® SCOUT SERIES BALANCES - STX EN-3 1. INTRODUCTION 1.1 Description The Scout STX balance is a high quality weighing instrument that will provide you with years of service if properly cared for. Models are available with ranges from 120g to 8200g. 1.2 Definition of Signal Warnings and Symbols Safety notes are marked with signal words and warning symbols.
® EN-4 SCOUT SERIES BALANCES - STX 1.4 Features Touch Controls: Quick, graphical access to all control functions, applications and features. INSTALLATION 2.1 Installing Components Refer to the illustrations and instructions below to identify and assemble your Scout balance with its components. All components must be assembled before using the balance. 2.1.1 Releasing the Transportation Lock Release the red transportation lock on the sub- Sub-platform...
® SCOUT SERIES BALANCES - STX EN-5 2.3 Leveling the Balance The Scout has an illuminated level indicator as a reminder that the balance should be leveled for accurate weighing. There is a level bubble in a small round window on the front of the balance. To level the balance, adjust the feet at each corner until the bubble is centered in the circle.
® EN-6 SCOUT SERIES BALANCES - STX 3. OPERATION 3.1 Controls Button Functions Table 3-1. Button Primary Function Tare (Short Press Turns the balance on Enter/clear a tare value. Zero If balance is On, sets Zero Secondary Function (Long Press Turns the balance Off.
® SCOUT SERIES BALANCES - STX EN-7 Principal Functions and Main Menu Weighing: Press Zero to set the display to zero. Place an item on the pan. Display indicates gross weight. Taring: With no load on the pan, press Tare to set the display to zero. Place an empty container on the pan and press Tare.
® EN-8 SCOUT SERIES BALANCES - STX The Scout Balance incorporates the following Applications. Weighing Parts Percent Dynamic Density Check Counting Weighing (Animal) Determination Weighing Weighing Display Totalization Mole Hold Note: Before using any application, be sure the balance has been leveled and calibrated. 4.1 Weighing Use this application to determine the weight of items in the selected unit of measure.
If this happens, unplug the USB flash drive and try another USB flash drive. Ohaus takes no responsibility if data on USB flash drive is erased or if the USB flash drive breaks while it is connected to the balance.
® EN-10 SCOUT SERIES BALANCES - STX The PARTS COUNTING Standard Home screen: Main Display Line Application Reference Fields Icon Application Buttons 4.2.1 Item Settings To view or adjust the current settings, touch the Item Settings button: Touch the Item Settings button. The Settings screen appears.
® SCOUT SERIES BALANCES - STX EN-11 APW: Set a known Average Piece Weight (APW) To adjust the APW value directly, touch the APW button A numeric input window appears. Key in the desired APW Weight, then press Save. The display returns to the application home screen with the new APW value in the reference field.
® EN-12 SCOUT SERIES BALANCES - STX The PERCENT WEIGHING Home screen: Main Display Line Application Icon Reference Fields Application Buttons 4.3.1 Item Settings To view or adjust the current settings Touch the Item Settings button. The Settings screen appears. Sample Name: Enter a sample name with the alphanumerical keypad and then press Save to store the name.
® SCOUT SERIES BALANCES - STX EN-13 4.4 Dynamic/Animal Weighing Use this application to weigh an unstable load, such as a moving animal. Two different start/reset modes can be selected: Manual (start and stop via key press) and Automatic (start and stop automatically).
® EN-14 SCOUT SERIES BALANCES - STX 4.4.1 Item Settings To view or adjust the current settings: Touch the Item Settings button. The Settings screen appears. Averaging Time: The Averaging Time can be set from 1 to 99 seconds. The default value is 5 seconds. Automatic Mode: The cycle begins when an object (animal) is placed on the pan, and the held value is...
The Scout can be used to determine an object’s density including solid and liquid. A density determination kit (not included, buy separately) is designed to be used with Ohaus Scout STX. However, you may use whatever lab apparatus that suits the requirements for density measurements.
