OWNER / OPERATOR MANUAL
WARNING
The engine exhaust from this product
contains chemicals known to the State
of California to cause cancer, birth
defects or other reproductive harm.
APPLICABLE SERIAL NUMBERS :
DRIVE UNIT 300001 and up
BRUSHCUTTERS
BCZ3000S
BCZ3000SW
BCZ3000S
ENGINE UNIT 300001 and up
BCZ3000SW
WARNING
Before using our brushcutters,
please read this manual carefully to
understand the proper use of your
unit.
848-JC0-93A0 (311)
