Quick Start Guide
Carefully remove your Scout balance and each of its components from the package.
Store the packaging material to ensure safe storage and future transport.
Included Components:
Balance
Quick Start Guide
Warranty Card
AC Adapter & Plug
Place on a firm, steady surface with sufficient space. Avoid excessive air current,
vibrations, heat sources, or rapid temperature changes.
Turn the pointer 90 counter-
clockwise.
Rectangular pan: Place diagonally
on sub-platform and rotate counter-
clockwise until it locks.
Round pan: Set straight down on
subplatform.
Connect the AC Adapter to the
balance input jack.
Battery Installation
Install the Four
(not included) with polarity as shown
in the battery compartment.
When operating on batteries, long
press the power button for up to 10
seconds to power on.
Ohaus Corporation www.ohaus.com
Pan
Stacking & Storage Cover (not applicable for 1mg models)
Calibration Mass (only for models up to 620g capacity)
(LR6) batteries
i
Scout STX Balances
Subplatform
Transportation
Lock Pointer
Unlocked
Position
AC Adapter Jack
Compartment
Scout STX Balances
Locked
Position
Battery