Page 18
® EN-16 SCOUT SERIES BALANCES - STX The balance calculates water density based on the water temperature value entered (internal lookup table). Measure the actual water temperature using a precision thermometer. Press Back to return to the Density Determination home screen. To begin the Density Determination process, press Start.
® SCOUT SERIES BALANCES - STX EN-17 Once the necessary weights have been determined, the density of the sample is displayed in g/cm (along with the weight in air, weight in water) on the Application screen. Press Start to reset all the weight values and restart the process. The balance can also be used to measure the Density of a Buoyant Material Using Water.
Page 20
® EN-18 SCOUT SERIES BALANCES - STX Confirm that the default value displayed (sinker volume) is correct. To edit the default values, touch Sinker Volume. A numeric input window is displayed. Key in the desired value, then press Save. The display returns to the previous screen. Edit the Liquid temperature if required.
® SCOUT SERIES BALANCES - STX EN-19 4.5.4 Measuring the Density of Porous Material Using Oil To enable this feature, enter the Item Settings screen, and select the following: Density Type: Solid Auxiliary Liquid: Water Porous Material: On To adjust the Water Temperature or Oil Density values, touch the Water Temp or Oil Density button.
® EN-20 SCOUT SERIES BALANCES - STX Step 2 of 3 – Weigh the Oiled Sample in Air. Follow the screen instructions then press Accept to store the sample weight (oiled). Step 3 of 3 – Weigh the Oiled Sample Submerged in Liquid.
® SCOUT SERIES BALANCES - STX EN-21 The CHECK WEIGHING Home screen: Main Display Line Application Icon Reference Fields Application Buttons 4.6.1 Item Settings To view or adjust the current settings Touch the Item Settings button. The Settings screen appears. Sample Name: Enter a sample name.
® EN-22 SCOUT SERIES BALANCES - STX Negative Check Negative check is used to determine when the material removed from the balance is within the target range. In this case the UNDER and OVER limits are both negative values. (The UNDER limit must be greater than the OVER limit.) Place the item to be weighed on the balance and press TARE.
® SCOUT SERIES BALANCES - STX EN-23 4.7.2 Display Hold Mode This mode allows the user to hold a stable weight reading. Follow the screen instructions to begin. 1. Place item on the pan and press Hold. The capture process starts. 2.
® EN-24 SCOUT SERIES BALANCES - STX The sample weight is shown on the Main Display Line. 3. Press Accumulate to add the weight of the item to the total. When stable, the new total is shown on the secondary Display Line. 4.
® SCOUT SERIES BALANCES - STX EN-25 Weighing Units: Select the displayed unit for gross and tare. Print Settings: To view or adjust the print settings 4.9.2 Enter Molar Mass Press Molar Mass, and use the numeric keypad to enter the required Molar Mass value of the substance, and then press Save.
Interface connection Security Slot AC Adapter Jack * Interface kits may vary according to local regulations The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by OHAUS is under license.
® SCOUT SERIES BALANCES - STX EN-27 5. MENU SETTINGS 5.1 Menu Navigation All menu navigation is performed by touching the display. To enter the Menu, touch Menu from any Application Home screen. The Main menu appears, with buttons for Back and Exit. Continue touching the appropriate list item to navigate to the Menu items or touch a button to change location.
® EN-28 SCOUT SERIES BALANCES - STX 5.2 Main Menu The Scout balance Main menu structure is illustrated below. 5.2.1 Calibration Scout STX balances offer a choice of two calibration methods: Span Calibration and Linearity Calibration. Note: Do not disturb the balance during any calibration. Calibration sub-menu Span Linearity...
® SCOUT SERIES BALANCES - STX EN-29 5.2.2 Balance Setup Enter this sub-menu to customize Balance display functionality. Language User Settings Filter Level Auto Zero Tracking Stability Auto Tare Date & Time Balance Setup sub-menu Factory default settings are shown below in bold. Language Set the language displayed for menus and displayed messages.
