  • Page 1 Table of Content D-Link DSL-2640B User Manual...

  • Page 2: Table Of Contents

    .................... 70 WIRELESS ......................27 HECK YOUR ADDRESS ................71 LAN SETUP......................32 TATICALLY SSIGN AN ADDRESS TIME ........................34 TECHNICAL SPECIFICATIONS ................72 PARENTAL CONTROL ..................35 LOGOUT .......................36 CONTACTING TECHNICAL SUPPORT ..............73 ADVANCED ......................37 PORT FORWARDING ...................37 D-Link DSL-2640B User Manual...

  • Page 3: Product Overview

    • One straight-through Ethernet cable • One Quick Installation Guide Note: Using a power supply with a different voltage rating than the one included with the DSL-2640B will cause damage and void the warranty for this product. System Requirements • ADSL Internet service •...

  • Page 4: Introduction

    ULTIMATE INTERNET CONNECTION The DSL-2640B ADSL2+ router is a versatile, high-performance remote router for home and the small office. With integrated ADSL2/2+ supporting up to 24Mbps download speed, firewall protection, Quality of Service (QoS), 802.11g wireless LAN and 4 Ethernet switch ports, this router provides all the functions that a home or small office needs to establish a secure and high-speed remote link to the outside world.

  • Page 5: Features

    • Compatible with 802.11b Devices - The DSL-2640B is still fully compatible with the IEEE 802.11b and g standards, so it can connect with existing 802.11b and g PCI, USB and Cardbus adapters.

  • Page 6: Hardware Overview

    Use the adapter shipped with the Use the ADSL cable to connect Push in to power-on the Router. Push again to power-off the Router to connect to power to the your telephone line (RJ-11 Router source port) D-Link DSL-2640B User Manual...

  • Page 7: Led S

    Steady red light indicates failed wireless connection. A blinking green device. Internet connection. Dark if no WAN protocol is light indicates activity on the WLAN configured or ADSL is offline. interface D-Link DSL-2640B User Manual...

  • Page 8: Installation

    Before you Begin Please read and make sure you understand all the prerequisites for proper installation of your new Router. Have all the necessary information and equipment on hand before beginning the installation. D-Link DSL-2640B User Manual...

  • Page 9: Installation Notes

    Operating Systems The DSL-2640B uses an HTML-based web interface for setup and management. The web configuration manager may be accessed using any operating system capable of running web browser software, including Windows 98 SE, Windows ME, Windows 2000, and Windows XP.
  • Page 10 DSL-2640B through the wireless interface. Security for wireless communication can be accomplished in a number of ways. The DSL-2640B supports WPA (Wi-Fi Protected Access), WPA2, and mixed WPA/WPA2. Wireless access can also be controlled by selecting MAC addresses that are allowed to associate with the device. Please read the section on Wireless Configuration.

  • Page 11: Information You Will Need From Your Adsl Service Provider

    ADSL, ADSL2, and ADSL2+ modulation. However, if you are instructed to specify the modulation type used for the Router, you may choose among the numerous options available on the Modulation Type drop-down menu on the ADSL Configuration window (Advanced > ADSL) D-Link DSL-2640B User Manual...
  • Page 12 ADSL service provider’s network and your computer. If you are setting up the Router for multiple virtual connections, you will need to configure the VPI and VCI as instructed by your ADSL service provider for the additional connections. This setting can be changed in the WAN Settings window of the web management interface. D-Link DSL-2640B User Manual...

  • Page 13: Information You Will Need About Dsl-2640B

    IP address used for DHCP service on the LAN when DHCP is enabled. LAN Subnet Mask for the DSL-2640B This is the subnet mask used by the DSL-2640B, and will be used throughout your LAN. The default subnet mask is 255.255.255.0. This can be changed later.
  • Page 14 Ethernet NIC If your computer has an Ethernet NIC, you can connect the DSL-2640B to this Ethernet port using an Ethernet cable. You can also use the Ethernet ports on the DSL-2640B to connect to other computer or Ethernet devices.

