- Page 1 3 - A x i s G i m b a l R i g f o r i P h o n e iPhone 7 Plus / 7 / 6s Plus / 6s / 6 Plus / 6 iPhone SE / 5s / 5c / 5 GuiLin FeiYu Technology Incorporated Company...
-
Page 2: Product Overview
1. Product Overview * The showing smartphone is only for reference 1/4 inch 1/4 inch 1/4 inch screw hole screw hole screw hole Panning Panning 360° 360° Tilting axis Rolling axis 1/4 inch screw hole 1/4 inch screw hole Panning axis Indicator USB port... -
Page 3: Install The Battery
2. User Guide (1) Please install the iPhone before powering on the gimbal Attention ! (2) Please turn off the power when the gimbal is not in use, then remove the iPhone Install the iPhone Install the battery Attach the iPhone by the quick-release adapter, and ensure it is secure. Remove the handle and insert one 22650 battery into it. -
Page 4: Working Modes
3. Modes / Functions Working Modes Panning Mode The phone can move to left or right smoothly along with the handheld moving. The tilting and rolling directions fixed. * Boot default mode: Panning mode Panning and Tilting Mode The phone can move to left or right and tilt up and down smoothly along with the handheld moving. The rolling directions fixed. - Page 5 When the initialization failed, the LED indicator will flash quickly, repeat step (2) to reinitialize. 6. Parameters Pa cka ge List Titling Angle 320° Product model Quantity Rolling Angle 100° SPG Plus Batteries (Type:22650) Panning Angle 360° Titling Increments 2°/s ~ 75°/s USB cable Panning Increments 3°/s ~ 150°/s...