Page 32
® EN-30 SCOUT SERIES BALANCES - STX Level Assist Shows how to level the equipment by adjusting the feet. Filter level Set the amount of signal filtering. = faster stabilization time with less stability. MEDIUM = normal stabilization time with normal stability. HIGH = slower stabilization time with more stability.
® SCOUT SERIES BALANCES - STX EN-31 5.2.3 Weighing Units Enter this sub-menu to activate the desired units of measure. Note: Due to national laws, the indicator may not include some of the units of measure listed. Units Sub-menu milligram gram kilogram carat...
® EN-32 SCOUT SERIES BALANCES - STX 5.2.4 Data Maintenance Data Maintenance sub-menu: Export to Import from Balance Info Export to USB* Export data to USB flash drive. Two types of data can be exported: - Application Mode Settings = APW, Ref.Weight etc. - Menu Settings = balance setup functions etc.
Page 36
® EN-34 SCOUT SERIES BALANCES - STX Single Header Only Set the printing criteria. = Headers will be printed for every print requirement = Headers will be printed once a day Print Options* Set the printing criteria. Printer = Print data to a printer = Print data to a PC Note: If language selection is set to Chinese, Japanese or Korean, these options shall match the actual peripheral device.
Page 37
® SCOUT SERIES BALANCES - STX EN-35 Selection Sample Name Set the status. Set the status. Select All = all options will be turned on OFF = the Sample Name is not Deselect All = all options will be printed. turned off = the Sample Name is printed.
Page 38
® EN-36 SCOUT SERIES BALANCES - STX User Name Signature Line Set the status. Set the status. OFF = the User Name is not OFF = the Signature Line is not printed. printed. = the User Name is printed. = the Signature Line is printed. Signature:__________________ User Name: XXXXXXXXXXXX...
® SCOUT SERIES BALANCES - STX EN-37 Alternate Tare Command Set the alternate command character for Tare. Settings of A to Z are available. The default setting is empty, except P&Z. Alternate Zero Command Set the alternate command character for Zero. Settings of A to Z are available.
® EN-38 SCOUT SERIES BALANCES - STX 5.2.7 Factory Reset Use this sub-menu to reset the menus to their Factory default settings. Reset All = reset all menus to their factory default setting. Exit = return to main screen without resetting any menus. Note: Calibration data is not affected.
OHAUS service agent. For service assistance or technical support in the United States call toll-free 1-800-672-7722 ext. 7852 between 8:00 AM and 5:00 PM EST. An OHAUS product service specialist will be available to provide assistance. Outside the USA, please visit...
EMC: See Declaration of Conformity Pollution degree: 2 Installation category: II Main supply voltage fluctuations: up to ± 10% of the nominal voltage TABLE 7-1. SPECIFICATIONS Model STX123 STX223 STX222 STX422 STX622 STX1202 Capacity (g) 1200 Readability (g) 0.001...
Page 43
® SCOUT SERIES BALANCES - STX EN-41 TABLE 7-2. SPECIFICATIONS (Continued) Capacity x Readability: Model STX123 STX223 STX222 STX422 STX622 STX1202 Gram (g) 120 x 0.001 220 x 0.001 220 x 0.01 420 x 0.01 620 x 0.01 1200 x 0.01 Kilogram (kg) 1.2 x 0.00001...
® EN-42 SCOUT SERIES BALANCES - STX TABLE 7-4. SPECIFICATIONS (Continued) Capacity x Readability: Model STX2202 STX421 STX621 STX2201 STX6201 STX8200 Gram (g) 2200 x 0.01 420 x 0.1 620 x 0.1 2200 x 0.1 6200 x 0.1 8200 x 1 Kilogram (kg) 2.2 x 0.00001 2.2 x 0.0001...
Contact OHAUS Note: * Bluetooth kit is only available in certain regions according to the local regulations. 8. SOFTWARE UPDATES Ohaus is continuously improving its balance software. To obtain the latest release, please contact your Authorized Ohaus Dealer or Ohaus Corporation.