  • Page 15: Wireless Installation Considerations

    1. Keep the number of walls and ceilings between the D-Link router and other network devices to a minimum - each wall or ceiling can reduce your adapter’s range from 3-90 feet (1-30 meters.) Position your devices so that the number of walls or ceilings is minimized.

  • Page 16: Device Installation

    Device Installation The DSL-2640B Wireless ADSL Router maintains three separate interfaces, an Ethernet LAN, a wireless LAN and an ADSL Internet (WAN) connection. Carefully consider the Router’s location suitable for connectivity for your Ethernet and wireless devices. You must have a functioning broadband connection in order to use the Router’s WAN function.

  • Page 17: Network Connections

    (MDI-II) port on a hub or switch. The rules governing Ethernet cable lengths apply to the LAN to Router connection. Be sure that the cable connecting the LAN to the Router does not exceed 100 meters. D-Link DSL-2640B User Manual...
  • Page 18 MDI-X ports (1x, 2x, etc.) with a crossed cable. Computer to Router Connection You can connect the Router directly to a 10/100BASE-TX Ethernet adapter card (NIC) installed on a PC using the Ethernet cable provided as shown in this diagram. D-Link DSL-2640B User Manual...

  • Page 19: Configuration

    Section 4 - Troubleshooting Configuration This section will show you how to configure your new D-Link wireless router using the web-based configuration utility. Web-based Configuration Utility Connect to the Router To configure the WAN connection used by the Router it is first necessary to communicate with the Router through its management interface, which is HTML-based and can be accessed using a web browser.

  • Page 20: Setup

    Router including how to change IP settings and DHCP server setup. WIZARD ADSL SETUP Click on the Setup Wizard button to launch the Setup Wizard. WELCOME TO D-LINK SETUP WIZARD There are three steps to configuring your router. Click on the Next to continue. D-Link DSL-2640B User Manual...
  • Page 21 Section 4 - Troubleshooting STEP 1: CHANGE YOUR DSL-2640B PASSWORD The default password is "admin", in order to secure your network, please modify the password. Note: Confirm Password must be same as "New Password". Of course, you can click on the Skip to ignore the step.
  • Page 22 The Auto PVC Scan feature will not work in all cases so please enter the VPI/VCI numbers if provided by the ISP. Select the Connection Type that your ISP has informed you to use. Click on the Next button to go to the next Setup Wizard window. D-Link DSL-2640B User Manual...
  • Page 23 Please input the correct IP address, Subnet Mask, Default Gateway and DNS information. Note: Should you select to leave default Gateway and DNS information blank, they should be automatically generated. Click on the Next button to go to the next Setup Wizard window. D-Link DSL-2640B User Manual...
  • Page 24 STEP 3: RESTART Click Back to review or modify settings. Click on Restart to apply current settings and reboot the DSL-2640B router. If your Internet connection does not work after the router restarts, you can try the Setup Wizard again with alternative settings or use Manual Setup instead provided you have your Internet connection details as provided to you by your ISP.

  • Page 25: Adsl Setup

    Click on the Save Settings button to save your settings. You will be asked to reboot by a pop-up window. Click on the OK to reboot the router. Click on the Connect button to connect the router to the Internet with the WAN interface. D-Link DSL-2640B User Manual...
  • Page 26 2. Click on the Disconnect button to disconnect the router to the Internet and the icon will be dark. D-Link DSL-2640B User Manual...

  • Page 27: Wireless

    Section 4 - Troubleshooting WIRELESS Use this section to configure the wireless settings for your D-Link router. Please note that changes made in this section will also need to be duplicated onto your wireless clients and PC. To access the WIRELESS (WLAN) settings window, click on the Wireless Setup button in the SETUP directory.
  • Page 28 MY WIRELESS NETWORK window. SECURE MY WIRELESS NETWORK Input the SSID. Select the Wireless Channel. Select the Encryption type. WPA-PSK is more secure than WEP 64 bit. Click on the Apply Settings button to apply the settings D-Link DSL-2640B User Manual...
  • Page 29 Specify the encryption key from the Default WEP Key drop-down menu. Select Authentication type from the drop-down menu. (Shared is better than Open) Click on the Apply Settings button to apply settings. D-Link DSL-2640B User Manual...
  • Page 30 Section 4 - Troubleshooting WIRELESS SECURITY MODE – Personal WPA-PSK WPA-PSK configuration is similar to WEP. The key length is between 8 to 63 ASCII codes. D-Link DSL-2640B User Manual...
  • Page 31 802.1X security measures to overcome some weaknesses in standard WEP applications. A RADIUS server is used to authenticate all potential users. Enter your RADIUS server data: IP Address, Port, and Key. Click on the Apply Settings button to apply settings. D-Link DSL-2640B User Manual...

