Enter a range of ports in the External Start Port and External End Port fields, and then click the Apply button to see the customized rule in the Port Forwarding Setup section. D-Link DSL-2642B User Manual...

  • Page 60: Dmz

    It has two subcategories: Block Website and Block MAC Address. You can either point to the Parental Control on the left window and click one of the submenus, or click one of the buttons in the Parental Control window. D-Link DSL-2642B User Manual...

  • Page 61: Block Website

    Block Website. To remove a Blocked URL entry in the table, click the corresponding button. To modify a table entry, click the corresponding button, make the desired changes, and then click the Apply button. D-Link DSL-2642B User Manual...

  • Page 62: Block Mac Address

    Block Website. To remove a Blocked URL entry in the table, click the corresponding button. To modify a table entry, click the corresponding button, make the desired changes, and then click the Apply button. D-Link DSL-2642B User Manual...

  • Page 63: Filtering Options

    It has three subcategories: Inbound Filtering, Outbound Filtering and Bridge Filtering. You can either point to the Filtering Options on the left window and click one of the submenus, or click one of the buttons in the Filtering Options window. D-Link DSL-2642B User Manual...

  • Page 64: Inbound Filtering

    Click the Apply button to add the entry in the Active Inbound IP Filtering table. To remove an entry in the table, click the corresponding button. To modify a table entry, click the corresponding button, make the desired changes, and then click the Apply button. D-Link DSL-2642B User Manual...
  • Page 65 The Source/Destination Port is the TCP/UDP port on Destination either the LAN or WAN depending on if you are Port configuring an Outbound or Inbound Filter rule. Select the WAN interfaces you want to apply for this Interface rule. D-Link DSL-2642B User Manual...

  • Page 66: Outbound Filtering

    Click the Apply button to add the entry in the Active Outbound IP Filtering table. To remove an entry in the table, click the corresponding button. To modify a table entry, click the corresponding button, make the desired changes, and then click the Apply button. D-Link DSL-2642B User Manual...
  • Page 67 The Source/Destination Port is the TCP/UDP port on Destination either the LAN or WAN depending on if you are Port configuring an Outbound or Inbound Filter rule. Select the WAN interfaces you want to apply for this Interface rule. D-Link DSL-2642B User Manual...

  • Page 68: Bridge Filtering

    ALLOW those matching any of the specific rules listed for the rules that configured below. To remove an entry in the table, click the corresponding button. To modify a table entry, click the corresponding button, make the desired changes, and then click the Apply button. D-Link DSL-2642B User Manual...
  • Page 69 Select a direction (LAN=>WAN, WAN=>LAN, or LAN<=>WAN) in the Frame Direction list. Select the WAN interface you want to apply for this rule. Click the Apply button to add the entry in the Active Bridge Filters table. D-Link DSL-2642B User Manual...

  • Page 70: Dns Setup

    DNS server addresses radio button and enter these IP addresses in the available entry fields for the Preferred DNS Server and the Alternative DNS Server. When you have configured the DNS settings as desired, click the Apply button. D-Link DSL-2642B User Manual...

  • Page 71: Dynamic Dns Setup

    Apply button. DDNS requires that an account be setup with one of the supported DDNS servers prior to engaging it on the Router. This function will not Note work without an accepted account with a DDNS server. D-Link DSL-2642B User Manual...

  • Page 72: Ipv6 Lan Config

    Static: Click the radio button to have a site prefix configured below. Site Prefix: Enter the site prefix. Site Prefix Length: Enter the site prefix length. Enable MLD Snooping: Tick the check box to enable MLD snooping. D-Link DSL-2642B User Manual...

  • Page 73: Network Tools

    Quality of Service, Queue Config, QoS Classification, UPnP, DSL, SNMP, TR-069, and Certificates. You can either point to the Network Tools on the left window and click one of the submenus, or click one of the buttons in the Network Tools window. D-Link DSL-2642B User Manual...

  • Page 74: Port Mapping

    To access Port Mapping, point to the Network Tools on the left window and click Port Mapping submenu, or click the Port Mapping button in the Network Tools window. Tick the Enable Virtual Ports on check box and enter an interface to apply for. Click Apply to take effect. D-Link DSL-2642B User Manual...
  • Page 75 Section 3 – Configuration Click the Add button to see the Add Port Mapping section. To create a new mapping group, enter Group Name, add interfaces to Grouped Interfaces. Click the Apply button to save the changes. D-Link DSL-2642B User Manual...