Mark Standard EN 61010-1, EN 61326-1 Refer to the declaration of conformity online at www.ohaus.com/ce. This product complies with the EU Directive 2002/96/EC (WEEE). Please dispose of this product in accordance with local regulations at the collecting point specified for electrical and electronic equipment. For disposal instructions in Europe, refer to www.ohaus.com/weee.
Ohaus. In lieu of a properly returned warranty registration card, the warranty period shall begin on the date of shipment to the authorized dealer.
Page 49
® Series – STX Balanzas Scout ES 1 Í NDICE 1. INTRODUCCIÓN ....................3 Descripción ..............................3 Definición de los sí mbolos y señales de advertencia .................. 3 Precauciones de seguridad .......................... 3 Caracterí sticas ............................. 4 2. INSTALACIÓN ....................4 Instalación de componentes ........................
Page 50
® Series – STX ES 2 Balanzas Scout 5.2.7 Reconfiguración de salida de fábrica por defecto ..................40 5.2.8 Bloqueo ..............................40 6. MANTENIMIENTO ..................39 Calibrado ..............................41 Limpieza ..............................41 Resolución de problemas ........................... 41 Información sobre el servicio técnico ......................42 7.
® Series – STX Balanzas Scout ES 3 1. INTRODUCCIÓN 1.1 Descripción Las balanzas Scout STX son un instrumento de medición de gran calidad que le proporcionará años de servicio y funcionamiento si lleva a cabo su mantenimiento del modo adecuado. La gama de modelos disponibles van de 120g a 8200g.
® Series – STX ES 4 Balanzas Scout 1.4 Caracterí sticas Control táctil :Un acceso rápido mediante gráficos a todas las funciones de control, las aplicaciones y las caracterí sticas técnicas del dispositivo. 2. INSTALACIÓN 2.1 Instalación de componentes Consulte las instrucciones y los gráficos que aparecen a continuación para identificar y efectuar el montaje de los componentes de su balanza Scout.
® Series – STX Balanzas Scout ES 5 2.3 Equilibrado de la balanza La balanza Scout dispone de un indicador iluminado que sirve para recordar que la balanza debe hallarse equilibrada para un pesaje preciso. Hay una burbuja de equilibrado en una pequeña ventana en la parte frontal de la balanza.
® Series – STX ES 6 Balanzas Scout 3. FUNCIONAMIENTO 3.1 Controles Botones de funciones Tabla 3-1. Botón Función primaria On - encendido Tara (Pulsación corta Enciende la balanza Introducir / borrar un valor Cero de tara. Si la balanza está encendida, la configura a cero Función secundaria Off - apagado...
® Series – STX Balanzas Scout ES 7 3.3 Principales Funcionesy Menú Principal (MainMenu) Pesaje : Pulsar Cero para configurar el valor que se muestra en pantalla a cero. Colocar un elemento en la bandeja. La pantalla indicará el peso bruto. Sin que haya ninguna carga en la bandeja, pulsar Tare –...
® Series – STX ES 8 Balanzas Scout APLICACIONES La balanza puede ser configurada para funcionar de modo operativo en varios modos de Aplicación. Tocar el botón situado arriba a la izquierda en el área de Aplicaciones (Applicationárea) para seleccionar el modo de la aplicación : The Scout Balance incorporates the following Applications.
® Series – STX Balanzas Scout ES 9 La pantalla principal de WEIGHING / Pesaje : Lí nea principal de la pantalla Icono de la Campos de referencia Aplicación Botones de la aplicación 4.1.1 Configuración de elementos Para ver o ajustar la configuración actual Tocar el botón ItemSettings –...
USB mientras se halla conectado a la balanza. Para minimizar el riesgo de que surjan problemas, Ohaus sugiere usar un flash drive USB de buena calidad. Para obtener más informació n sobre este particular, por favor consulte el manual de instrucciones del interfaz Host USB.