  • Page 32: Lan Setup

    IP address of the Router the range of IP addresses in the pool used for DHCP on the LAN will also be changed. The IP address pool can be up to 253 IP addresses. D-Link DSL-2640B User Manual...
  • Page 33 Click on the OK to reboot the router. LAN SETUP Do not turn the Router off while it is rebooting. You might need to re-configure your PC NIC settings to enter the Router’s web manager after reboot. D-Link DSL-2640B User Manual...

  • Page 34: Time

    Check the Enable Daylight Saving if needed and then select the proper Daylight Saving Offset drop-down menu. Configure the Daylight Saving Dates from start date to end. Click on the Save Settings button to apply your settings. D-Link DSL-2640B User Manual...

  • Page 35: Parental Control

    Unblock Website button. The checked items will be deleted from the table. INTERNET ACCESS TIME RESTRICTIONS Select days and time frame to allow/deny this rule. Click on the Save Settings button to apply settings. D-Link DSL-2640B User Manual...

  • Page 36: Logout

    The LOGOUT page enables you you to logout of your router configuration and close the browser. To access the LOGOUT setting window, click on the Logout button in the SETUP directory LOGOUT Click on the Logout button to logout router configuration settings close the browser. D-Link DSL-2640B User Manual...

  • Page 37: Advanced

    (WAN-to-LAN traffic). The Port Forwarding function allows remote users to access services on your LAN such as FTP for file transfers or SMTP and POP3 for e-mail. The DSL-2640B will accept remote requests for these services at your Global IP Address, using the specified TCP or UDP protocol and port number, and then redirect these requests to the server on your LAN with the LAN IP address you specify.

  • Page 38: Application Rules

    Select a name from the drop-down menu for pre-configured application or type a name in the Name input box to define your own rules. Enter your Trigger and Firewall port(s), and select the Traffic Type. Click on the Add/Apply button to apply settings. D-Link DSL-2640B User Manual...

  • Page 39: Q O S Setup

    VoIP where it may help prevent dropped calls. Large amounts of non-critical data can be scaled so as not to affect these prioritised sensitive real-time programs. D-Link has pre-setup some often used rules for the QoS. VoIP and H.323 are often used for Internet calls.
  • Page 40 Protocol, Source/Destination IP Range, and Source/Destination Port Range. Click on the Add/Apply button to add and apply this rule. ACTIVE WIRELESS QoS RULES Check the Remove items and click on the Remove Selected button to delete settings. D-Link DSL-2640B User Manual...
  • Page 41 All of the specified conditions in this filter rule must be satisfied for the rule to take effect. To access the OUTBOUND IP FILTER setting window, click on the Outbound Filter button in the ADVANCED directory. D-Link DSL-2640B User Manual...
  • Page 42 Click on the Add/Apply button to add and apply settings. The Active Outbound IP Filter shows detailed information about each created outbound IP filter. To remove an IP filter, click on the Remove button (only appears when there is an existing IP filter). D-Link DSL-2640B User Manual...
  • Page 43 The Inbound Filter allows you to create a filter rule to allow incoming IP traffic by specifying a filter name and at least one condition below. All of the specified conditions in this filter rule must be satisfied for the rule to take effect. To access the INBOUND IP FILTER setting window, click on the Inbound Filter button in the ADVANCED directory. D-Link DSL-2640B User Manual...
  • Page 44 Note: This section only applies when the Firewall is enabled. The Active Inbound IP Filter shows detailed information about each created inbound IP filter. To remove an IP filter, click on the Remove button (only appears when there is an existing IP filter). D-Link DSL-2640B User Manual...

