Thank you for purchasing KDK Ceiling Fan
感謝您購買 KDK 吊扇
Before operating this product, please read the instructions carefully, and keep this manual
for future reference.
操作本產品前，請仔細讀本說明書，並保存本說明書以作日後參考。
Contents / 目錄
M48SG_EN_CT.indd 1
M48SG_EN_CT.indd 1
Operating And Installation Instructions
操作和安裝指示

Ceiling Fan

吊扇
Model Number
Page / 頁數
型號
2
5
5
16
16
16
1/5/2011 8:07:45 PM
1/5/2011 8:07:45 PM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M48SG and is the answer not in the manual?

Questions and answers

Related Manuals for KDK M48SG

Summary of Contents for KDK M48SG

  • Page 1: Table Of Contents

    Ceiling Fan 吊扇 Model Number 型號 M48SG M60SG Thank you for purchasing KDK Ceiling Fan 感謝您購買 KDK 吊扇 Before operating this product, please read the instructions carefully, and keep this manual for future reference. 操作本產品前，請仔細讀本說明書，並保存本說明書以作日後參考。 Contents / 目錄 Page / 頁數...

  • Page 2: Safety Precautions / 安全注意事項

    Safety Precautions / 安全注意事項 To avoid the possibility of causing injury to users or damage to properties, please follow all the explanations written below. 為避免導致用戶受傷或財物損壞的可能性，請遵守以下所述的所有指示。 A state that may be caused by the mishandling of products, which, if not avoided, may lead to the WARNING possibility of death or serious injury of users.
  • Page 3 WARNING / 警告 Switch off power supply and wait until Do not dismantle the Ceiling Fan unless Avoid damage wire during installation the Blade is fully static, before cleaning stated by this manual. eg. Deform due to heat, twist, bend, or doing any maintenance jobs.
  • Page 4 CAUTION / 注意 Ceiling Fan must be mounted above Avoid continuous exposure of direct wind Do not install at places where there is 2.5m from the fl oor and 1m from the from the Ceiling Fan. high vibration and impact. 避免長時間讓吊扇直接吹著您。...

  • Page 5: Supplied Parts / 配備零件

    Supplied Parts / 配備零件 Pcs / 零件 Parts / Hexa Nut / 件 六角形螺帽 發動機組件 1. Motor Assembly / Spring Washer / 彈簧墊圈 Carl Bolt Plug / 扇翼組件 2. Blade Assembly Set / 卡爾螺栓塞子 P-R Washer / P-R 墊圈 導管 3.
  • Page 6 Insert the Upper Canopy to the Pipe. 將上罩蓋嵌入導管。 Do not screw the Upper Canopy Screw / 切勿鎖緊上罩蓋螺絲 Upper Canopy / 上罩蓋 Pipe / 導管 Check Point After Installation / 安裝後的重點檢查 Check / 檢查 1. Insert the Upper Canopy to Pipe Assembly and the screw is not tightened. / 將上罩蓋嵌入導管組件，並且螺絲沒 被鎖緊。...
  • Page 7 NOTE: Do not remove this Switch Lever. 注意：切勿拆除此開關杆。 Pipe / Pipe hole and Motor Shaft hole are aligned. 導管 導管孔和發動機轉動軸孔是較直的。 Cap / 蓋子 Switch is pushed by Switch Lever. Motor Shaft / 開關被開關杆推壓。 發動機轉動軸 CAUTION / 注意 Do not remove the Switch Lever at Pipe. Insert Pipe correctly to Motor Shaft.
  • Page 8 WARNING / 警告 Ensure Pipe has been fully tightened to Motor Shaft. (Bolt tightening torque is 800~1200N•cm). And, Cotter Pin must be fi xed into Bolt hole and bent. Can cause injury if Ceiling Fan drops. 確定將導管鎖緊至發動機轉動軸。(螺栓扭緊轉距是 800~1200N•cm)。 而且，開口銷必須插入螺栓孔然後折彎。 若吊扇掉落會導致受傷。 Remove Safety Wire Screw at Motor Shaft.
  • Page 9 Check Point After Installation / 安裝後的重點檢查 Check / 檢查 4. All wires are connected correctly by qualifi ed personnel. / 所有電線必須由合格人員正確地連接。 Live (Brown) / 火線 (棕色) Neutral (Blue) / 零線（藍色) Earth (Green/Yellow) / 地線（綠色/黃色) Assemble Blade Assembly Set To Motor Assembly / 組裝扇翼組件至 發動機組件...
  • Page 10 Drill hole. INSTRUCTION A / 指示 指示 A INSTRUCTION B / 指示 指示 B 鑽孔。 Make holes on the concrete ceiling. Drill Make holes on the concrete ceiling. Drill CAUTION / 注意 ø 6.5 mm (depth 30 mm) for Carl Bolt ø...
  • Page 11 Install to Ceiling. 安裝至天花板。 Pulley / 滑輪 Pulley / 滑輪 Ceiling Hook (“J” Hook) / C Hock / 天花板鉤子 鉤子 C （“J＂型鉤子） 1st step / 步驟一 2nd step / 步驟二 Take out Pulley Set from Parts Set, after that Place Pulley onto Ceiling Hook. 將滑輪放在天花板鉤子上。...

  • Page 12: Wiring Diagram

    Check Point After Assemble / 組裝後的檢驗點 Check / 檢查 1. The Ceiling Fan is securely fi xed onto the hanging hook. / 吊扇被穩固地安裝到吊鉤上。 2. The Safety Wire is securely fi xed onto ceiling. / 保險線已穩定地安裝在天花板上。 Wiring Instruction / 配線指示 Connect power supply according to the Wiring Instruction below. 按照以下的配線指示接電源。...
  • Page 13 Fix the Canopy / 安裝罩蓋 Adjust Upper Canopy position and fi x Upper Canopy Ceiling / 天花板 to Pipe fi rmly by screwing them as shown. The distance of Upper Canopy and Ceiling is Approximately 5mm / approximately 5mm. 大約 5毫米 調整上罩蓋的位置，然後如圖所示將上罩蓋旋緊至導管。...
  • Page 14 Loosen the screw from the Speed Regulator Cover. Open the Speed Regulator by lifting up the Speed Regulator Cover from the base. 鬆開調速器蓋子上的螺絲。從底部提起調速器蓋子以打開調速器。 Regulator Cover/ 調節器蓋子 Screw / 螺絲 Speed Regulator Base / 調速器基地 Terminal 1 / 端子 1 Terminal 2 / 端子 2 Insert the Power Cord (from the power supply) and the Lead Wire (from Motor Assembly) through the hole of the Speed Regulator Base as shown.
  • Page 15 Connect the power cord and lead wire with the Terminal 1 and Terminal 2 as shown. 如圖所示將電纜與電線連接至端子1及端子2。 Power Cord (from power supply) 電纜（自電源） Lead Wire (from Motor Assembly) / 電線（自發動機組件） WARNING / 警告 The Speed Regulator will be damaged if both these lead wires are connected directly to the power supply.

  • Page 16: How To Use / 如何使用

    Air Delivery 電壓 頻率 瓦特數 (W) 旋轉度（RPM） Model Type Air Velocity (m/min) (m³/min) 模型 類型 風速 (米/分鐘) 送風量 (立方米/分鐘) High High 伏特直流 赫茲 低 高 低 高 M48SG M60SG M48SG8001ZM M48SG_EN_CT.indd 16 M48SG_EN_CT.indd 16 1/5/2011 8:07:50 PM 1/5/2011 8:07:50 PM...