  • Page 76: Igmp

    When the Enable IGMP Snooping check box is selected, multicast packets are allowed to pass in both directions on the WAN interface. Most users will want to leave this on. Click the Apply button to take effect. D-Link DSL-2642B User Manual...

  • Page 77: Quality Of Service

    Large amounts of non-critical data can be scaled so as not to affect these prioritized sensitive real-time programs. Tick the Enable QoS check box and select a default DSCP mark from the drop-down menu. When you are finished, click Apply/Save to take the settings effect. D-Link DSL-2642B User Manual...

  • Page 78: Queue Config

    Click the Add button to add a Queue Configuration entry. In the Add Queue Config section, enter the name and select from the Enable, Interface, and Precedent drop-down menu to configure the queue. Click the Apply/Save button to save and activate this rule. D-Link DSL-2642B User Manual...

  • Page 79: Queue Classfication

    IP header DSCP byte. A rule consists of a class name and at least one condition below. All of the specified conditions in this classification rule must be satisfied for the rule to take effect. Click on the Add button to add a new entry. D-Link DSL-2642B User Manual...
  • Page 80 Please remember that all of the specified conditions on this window must be met for the rule to take effect. Click the Apply/Save button to save and activate this rule. D-Link DSL-2642B User Manual...

  • Page 81: Upnp

    UPnP is a protocol supported by diverse networking media including Ethernet, Firewire, phone line, and power line networking. To enable UPnP for any available connection, tick the Enable UPnP check box, and click the Apply button. D-Link DSL-2642B User Manual...

  • Page 82: Dsl

    To access ADSL, point to the Network Tools on the left window and click DSL submenu, or click the ADSL Settings button in the Network Tools window. This window allows you to select the desired modulation, phone line pair, and capability. Click the Apply button when you are finished. D-Link DSL-2642B User Manual...

  • Page 83: Snmp

    To access SNMP, point to the Network Tools on the left window and click SNMP submenu, or click the SNMP button in the Network Tools window. Simple Network Management Protocol is a standard for internetwork and intranetwork management. Tick the Enable SNMP Agent check box and configure the parameters for SNMP on this window and then click the Apply button. D-Link DSL-2642B User Manual...
  • Page 84 Connection Request Password: Enter the connection request password used for this feature in here. Click on the Apply button to accept these changes. Click on the Cancel button to discard these changes. D-Link DSL-2642B User Manual...

  • Page 85: Certificates

    Certificates window. Certificates – Local Cert This is for peers to verify your identity. Click the Create Certificate Request button to add a local certificate entry. Click Import Certificate button to paste certificate content and private key. D-Link DSL-2642B User Manual...
  • Page 86 Section 3 – Configuration Certificates – Trusted CA This is for you to verify peers’ certificates. Click Import Certificate button to paste certificate content. D-Link DSL-2642B User Manual...

  • Page 87: Routing

    It has three subcategories: Static Route, Default Gateway and RIP. You can either point to the Routing on the left window and click one of the submenus, or click one of the buttons in the Routing window. D-Link DSL-2642B User Manual...

  • Page 88: Static Route

    Click Apply to see the entry in the Active Static Route table. To remove an entry in the table, click the corresponding button. To modify a table entry, click the corresponding button, make the desired changes, and then click the Apply button. D-Link DSL-2642B User Manual...

  • Page 89: Default Gateway

    To enable RIP, tick the Enable check box of the interface you want to enable, select the Version (1, 2, or Both) and Operation (Active or Passive), and tick the Enable check box in the corresponding entry. Click the Apply/Save button to let your changes take effect. D-Link DSL-2642B User Manual...

  • Page 90: Schedules

    Schedule Rule table. To remove an entry in the table, click the corresponding button. To modify a table entry, click the corresponding button, make the desired changes, and then click the Apply button. D-Link DSL-2642B User Manual...

  • Page 91: Maintenance

    To reset the Router to its factory default settings, click the Restore Default Settings button. You will be prompted to confirm your decision to reset the Router. The Router will reboot with the factory default settings including IP settings (192.168.1.1) and Administrator password (admin). D-Link DSL-2642B User Manual...

  • Page 92: Firmware Update

    Click the Update Firmware button to begin copying the file. The file will load and restart the Router automatically. Performing a Firmware Upgrade can sometimes change the configuration settings. Make sure to backup the Router’s configuration settings before upgrading the firmware. Note D-Link DSL-2642B User Manual...

