Specifications - Extech Instruments CG304 User Manual

Specifications

Measurement principle
Measuring range
1
Accuracy
(% of reading)
Resolution
Min. curvature radius
Diameter of Min. area
Basic critical thickness
Industrial standards
Operating Temperature
Operating Relative
Humidity (R.H.)
Power
Dimensions
Weight
1 Accuracy note: Accuracy statement applies to use on a flat surface, with a zero calibration
performed and with the meter stabilized at ambient temperature. The accuracy of the reference
films or any reference standards should be added to measurement results.
All rights reserved including the right of reproduction in whole or in part in any form
Ferrous
Magnetic induction
0~2000μm
0~78.7mils
0~1000μm: ±(2% + 2μm)
1000μm ~2000μm: (±3.5%)
0~39.3mils: ±(2% + 0.08mils)
39.3mils ~78.7mils: (±3.5%)
0~100μm: (0.1μm)
100μm ~1000μm: (1μm)
1000μm ~2000μm: (0.01mm)
0~10mils: (0.01mils)
10mils~78.7mils: (0.1mils)
59.06mils (1.5mm)
275.6mils (7mm)
19.69mils (0.5mm)
Conforms to GB/T 4956-1985, GB/T 4957-1985, JB/T 8393-1996, JJG
889-95, and JJG 818-93
0°C~40°C (32°F~104°F)
20%~90% Relative Humidity
2 x AAA batteries with Auto Power OFF after 3 minutes
120 x 62 x 32 mm (4.7 x 2.4 x 1.25")
175g (6.17 oz.)
Copyright © 2015-2017 FLIR Systems, Inc.
www.extech.com
Non-Ferrous
Eddy current principle
0~2000μm
0~78.7mils
0~1000μm: ±(2% + 2μm)
1000μm ~2000μm: (±3.5%)
0~39.3mils: ±(2% + 0.08mils)
39.3mils ~78.7mils: (±3.5%)
0~100μm: (0.1μm)
100μm ~1000μm: (1μm)
1000μm ~2000μm: (0.01mm)
0~10mils: (0.01mils)
10mils~78.7mils: (0.1mils)
118.1mils (3mm)
196.9mils (5mm)
11.81mils (0.3mm)
ISO-9001 Certified
13 CG304-en-GB_v2.3 5/17
