KDK P30KH Service Manual
Living fan
Hide thumbs
Also See for P30KH:
- Operating instructions manual (12 pages) ,
- Operating instructions manual (6 pages)
Related Manuals for KDK P30KH
Summary of Contents for KDK P30KH
- Page 1 Order Number: MEL0609026C3 Living Fan P30KH SPECIFICATION MODEL AC220 / 230V 50Hz WATTAGE AIR VELOCITY AIR DELIVERY High High m/min /min P30KH 19-26 37-40 835-875 1100-1135 200-209 50-55...
-
Page 2: Exploded View
EXPLODED VIEW... -
Page 3: Replacement Parts List
REPLACEMENT PARTS LIST REF. SAFETY PART NO. PART NAME REMARKS PARTS FFE09030402M GUARD MARK ASS'Y K058M FFE090101AVP FRONT GUARD M0113 FFE0802950EM SPINNER N0999 FFE08010200M BLADE N0214 FFE0931020IM GUARD RING ASS'Y N0428 FFE09099001M GUARD SET NUT BZ054 FFE090203ASM REAR GUARD M0113 FFE0204040IM FRONT OUTER COVER N0428... -
Page 4: Wiring Diagram
When you push, it will switch to ON or OFF After connecting the socket, the initial operation will be notch 1. Other button will not operate before OFF-ON is pushed. ELECTRIC FAN P30KH WIRING DIAGRAM CONDENSOR SCREW LIST REF. NO. PART NUMBER... - Page 5 1/f Yuragi – What is it? Speed 1/f Yuragi – Why does it make us comfort? Brings comfort Inspiring and Relaxing, regenerating, and relief calming stabilizing your body and mind 1/f Yuragi – What actually it is? Big wave Degree 1/f (45°) Small wave Graph 1 : Basic wave profi l e Frequency (1 / per day)
- Page 6 1/f Yuragi – Technology comparison Current function Rhythm Breeze Speed notch toggles by 4 secs regularly Air Speed Notch 3 Notch 2 With rhythm breeze function turned Notch 1 4 seconds interval Time (s) Air Speed New function 1/f Yuragi Speed notch toggles to make Yuragi pattern...
