Turning ON/OFF Remote Camera Using AW-RP50
★ By using AW-RP50 controller, you can switch the remote camera's power supply from STANDBY mode (Power OFF)
to POWER ON mode (Power ON), and vice versa.
* Before you use AW-RP50 controller to control the remote camera's power supply, you need to set up the connection
with the camera in advance.
For the connection setting-up procedure, please refer to the following Manual 【Controlling AW-HE40 Camera via
AW-RP50 Controller】.
https://eww.pass.panasonic.co.jp/pro-av/support/content/faq/EN/remcam/1_.pdf
<Note>
・ Be careful with the Power ON/OFF operation described in this Manual because it can affect the camera's pan-tilt
head position at the time of turning the power on. (POWER ON Preset Function)
For details, please refer to the following Manual 【Booting Up with Pan-Tilt Head in Specified Position】.
https://eww.pass.panasonic.co.jp/pro-av/support/content/faq/EN/remcam/7_.pdf
■ Turning ON/OFF Remote Cameras One by One
* For switching the power supply mode of the remote camera (AW-HE40) which is assigned to [CAM1];
1.Keep holding down LED button 1 at CAMERA STATUS/SELECTION area – (Fig.1-A). The selected camera's name
will be displayed on the upper half, and its power status (POWER ON/POWER OFF) on the lower half of the LCD
panel – (Fig.2).
2.While the LED button 1 is held down at CAMERA STATUS/SELECTION area, turn F2 dial – (Fig.1-B);
(If you turn ON the camera,)
Select "ON" – (Fig.2), and then press the F2 dial. The camera will switch over to POWER ON mode (Power ON).
(If you turn OFF the camera,)
Select "OFF" – (Fig.2), and then press the F2 dial. The camera will switch over to STANDBY mode (Power OFF).
(Figure 1: AW-RP50 Control Panel)
(A)
Controller
(Figure 2: AW-RP50 LCD Panel)
(B)
Hold down Button 1
CAM[1] <AW-HE40>
POWER:OFF↓
Turn F2
(Turning ON)
CAM[1] <AW-HE40>
POWER:ON↓
Press F2 to determine
(Turning OFF)
CAM[1] <AW-HE40>
POWER:OFF↓
Press F2 to determine
