Summary of Contents for Guilin Feiyu Technology VIMBLE C
- Page 1 Instruction Manual V 1 . 0 3-Axis Stabilized Handheld Gimbal For SmartPhone GuiLin FeiYu Technolog y Incorporated Company...
- Page 2 User Guide Attention ! (1) Please install the smartphone before powering on the gimbal! (2) When not in use, turn off the gimbal and then remove the smartphone. Installing the phone Power on / off In case of low battery, the indicator will Attention: Turn the gimbal on after the phone has Tips: Please take off...
-
Page 3: Product Overview
Product Overview * The smartphone shown in the picture Please refer to“Explanation of is only for reference LED indicator modes” Joystick Tilting Left Rolling axis Right axis Down Panning LED indicator axis Joystick Toggle switch USB port Bluetooth shutter Handle (Built-in battery) For toggle switch operation, 1/4 inch screw hole... -
Page 4: Balance Adjustment
Balance Adjustment How to balance adjustment Knob ring If the iPhone tilted to the right,then loose the knob ring, move the cross arm to the left, try to adjust to the best balance then tight it. Cross arm Knob ring If the iPhone tilted to the left,then loose the knob ring, move the cross... - Page 5 Feiyu ON Feiyu ON Feiyu ON Feiyu ON Download Download GuiLin FeiYu Technology Incorporated Company GuiLin FeiYu Technology Incorporated Company App Store Google play Connecting APP Start the app on your smartphone,follow the instructions to connect the smartphone with gimbal via Bluetooth.
- Page 6 Modes / Functions Vertical Shooting Mode Vertical Shooting Working Modes Reset ≤30° Panning Mode Tilting and rolling direction are fixed, ≤30° and the camera lens moves according to the hand movementof the user. Press the toggle switch on the back Panning and Tilting Mode one time Press the toggle switch...
- Page 7 Explanation of LED indicator modes Note: The two RGB indicators have thesame status Gimbal operating mode and LED indicator: RGB three-color lights Mode / Status Blue light flashes once Panning Blue light flashes twice Panning and tilting mode Blue light flashes three times Standby Blue light on steadily Lock mode / Initializing Initialization failure /...
-
Page 8: Firmware Upgrade
Firmware Upgrade Option 1: connect the gimbal with PC via micro USB cable, and then upgrade the firmware. Please visit the official website www.feiyu-tech.com to download the relevant programs for upgrading, including USB driver, firmware upgrade software and product firmware, and install the relevant software, decompress the firmware files for standby application. -
Page 9: Gimbal Initialization
Gimbal initialization You can initialize your gimbal : （1） when camera is not level （2） if not used for a long period of time （3） in case of extreme temperature variations Adjusting steps: Stands on table Blue light flashes quickly for three times Press the Red light... - Page 10 Parameters Titling Angle 320° Titling Increments min 2°/s max 75°/s Rolling Angle 320° Panning Increments min 3°/s max 150°/s Panning Angle 320° Usage time 5 Hours Adaption iPhone series / HUAWEI P9 / HUAWEI P9 Plus / Mi 5 / MEIZU MX6 / SAMSUNG NOTE 5 / S7 or other smartphones with the similar dimensions Weight 420g （...
- Page 11 D I S C L A I M E R Prohibit any user for any illegal purpose. Users will be responsible for all behaviors of purchase and use products. The Company assumes no liability for any risks related to or resulting from the debug and use of this product (including the direct, indirect or third-party losses).
- Page 12 C r e a t e M o r e P o s s i b i l i t i e s For more information, please visit our official website www.feiyu-tech.com Support Email: service@feiyu-tech.com www.feiyu-tech.com...