Page 59
® Series – STX Balanzas Scout ES 11 4.2.1 Configuración de distintos elementos Para ver o modificar / ajustar la configuració n actual, tocar el botón Configuración de elementos : Tocar el botón Configuración de elementos. Aparecerá la pantalla de configuración. SampleName- Nombre de la muestra: Introducir el nombre de la muestra mediante el teclado alfanumérico y luego pulse [Save] –...
Page 60
® Series – STX ES 12 Balanzas Scout APW – Peso Medio Unitario del Elemento: Configurar un peso medio unitario del elementoconocido (APW) Para ajustar directamente el peso medio del elemento, tocar el botó n APW Aparecerá una pantalla que permite introducir un dato numérico.
® Series – STX Balanzas Scout ES 13 La pantalla principal delPesaje porcentual (PERCENT WEIGHING) : Lí nea principal de la pantalla Icono de la Aplicació n Campos de referencia Botones de la aplicación 4.3.1 Configuración de elementos Para ver o modificar / ajustar la configuració n actual Tocar el botón ItemSettings –...
® Series – STX ES 14 Balanzas Scout 4.4 Pesaje dinámico /Animales Utilizar esta aplicación para pesar cargas inestables, como animales vivos (en movimiento). Pueden seleccionar dos modos de inicio – reconfiguración (start/reset) :Manual(start& stop – iniciar y detener mediante el pulsado de teclas) yAutomatic - Automático (start& stop - iniciar y detener de modo automático).
® Series – STX Balanzas Scout ES 15 4.4.1 ItemSettings – Configuración de elementos Para ver o modificar / ajustar la configuració n actual : Tocar el botón ItemSettings – Configuración de elementos. Aparecerá la pantalla de Configuración (Settingsscreen). Averaging Time – Tiempo medio :El tiempo medio puede configurarse de 1 a 99 segundos.
® Series – STX ES 16 Balanzas Scout Gancho superior – Soporte del vaso Prepare la balanza como se muestra en el grá fico situado a la derecha : 1. Apagar la balanza (Power off). 2. Extraer la plataforma de la balanza. 3.
Page 65
® Series – STX Balanzas Scout ES 17 Introducir el valor actual de la temperatura del agua, y luego pulsar [Save] - Guardar. La balanza calcula la densidad del agua en función de la temperatura del agua introducido(consultando una tabla de comprobació...
® Series – STX ES 18 Balanzas Scout Una vez que se han determinado los pesos necesarios, se mostrará en pantalla la densidad de la muestra en g/cm (junto con el peso en suspensión – en el aire, y el peso en inmersión en el agua) en la pantalla de la aplicación(Applicationscreen).
Page 67
® Series – STX Balanzas Scout ES 19 DensityType – Tí po de densidad: Lí quido Nota :Cuando se configura la función Tipo de Densidad (DensityType)en el modo Lí quido(Liquid), se desactivan las opciones de Tipo de lí quido (Liquidtype) y de material poroso (Porous material).
® Series – STX ES 20 Balanzas Scout Una vez que se han determinado los pesos necesarios, se mostrará en pantalla la densidad de la muestra del lí quido expresada en g/cm (junto con el peso en suspensión – en el aire, y el peso en inmersión en el agua) en la pantalla de la aplicació...
Page 69
® Series – STX Balanzas Scout ES 21 Pulsar [Start]– inicio para iniciar el proceso de determinación de la densidad. Paso 1 de 3 – Pesaje de una muestra libre de aceites en el aire. Siga las instrucciones que aparecen en pantalla y pulsar [Accept] - Aceptar para almacenar del valor del peso de la muestra en seco (en suspensió...
® Series – STX ES 22 Balanzas Scout 4.6 Pesaje de comprobación - CheckWeighing Se utiliza el pesaje de comprobació n para comprobar el peso de una muestra contra unos lí mites pre-establecidos. 1. Enla parte superior izquierda de la pantalla principal, seleccionar CheckWeighing – Pesaje de comprobación.
® Series – STX Balanzas Scout ES 23 4.6.2 Lí mites Para ver o modificar / ajustar la configuració n actual Tocar el botónLimits - lí mites. Entonces Aparecerá la pantalla de configuración de los lí mites (limitssettingsscreenappears). Los valores de los lí mites de comprobación aparecerán en la pantalla de configuración (settingsscreen).