  • Page 45: Dns Setup

    LAN, this ensures that the host can be located from the Internet if the public IP address changes. DDNS requires that an account be setup with one of the supported DDNS service providers (DyndDNS.org or dlinkddns.com). To access the DNS SETUP setting window, click on the DNS Setup button in the ADVANCED directory. D-Link DSL-2640B User Manual...
  • Page 46 DynDns.org and dlinkddns.com. Host Name: Enter the Host Name that you registered with your DDNS service provider. Username or Enter the Username for your DDNS Key: account. Password or Enter the Password for your DDNS account. Key: D-Link DSL-2640B User Manual...

  • Page 47: Firewall & Dmz

    DMZ will be exposed to various types of security risks. If you use the DMZ, take measures (such as client-based virus protection) to protect the remaining client PCs on your LAN from possible contamination through the DMZ. To access the FIREWALL & DMZ setting window, click on the Firewall & DMZ button under the ADVANCED tab. D-Link DSL-2640B User Manual...
  • Page 48 WAN. DMZ SETTING Check the Enable DMZ box and type the IP Address of the server or device on your LAN in the DMZ IP Address box. D-Link DSL-2640B User Manual...
  • Page 49 Section 4 - Troubleshooting APPLICATION LEVEL GATEWAY (ALG) CONFIGURATION Check the relevant ALG options as required. Click on the Apply Settings button to apply settings. D-Link DSL-2640B User Manual...

  • Page 50: Advanced Adsl

    The ADVANCED ADSL settings allow you to choose which ADSL modulation settings your modem router will support. D-Link does not recommend changing these settings unless directed to do so by your ISP. To access the ADVANCED ADSL setting window, click on the Advanced ADSL button in the ADVANCED directory.

  • Page 51: Advanced Wireless

    ADVANCED WIRELESS These options are for users that wish to change the behavior of their 802.11g wireless radio from the standard setting. D-Link does not recommend changing these settings from the factory default. Incorrect settings may impair the performance of your wireless radio. The default settings should provide the best wireless radio performance in most environments.

  • Page 52: Advanced Lan

    Section 4 - Troubleshooting ADVANCED LAN The ADVANCED LAN options are for users that wish to change the LAN settings. D-Link does not recommend changing these settings from factory default. Changing these settings may affect the behavior of your network.

  • Page 53: Remote Management

    Select the management services which you want to enable/disable on your LAN/WAN interface. Click on the Apply Settings button to apply settings. Notice If you disable HTTP service, you’ll not be able to access the router’s configuration window permanently. D-Link DSL-2640B User Manual...

  • Page 54: Maintenance

    PASSWORD The factory default password of this router is 'admin'. To help secure your network, D-Link recommends that you should choose a new password. Please make sure to choose a password you can remember or write it down and keep in a safe and separate location for future reference. If you forget your device password, the only solution is to reset your router to factory default settings and you will loose all your device configuration settings.

  • Page 55: Save/Restore Settings

    To reset the Router to its factory default settings, click on the Restore Device button. You will be prompted to confirm your decision to reset the Router. The Router will reboot with the factory default settings including settings (192.168.1.1) Administrator password (admin). D-Link DSL-2640B User Manual...

  • Page 56: Firmware Update

    Firmware button to begin copying the file. The Router will load the file and restart automatically. Notice Performing a Firmware Upgrade can sometimes change the configuration settings. Be sure to back-up the Router’s configuration settings before upgrading the firmware. D-Link DSL-2640B User Manual...

  • Page 57: Diagnostics

    IP addresses. The diagnostics feature executes a series of test on your system software and hardware connections. Use this window when working with your ISP to troubleshoot problems. D-Link DSL-2640B User Manual...

  • Page 58: System Log

    Local: Display on local host only Remote: Send log file to remote system log server only Server IP IP address of the remote system Address: log server Server UDP UDP port number of the remote system log server Port: D-Link DSL-2640B User Manual...
  • Page 59 Click on the On Log Full check-box to let the system send the E-mail alarm message when the local log is full. VIEW SYSTEM LOG The table lists the system log. Click on the Apply Settings button to apply your settings. D-Link DSL-2640B User Manual...

