Page 1 BCZ3050S BCZ3050T BCZ3050SW Use as a trimmer only BCZ3050S/T/SW 848-JCS-93A0 (908) OWNER'S/OPERATOR'S MANUAL BRUSHCUTTERS BCZ3050S BCZ3050SW BCZ3050T WARNING The engine exhaust from this product contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm.
Page 2: Table Of Contents
BCZ3050S/T/SW SAFETY FIRST Instructions contained in warnings within this manual marked with a concern critical points which must be taken into consideration to prevent possible serious bodily injury, and for this reason you are requested to read all such instructions carefully and follow them without fail.
Page 3: Parts Location
BCZ3050SW ········································································· 72.5 (1843) x 25.6 (651) x 21.5 (546) in (mm) Dry weight BCZ3050S/BCZ3050T ······································ 12.1 lbs (5.49 kg) (12.94 lbs (5.87 kg) Including line head) BCZ3050SW ··················································· 12.76 lbs (5.79 kg) (13.60 lbs (6.17 kg) Including line head) Engine Type··················································································································...
Page 4: Warning Labels On The Machine
BCZ3050S/T/SW 3. Warning labels on the machine ( 1 ) ( 2 ) ( 3 ) (1) Read owner's manual before operating this machine. (2) Wear head, eye and ear protection. (3) Warning! Danger of kickback. (4) Beware of thrown objects.
Page 5: For Safe Operation
3. Wear the following protective equipments when operating the product. a: Approved helmet to reduce the risk of falling objects. BCZ3050S/T/SW b: Approved ear protection to reduce the risk of hearing loss. c: Approved (ANSI Z87.1.) eye protection and foot protection to reduce the risk of injury associated with thrown objects.
Page 6 RedMax servicing dealer for repair. ■ Using the product IMPORTANT Cut only materials recommended by the manufacturer.
Page 7 Comply with times listed in local ordinances. BCZ3050S/T/SW 2. To reduce sound levels, limit the number of pieces of equipment used at any one time. 3. Operate the product at the lowest possible throttle speed to do the job.
Page 8 4. When replacing the any other part, or any lubricant, always be sure to use only RedMax products or products which have been certified by RedMax for use with the RedMax product. 5. In the event that any part must be replaced...
Page 9: Set Up
■ INSTALLING HANDLE • Mount the handle to the shaft tube and clamp it at a location that is comfortable to you. (SE1) (1) About 19 inches (48cm) [BCZ3050S] (2) About 14.5 inches (37cm) [BCZ3050T] [BCZ3050SW] ■ HIP PAD • Fix the tube by the band. (SE2) (1) Band ■...
Page 10: Fuel
• Poor quality gasolines or oils may damage sealing rings, fuel US-10 lines or fuel tank of the engine. • Failures caused by operating engines on gasoline with octane rating lower than 89 are not covered by the RedMax Two- Stroke engine warranty. WARNING • Alternative Fuels (Not Gasoline)
Page 11 Do not mix more gasoline/oil than you intend to use in 30 days, and 60 days when fuel stabilizer is added. RedMax Air-Cooled "Max Life" Synthetic blend Premium two-stroke engine oil "Contains fuel stabilizer" and will automatically extend your gasoline/oil mixture life up to 60 days.
Page 12: Operation
BCZ3050S/T/SW 8. Operation ■ STARTING ENGINE WARNING The cutting head will start rotating upon the engine starts. 1. Rest the unit on a flat, firm place. Keep the cutting head off the ground and clear of surrounding objects as it will start rotating upon starting of the engine.
Page 13 • Each time the head is bumped, the line advance about 1 inch(25.4 mm). For better effect, tap the head on bear ground or hard soil. Avoid bumping in thick, tall grass as the engine may stall by overload. BCZ3050S/T/SW US-13...
Page 14: Maintenance
.095 or 18 feet of .105 inch monofilament line. RedMax recommends Cable Twist™ line for best performance for commercial use. RedMax Cable Twist™ line is available from your local RedMax Dealer. Taking the Head Apart (MA1-b) 1. Press in one side locking tab that...
Page 15 Clean the spark plug and check that the plug gap is in the correct range. For a replacement plug, use the correct type specified by RedMax. (MA4) • REPLACEMENT PLUG IS A NGK .038 in 1.00mm CMR7H-10.
Page 16: Storage
BCZ3050S/T/SW 9. Maintenance ■ MUFFLER WARNING • Inspect periodically, the muffler for loose fasteners, any damage or corrosion. If any sign of exhaust leakage is found, stop using the machine and have it repaired immediately. • Note that failing to do so may result in the engine catching on fire.
Page 17: Optional Blade Usage
12. Optional blade usage (for BCZ3050S/SW only) WARNING [ BCZ3050T ] This trimmer is designed for use as a trimmer only. Metal blades should never be used on this trimmer. OPT1 IMPORTANT Change to the cutting attachment guard which is suitable for the metal blade.
Page 18 BCZ3050S/T/SW 12. Optional blade usage (for BCZ3050S/SW only) ■ STARTING THE ENGINE Please refer 5.For safe operation (P.6), 8.Operation (P.12). WARNING • The product is equipped with a centrifugal clutch mechanism, so the cutting attachment could rotate as soon as the engine is started.
Page 19 12. Optional blade usage (for BCZ3050S/SW only) d. Keep the blade sharp. A dull blade increase the chance of blade thrust. e. Avoid feeding the blade too rapidly. The blade can bounce away from material being cut if the blade is fed faster than its cutting capability.
Page 20: Troubleshooting Guide
BCZ3050S/T/SW 13. Troubleshooting guide Case 1. Starting failure CHECK fuel tank fuel filter carburetor adjustment screw sparking (no spark) spark plug Case 2. Engine starts but does not keep running/Hard re-starting. CHECK fuel tank carburetor adjustment screw muffler,cylinder (exhaust port)
Page 21 If the part fails prior to the first scheduled replacement, the part will be repaired or replaced by RedMax at no cost. Any such part repaired or replaced under warranty is warranted for the remainder of the period prior to the first scheduled replacement point for the part.
Page 22 RedMax Limited Warranty, provides to the ORIGINAL retail purchaser that this RedMax product is free from DEFECTS in MATERIAL and WORKMANSHIP under normal use and maintenance from the date of retail purchase. RedMax agrees to repair or replace at our discretion, any defective product, free of charge at any authorized RedMax servicing dealer using original RedMax replacement parts, within the listed below application time periods, limitations and exclusions.
Page 23 Should a product difficulty occur within the applicable warranty period, you must, at your expense, deliver or ship your RedMax unit to an authorized RedMax Servicing Dealer only for warranty repairs and arrange for pick-up or return of your unit after the repairs have been made.

This manual is also suitable for:

Bcz3050sw Bcz3050t Bcz2450s Bcz2450t Bcz2650s Bcz2650t ... Show all