  • Page 93: Access Controls

    There are three subcategories in Access Controls: Account Password, Services, and IP Address. You can Y either point to the Access Controls on the left window and click one of the submenus, or click one of the buttons in the Access Controls window. D-Link DSL-2642B User Manual...

  • Page 94: Account Password

    Confirm Password field to be certain you have typed it correctly. You can configure the idle time between 5 and 30 minutes for the webpage asking you to logout. Click the Apply button to save the changes. D-Link DSL-2642B User Manual...

  • Page 95: Services

    This page lists out all the available services including FTP, HTTP, ICMP, SNMP, SSH, TELNET, and TFTP that can enable at LAN, WAN or both. Tick to enable the services, or deselect to disable them. When you are finished, click Apply/Save to save the settings. D-Link DSL-2642B User Manual...

  • Page 96: Ip Address

    Apply in the section. The IP address will show in the table in the Remote Web and Telnet Management section. Tick the Enable Access Control Mode check box and click Apply in this section to enable the function. D-Link DSL-2642B User Manual...

  • Page 97: Diagnostics

    IP addresses. The diagnostics feature executes a series of tests of your system software and hardware connections. Use this window when working with your ISP to troubleshoot problems. D-Link DSL-2642B User Manual...

  • Page 98: System Log

    Select the Log Level and Display Level from the drop-down lists. The levels available are the same for each type of level: Emergency, Alert, Critical, Error, Warning, Notice, Informational and Debugging. Click the Apply button to allow your new settings to take effect. D-Link DSL-2642B User Manual...

  • Page 99: Status

    To access the Device Info window, click the Device Info button in the Status directory. Use this window to quickly view basic current information about the LAN and WAN interfaces and device information including Firmware Version and MAC address. D-Link DSL-2642B User Manual...

  • Page 100: Wireless Clients

    To access the DHCP Clients window, click the DHCP Clients button in the Status directory. The Connected LAN Clients list displays active DHCP clients when the Router is acting as a DHCP server. Click the Refresh button to update the status. D-Link DSL-2642B User Manual...

  • Page 101: Logs

    Section 3 – Configuration Logs To access the Logs window, click the Logs button in the Status directory. This page displays the event logs of the Router. Click the Refresh button to update the status. D-Link DSL-2642B User Manual...

  • Page 102: Statistics

    Statistics To access the Statistics window, click the Statistics button in the Status directory. Use this window to monitor traffic on the Local Network, Internet or ADSL connection. This window also displays information concerning ADSL status. D-Link DSL-2642B User Manual...

  • Page 103: Routing Info

    Routing Info To access the Routing Info window, click the Routing Info button in the Status directory. This page is used to direct forwarding by matching destination addresses to the network paths used to reach them. D-Link DSL-2642B User Manual...

  • Page 104: Help

    Section 3 – Configuration Help To access the Help window, click the Help directory. D-Link DSL-2642B User Manual...

  • Page 105: Troubleshooting

    Troubleshooting This chapter provides solutions to problems that might occur during the installation and operation of the DSL-2642B. Read the following descriptions if you are having problems. (The examples below are illustrated in Windows® XP. If you have a different operating system, the screenshots on your computer will look similar to the following examples.)
  • Page 106 There is a potential security issue if the firewall is disabled on your PC. Please remember to turn it back on once you have finished the whole installation procedure. This will enable you to be able to surf the Internet without any problem. D-Link DSL-2642B User Manual...

  • Page 107: Networking Basics

    Check Your IP Address After you install your new D-Link adapter, by default, the TCP/IP settings should be set to obtain an IP address from a DHCP server (i.e. wireless router) automatically. To verify your IP address, please follow the steps below.

  • Page 108: Statically Assign A Nip Address

    Windows® 2000 - From the desktop, right-click the My Network Places > Properties. Step 2 Right-click the Local Area Connection which represents your D-Link network adapter and select Properties. Step 3 Highlight Internet Protocol (TCP/IP) and click on the Properties.

  • Page 109: Technical Specifications

    Technical Specifications  RFC1334 PAP ADSL Standards DHCP Server  RFC2364 PPP over ATM  RFC1389 RIP v2  ANSI T1.413 Issue 2  RFC1577 Classical IP over  RFC2516 PPP over  ITU G.992.1 (G.dmt) Annex A  ITU G.992.2 (G.lite) Annex A Ethernet ...
