Arrow COMMANDER SERIES Owner's Manual And Assembly Manual page 6

1:
Step
Remove Parts:
• Roof Trim Cap (2)
• Roof Trim (2)
• Peak Cap (1)
1
Remove the rear Roof Trim Caps and Roof Trim
from both sides of building.
2
Remove Peak Cap and four (4) Bolts and Nuts from
rear Ridge Cap.
3
Remove the last full-size Roof Panel and End Roof
Panel from both sides of building.
4
Remove the rear Ridge Cap by removing two (2)
Bolts and Nuts towards middle of building.
1
Remove Roof Trim
Disassemble Rear Wall
• Roof Panel (2)
• End Roof Panel (2)
• Ridge Cap (1)
2
3
2
IMPORTANT: Take care in
removing parts from building.
They will be reused later.
4
don't focus weight
Remove four (4) Bolts
at end of Ridge Cap.
6
1
on roof
4
Remove last
two (2) bolts.