® Series – STX ES 24 Balanzas Scout 4.7 DisplayHold – Fijación de un valor en pantalla La aplicación Displayhold– fijació n de un valor en pantalla permite al usuario capturar y almacenar el peso estable más elevado de una serie de mediciones de pesaje. En la parte superior izquierda de la pantalla principal, seleccionar Displayhold–...
® Series – STX Balanzas Scout ES 25 4.7.3 Modo Peakhold– Fijación en pantalla del valor más elevado Este modo le permite al usuario mantener fijado en pantalla el valor de lectura estable má s elevado. Siga las instrucciones que aparecen en pantalla para comenzar. 1.
Page 74
® Series – STX ES 26 Balanzas Scout Se mostrará en la lí nea principal de la pantalla el peso de la muestra. 3. PulsarAccumulate - acumularpara sumar el peso del elemento al total. Cuando es, se muestra el nuevo total en la lí...
® Series – STX Balanzas Scout ES 27 SampleName - Nombre de la muestra :Introducir el nombre de la muestra. WeighingUnits – Unidades de pesaje :Selecciona la unidad de pesaje para el peso bruto y la tara. PrintSettings– Configuración de impresión: Para ver o modificar / ajustar las configuraciones de impresión 4.9.2 Introducir masa molar(Molar...
* Los kits de interfaces disponibles pueden estar sujetos a cambios de acuerdo con las distintas normativas nacionales aplicables La palabra y el logotipo Bluetooth® son marcas registradas propiedad de Bluetooth SIG, Inc., OHAUS hace uso de dichas marcas al amparo de sus licencias de utilización.
® Series – STX Balanzas Scout ES 29 5. CONFIGURACIONES DEL MENÚ (MENU SETTINGS) 5.1 Navegación en el Menú (MenuNavigation) Toda la navegación en el menú se efectúa a través de la pantalla táctil. Para entrar en el menú, toque [Menu]a partir de cualquier pantalla principal de una Aplicación (ApplicationHome screen).Aparecerá...
® Series – STX ES 30 Balanzas Scout Salir del Menú y volver a la Aplicación actual Una vez confirmada la configuración, tocar Back - atrás oExit - Salirpara volver a la Aplicación. 5.2 Menú principal (MainMenu) A continuación de muestra la estructura del menú principal de la balanza Scout. 5.2.1 Calibrado Las Balanzas ScoutSTX permiten escoger entre dos mé...
® Series – STX Balanzas Scout ES 31 5.2.2 Balance Setup – Configuración de la balanza Entrar en este sub-menú para personalizar las funciones de la pantalla de la Balanza. Language UserSettings FilterLevel Auto Zero Tracking Idioma Configuraciones del Nivel de filtros Ajuste a cero automático usuario Stability...
Page 80
® Series – STX ES 32 Balanzas Scout Auto Off – Apagado automático Permite configurar el tiempo de inactividad tras el cual elequipo se apagará automáticamente. Off - apagado, 1 min., 5 mins., 10 mins. Nota :La función de apagado automático (Auto Off) funciona en bruto únicamente cuando el interruptor de seguridad está...
® Series – STX Balanzas Scout ES 33 5.2.3 Unidades de pesaje Entre en este sub-menú para activar las unidades de pesaje deseadas. Nota :Por causa de las distintas leyes y normativas nacionales de aplicación, es posible que el indicador no incluya algunas de las unidades de medida que aparecen en el siguiente listado. Sub-menú...
® Series – STX ES 34 Balanzas Scout 5.2.4 Data Maintenance – Conservación / almacenamiento de datos Sub-menú de conservación / almacenamiento de datos : Exportar Importar a InfoBalanza partir de USB Exportar a USB* Exportar datos a un soporte flash drive USB. Pueden exportarse dos tipos de datos : - Configuraciones de los modos de las aplicaciones (Application Mode Settings) = Peso medio de la muestra (APW), peso de referencia (Ref.Weight) etc.
