Summary of Contents for Guilin Feiyu Technology FY WG2 3 Axis
- Page 1 I n st r u c t i o n M a n u a l V 1 . 0 FY WG2 3 Axis Wearable Gimbal Compatible with Gopro Hero5 / Gopro Hero4 and cameras with similar dimensions GuiLin FeiYu Technology Incorporated Company...
- Page 2 User Guide Attention! (1) Please install the camera before powering on the gimbal. (2) When not in use, turn off the gimbal and then remove the camera. Install the Camera Install the camera on retainer plate, then fix the camera with retainer bar and screw. Hero5 Reference point Hero4...
- Page 3 Power on / off Attention: Make sure the camera is secure before powering on the Gimbal. Power On: Press and hold function button until the green light is on. Power Off: Press and hold function button until the red light changes from quick flashing to always on.
- Page 4 Charging Please make sure the battery is fully charged before you use the gimbal for the first time. Charge with micro USB cable. micro USB （equipped by user）...
-
Page 5: Product Overview
Product Overview * The showing sports camera is only for reference Long screw Waterproof Tilting axis Rolling axis Bluetooth Function Button Panning axis USB port T-Clamp Screw Hole 1/4 inch Indicator Status screw hole T-Clamp Screw Hole 1/4 inch screw hole... - Page 6 61.1～78.1mm 89.3mm 40mm...
- Page 7 Vertical Forward Inverted Camera in left Camera in left Camera in left Camera in right Camera in right Camera in right...
- Page 8 (2) Android version: (1) iOS version: Google play Feiyu ON Feiyu ON Download GuiLin FeiYu Technology Incorporated Company App Store Connect to APP Start the app on your smartphone, follow the instructions to connect the smartphone with gimbal via Bluetooth. Gimbals...
-
Page 9: Mode /Function
Mode /Function Indicator Status Mode / Status Panning Mode Lock Mode Blue light flashes once Panning Tilting and rolling direction are fixed, and the camera The orientation of the camera is fixed. Blue light flashes twice Panning and tilting mode lens moves according to the hand movement of the user. -
Page 10: Firmware Upgrade
Firmware Upgrade Option 1: connect the gimbal with PC via micro USB cable, and then upgrade the firmware. Please visit the official website www.feiyu-tech.com to download the relevant programs for upgrading, including USB driver, firmware upgrade software and product firmware, and install the relevant software, decompress the firmware files for standby application. -
Page 11: Gimbal Initialization
Gimbal initialization (1) Stands on table You can initialize your gimbal: (2) Triple tap （1） when camera is not level （2） if not used for a long period of time （3） in case of extreme temperature variations Blue light is on Adjusting steps: (1) Stands on table Blue light flash... - Page 12 Parameters Titling Angle 360° Rolling Angle 50° Panning Angle 360° min 2°/s max 75°/s Titling Increments Panning Increments min 3°/s max 150°/s Weight g（Not including camera ） Usage time 2.5 Hours Adaption Weight 115 g...
- Page 13 D I S C L A I M E R Prohibit any user for any illegal purpose. Users will be responsible for all behaviors of purchase and use products. The Company assumes no liability for any risks related to or resulting from the debug and use of this product (including the direct, indirect or third-party losses).
- Page 14 For more information, please visit our official website: www.feiyu-tech.com Support Email: service@feiyu-tech.com Due to software and hardware improvements, your actual product might differ from the descriptions and pictures in this user manual. You can get the latest user manual www.feiyu-tech.com from the official website.
