OHAUS Scout SPX Quick Start Manual

Quick Start Guide
UNPACKING
Carefully remove your Scout balance and each of its components from the
package. Store the packaging material to ensure safe storage and future transport.
Included Components:

Balance

Quick Start Guide

Warranty Card
SELECTING THE LOCATION
Place on a firm, steady surface with sufficient space. Avoid excessive air current,
vibrations, heat sources, or rapid temperature changes.
PREPARATION FOR USE
Step-1 Release the red Transportation
Lock on subplatform of the
balance
Turn the pointer 90 counter-
clockwise.
Step-2 Install the Pan
Rectangular pan: Place diagonally
on sub-platform and rotate
counter-clockwise until it locks.
Round pan: Set straight down on
subplatform.
Step-3 Connect Power
Connect the AC Adapter to the
balance input jack.
Battery Installation
Install the Four "AA" (LR6)
batteries (not included) with
polarity as shown in the battery
compartment.
Step-4 Level the balance
Level the balance before using by
adjusting the feet until level
bubble is center
Ohaus Corporation www.ohaus.com

Pan

Calibration Mass (only for models up to 620g
capacity)

AC Adapter & Plug
i

Scout SPX Balances
Subplatform Transportation
Lock Pointer
Unlocked
Position
AC Adapter Jack
Scout
Locked
Position
Battery
Compartment

SPX Balances