  • Page 60: Status

    The Device Info page displays a summary overview of your router status, including: Device software version and summary of your Internet configuration (both wireless and Ethernet status). To access the DEVICE INFO setting window, click on the Device Info button in the STATUS directory. GENERAL This window displays current system time and the firmware version. D-Link DSL-2640B User Manual...
  • Page 61 This window displays WAN information including IP address, Mask, Default Gateway, Primary/Secondary DNS Server. WIRELESS LAN This window displays authenticated wireless stations and their status. This window displays LAN information including IP address, Subnet Mask, and DHCP Server. D-Link DSL-2640B User Manual...

  • Page 62: Connected Clients

    To access the CONNECTED CLIENTS setting window, click on the Connected Clients button in the STATUS directory. CONNECTED WIRELESS CLIENTS This window displays authenticated wireless stations and their status. CONNECTED DHCP LAN CLIENTS This window displays all the client devices which have obtained IP addresses from the router. D-Link DSL-2640B User Manual...

  • Page 63: Statistics

    STATISTICS This page displays your router network and data transfer statistics and is helpful for D-Link technicians to assist you in identifying if your router is functioning properly. The information provided is primarily informative and does not affect the function of your router.
  • Page 64 Section 4 - Troubleshooting ADSL STATISTICS This window displays ADSL information including Link Rate, SNR, and some Error Counters. D-Link DSL-2640B User Manual...

  • Page 65: Troubleshooting

    1. Why can’t I access the web-based configuration utility? When entering the IP address of the D-Link router (192.168.1.1 for example), you are not connecting to a website on the Internet or have to be connected to the Internet. The device has the utility built-in to a ROM chip in the device itself.
  • Page 66 • Close your web browser (if open) and open it. • Access the web management. Open your web browser and enter the IP address of your D-Link router in the address bar. This should open the login page for the web management.

  • Page 67: Wireless Basics

    D-Link wireless products are based on industry standards to provide easy-to-use and compatible high-speed wireless connectivity within your home, business or public access wireless networks. Strictly adhering to the IEEE standard, the D-Link wireless family of products will allow you to securely access the data you want, when and where you want it.
  • Page 68 PDAs, headphones, laptops, speakers, and other devices that operate on batteries. Who uses wireless? Wireless technology as become so popular in recent years that almost everyone is using it, whether it’s for home, office, business, D-Link has a wireless solution for it.
  • Page 69 Appendix A - Wireless Basics Using a D-Link Cardbus Adapter with your laptop, you can access the hotspot to connect to Internet from remote locations like: Airports, Hotels, Coffee Shops, Libraries, Restaurants, and Convention Centers. Wireless network is easy to setup, but if you’re installing it for the first time it could be quite a task not knowing where to start. That’s why we’ve put together a few setup steps and tips to help you through the process of setting up a wireless network.

  • Page 70: Networking Basics

    Check your IP address After you install your new D-Link adapter, by default, the TCP/IP settings should be set to obtain an IP address from a DHCP server (i.e. wireless router) automatically. To verify your IP address, please follow the steps below.

  • Page 71: Statically Assign An Ip Address

    Windows® 2000 - From the desktop, right-click on the My Network Places > Properties. Step 2 Right-click on the Local Area Connection which represents your D-Link network adapter and select Properties. Step 3 Highlight Internet Protocol (TCP/IP) and click on the Properties.

  • Page 72: Technical Specifications

    * Maximum wireless signal rate derived from IEEE Standard 802.11g specifications. Actual data throughput will vary. Network conditions and environmental factors, including volume of network traffic, building materials and construction, and network overhead, lower actual data throughput rate. Environmental factors will adversely affect wireless signal range. D-Link DSL-2640B User Manual...

  • Page 73: Contacting Technical Support

    Appendix D –Contacting Technical Support Contacting Technical Support You can find software updates and user documentation on the D-Link websites. If you require product support, we encourage you to browse our FAQ section on the Web Site before contacting the Support line.
