- Page 1 3-Axis Gimbal for Sony Camera Guilin Feiyu Technology Incorporated Company User Manual V 1.1...
-
Page 2: Product Overview
1. Product Overview Tilt axis Cross arm Roll axis Adapter(Clamping plate) Vertical arm Camera thumb screw Pan axis Status indicator Retaining ring Joystick Function button Trigger button Self-timer shortcuts Micro USB port Single hand grip 1/4-20 Thread Mount... - Page 3 Included items Dual-hand grip accessories 1/4-20 22650 Li-ion Cold shoe mount Micro USB cable 1/4 thumb screw Inch screw battery Hand grip installation Single hand grip Retaining ring Dual-hand grip foldable set (Optional) Make sure to tighten the retaining ring until fully locked! Retaining ring...
-
Page 4: Insert Battery
2. User Guide Install the Sony camera Insert battery Remove the hand grip and insert the Tips：you need to install the waterproof shell before you can perform the following steps provided 22650 battery. Place the camera correctly on the clamping plate and attach the tilt axis ,use the camera thumb screw to secure the camera through the middle chute atthe bottom of clamping plate. - Page 5 Gimbal charging * Please fully charge the battery before powering on the gimbal for the first time. Option 1: charging with micro USB cable. Micro USB cable 5V/1A USB charger (not included) Option 2: remove the battery and charge in external charger (not included).
-
Page 6: Balance The Gimbal
Balance the gimbal How to balance gimbal If the camera is tilted to the left, then loose camera thumb screw, move the camera to the right,try Best balance to adjust to the best balance,and then tighten the camera thumb screw . If the camera is tilted to the right, then loose camera thumb screw, move the camera to the left,try to... -
Page 7: Power On/Power Off
Power on / off Power on： press and hold the function button until the status indicator turns green and gimbal beeps. Power off： press and hold the function button until the status indicator changes from a flashing red to a solid red light and gimbal beeps. - Page 8 Explanation of indicator status The current mode of the gimbal can be identified Explanation of joystick control by the indicator status. Status indicator Indicator status Mode / Status Blue light flashes once Pan mode Right Blue light flashes twice Follow mode Function button Left...
- Page 9 Motion Control Mode Manual Lock The G5 GS gimbal can easily create constant speed moves Camera can be manually positioned while lock mode , by using the motion control mode. This mode can be used follow mode or pan mode. both the pan and tilt can be for recording both regular video and timelapse photography.
- Page 10 3.Set rotation start position 2.Enter motion control mode by clicking the function button 4 times Record the first position (rotation start position) by manually moving camera to desired position. Hold in position for half a second. Click the function button to record rotation start position. Tilting Panning 4.Set rotation end position...
-
Page 11: Connecting App
(2) Android version: Feiyu ON Feiyu ON Feiyu ON Feiyu ON Download App Store GuiLin FeiYu Technology Incorporated Company Download GuiLin FeiYu Technology Incorporated Company Google play * Scan QR codes to automatically link to App Connecting App download pages. -
Page 12: Firmware Upgrade
5. Firmware Upgrade Option 1: connect the gimbal with PC via micro USB cable. Please visit the G5 GS product page on official website (www.feiyu-tech.com) to download the relevant programs for upgrading firmware, including: USB driver, firmware upgrade software, and product firmware. -
Page 13: Gimbal Initialization
6. Gimbal Initialization You can initialize your gimbal when: （1）Camera fails to remain level. （2）Gimbal has no been used for a long period of time. （3）Gimbal is used in extreme temperature Place the gimbal on a flat, horizontal surface. The variations. -
Page 14: Technical Specifications
7. Technical Specifications 116.3 68.8 (Unit:mm) Max. Tilting Range No limit Max. Rolling Range +/- 160° Max. Panning Range No limit Tilting speed Min: 2°/s - Max: 75°/s Panning speed Min: 3°/s - Max: 150°/s Operation time 7 Hours Adaption camera and AS50 sony camera and 130 ~ 200g sony camera mobile camera width range Weight... - Page 15 D I S C L A I M E R Any user for illegal purpose prohibited. Users are responsible for use products. The company assumes no liability for any risks related to or resulting from the debug and use of this product (including direct, indirect or third-party losses).
- Page 16 Guilin Feiyu Technology Incorporated Company Due to software and hardware improvements, your actual product might differ from the descriptions and pictures in this user manual. You can get the latest user manual from the official website. For more information, please visit our official website...