Page 83
® Series – STX Balanzas Scout ES 35 Velocidad de transmisión (BaudRate) Permite configurar la velocidad de transmisión (bits por segundo). 1200 = 1200 bps 2400 = 2400 bps 4800 = 4800 bps 9600 = 9600 bps 19200 = 19200 bps 38400 = 38400 bps 57600...
Page 84
® Series – STX ES 36 Balanzas Scout Un solo encabezado (Single HeaderOnly) Configuración de los criterios de impresión. OFF – apagado = Se imprimirán los encabezados en cada impresión ON – encendido = Los encabezados se imprimirán únicamente una vez al dí a Opciones de impresión* Configuración de los criterios de impresión.
Page 85
® Series – STX Balanzas Scout ES 37 Selección (Selection) Nombre de la muestra (SampleName) Configurar el estatus. Configurar el estatus. OFF – apagado = No se imprimirá el Seleccionar todo = Todas las opciones estará n encendidas nombre de la muestra. ON –...
Page 86
® Series – STX ES 38 Balanzas Scout Lí nea para la firma (Signature Line) Nombre de la balanza Configurar el estatus. (Balance Name): XXXXXXX OFF – apagado = No se imprimirá la lí nea para la firma. Nombre de usuario (UserName) ON –...
® Series – STX Balanzas Scout ES 39 AltCommand (Comando de impresión alternativo) Comando de impresión alternativo (AlternatePrintCommand) Permite configurar el carácter a utilizar como comando alternativo para imprimir. Hay configuraciones disponibles de la A a la Z. No hay configuració n por defecto exceptuando P.T o Z.
® Series – STX ES 40 Balanzas Scout Nombre de usuario (UserName) Configurar la identificación del usuario. Se hallan disponibles configuraciones alfanuméricas de hasta 25 caracteres. La configuración por defecto esScout. Nombre del proyecto (Project Name) Entrar en este menú para configurar la identificación del Proyecto. Se hallan disponibles configuraciones alfanuméricas de hasta 25 caracteres.
® Series – STX Balanzas Scout ES 41 6. Mantenimiento 6.1 Calibrado Es conveniente comprobar el calibrado con cierta periodicidad colocado un peso con un peso preciso establecido sobre la balanza para comprobar el resultado. Si resulta necesario efectuar una calibración ejecute el procedimiento de calibrado interno. Limpieza Riesgos de descarga eléctrica.
Si el apartado de resolución de problemas no le resulta útil para resolver un problema, puede ponerse en contacto con su agente autorizado OHAUS. Para servicio o soporte técnico en los Estados Unidos puede llamar al servicio de atención al cliente al número gratuito :1-800-672- 7722 ext.
Page 91
® Series – STX Balanzas Scout ES 43 TABLA 7-1. Caracterí sticas técnicas MODELO STX123 STX223 STX222 STX422 STX622 STX1202 Capacidad (g) 1200 Legibilidad d (g) 0.001 0.001 0.01 0.01 0.01 0.01 Repetibilidad (desviació n 0.002 0.002 0.01 0.01 0.01 0.02...
Page 92
® Series – STX ES 44 Balanzas Scout TABLA 7-3. Caracterí sticas técnicas (Continuación) MODELO STX2202 STX421 STX621 STX2201 STX6201 STX8200 Capacidad (g) 2200 2200 6200 8200 Legibilidad d (g) 0.01 Repetibilidad (desviació n 0.02 está ndar) (g) Linealidad (g) 0.03 Masa de Calibrado de Rango 2 kg...
Contact OHAUS 8. ACTUALIZACIONES DE PROGRAMAS DE SOFTWARE Ohaus está sumida como empresa en un proceso de mejora continua y continuada de mejora del software de sus balanzas. Para obtener la última versión, por favor, póngase en contacto con su agente autorizado Ohaus o con la empresaOhaus.
