AMPLIFIER SECTION

Short term amplifier output power
(Long term output power is limited by driver unit protection circuitry)
Amplifier system THD at nominal output
Mains voltage
Power consumption
Standby, ISS active
Idle
Full output, peak
SIGNAL PROCESSING SECTION
Signal connectors
Analog signal input connector XLR female, balanced 10 kOhm
Maximum analog input signal
Analog input sensitivity (100 dB SPL at 1 m)
Adjustment range (LEVEL dip switches + rotary level control)
Digital signal input connector XLR female 110 Ohm
Digital signal output / Thru connector XLR male 110 Ohm
Digital audio input
Word length
Sample rate
Digital input sensitivity (100 dB SPL at 1 m)
Digital input maximum attenuation
Positive input gain selection (GLM control)
Control network
Type
Connection
GLM software frequency response adjustment parametric notch filters
TM
System calibration
Crossover setting in subwoofer's input/output channels
Centralized Bass Management (for analog signal)
Distributed Bass Management (GLM control)
LFE cutoff
Midband rejection >400 Hz
Bass Roll-Off control operating range in 4 dB steps
Phase matching control
Genelec Document D0148R001. Copyright Genelec Oy 5.2017. All data subject to change without prior notice
International enquiries:
In the U.S. please contact:
Genelec, Olvitie 5
Genelec, Inc., 7 Tech Circle
FIN-74100, Iisalmi, Finland
Natick, MA 01760, USA
Phone +358 17 83881
Phone +1 508 652 0900
Fax +358 17 812 267
Fax +1 508 652 0909
Email genelec@genelec.com
Email genelec.usa@genelec.com
800 W
<0.01%
100-240 VAC 50/60 Hz
<2 W
40 W
600 W
7.1 channel analog IN/OUT
Analog Link IN/OUT
Digital AES/EBU IN/OUT
pin 1 gnd, pin 2 non-inverting, pin 3 inverting
+24.0 dBu
-6 dBu
+48 dBu to -6 dBu
AES/EBU Single Wire
AES/EBU Single Wire
16 - 24 bits
32 - 192 kHz
-30 dBFS
48 dB
+6, +12, +18 dB
Proprietary GLM network
2 RJ45, CAT5 cables
20
Genelec GLM AutoCal™, GLM manual, Stand-alone
Input low pass fixed 85 Hz, output high pass fixed 85 Hz
Input low pass selectable 50 to 100 Hz, output no filtering
120 Hz
≥ 50 dB
0 to -12 dB at 20 Hz
90° steps with dip switch controls
15° steps with GLM control