Para las instrucciones sobre la eliminación de residuos aplicable en Europa, por favor, consulte nuestra página web : www.OHAUS.com/weee. Gracias por contribuir a la protecció n del medio ambiente.
Page 95
Bureau Veritus Quality International (BVQI), lo que confirma que el sistema de gestión de calidad de Ohaus es compatible con los requisitos de la norma ISO 9001. El 21 de junio de 2012, Ohaus Corporation, EE.UU., volvió a registrarse en el estándar ISO 9001:2008.
Page 96
Durante el perí odo de vigencia de la garantí a, Ohaus reparará, o, a su opció n, sustituirá sin cargo alguno cualquier componente que demuestre estar defectuoso, siempre que el producto se devuelva a Ohaus, flete prepagado.
Page 97
Balances Scout ®Séries – STX FR-1 TABLE DES MATIÈRES 1. INTRODUCTION ....................3 Description ..............................3 Définition des signaux d'avertissement et des symboles ................3 Mesures de sécurité ............................. 3 Fonctionnalités ............................. 4 2. INSTALLATION ....................4 Installation des composants......................... 4 2.1.1 Déverrouillage du verrou de transport ......................4 2.1.2...
Balances Scout ®Séries – STX FR-3 1. INTRODUCTION 1.1 Description La balance Scout STX est un instrument de pesée de grande qualité qui vous procurera des années de service si celui-ci est entretenu avec soin. Les modèles disponibles couvrent une plage de 120 g à...
FR-4 Balances Scout ®Séries - STX Ne placez pas la balance de telle sorte qu'il soit difficile d’avoir accès à la connexion de l'alimentation électrique. 1.4 Fonctionnalités Commandes tactiles : Accès rapide, graphique à toutes les fonctions de contrôle, utilisations et fonctionnalités.
Balances Scout ®Séries – STX FR-5 importants, avec des changements rapides de température, près de champs magnétiques ou à proximité d'appareils générant des champs magnétiques ou des vibrations. 2.3 Mise de niveau de la balance La Scout a un indicateur de niveau lumineux rappelant que la balance doit être mise de niveau pour un pesage précis.
Balances Scout ®Séries - STX FR-6 Disposer des masses d’étalonnage appropriées avant de commencer l’étalonnage. Se reporter à la section Étalonnage pour les masses et la procédure d'étalonnage. 3. OPÉRATION 3.1 Commandes Fonctions des boutons TABLEAU 3-1 Bouton Fonction primaire Activé...
Balances Scout ®Séries – STX FR-7 Boutons d'application : Les fonctions varient selon l'application 3.2 Principales fonctions et menu principal Pesée : Appuyez sur Zéro pour mettre l'affichage à zéro. Placez un objet sur le plateau. L'affichage indique le poids brut. Mesure de la tare : En l'absence de charge sur le plateau, appuyez sur Tare pour régler l'affichage à...
FR-8 Balances Scout ®Séries - STX La balance Scout comprend les applications suivantes. Pesé e : Comptage Pesée en Pesée Détermination Pesée de de pièces pourcentage dynamique de la masse contrôle (animal) volumique Maintien de Totalisation Mole l'affichage Remarque : Avant d'exploiter une application, vérifiez que la balance soit de niveau et étalonné...
Dans ce cas, débranchez le lecteur flash USB et essayez un autre lecteur flash USB. Ohaus décline toute responsabilité si les données sur le lecteur flash USB sont effacées ou si le lecteur flash USB est endommagé lorsqu'il est connecté à la balance.
FR-10 Balances Scout ®Séries - STX 4.2 Comptage de pièces Utilisez cette application pour compter des échantillons de poids uniforme. 1. Dans la partie supérieure gauche de l'écran d'accueil, sélectionnez Comptagede pièces. 2. Appuyez sur Tare ou Zéro, le cas échéant, pour commencer. 3.
Balances Scout ®Séries – STX FR-11 Établir un poids moyen des pièces (APW) Chaque fois qu'un nouveau type de pièce est décompté, le poids nominal d'une pièce (poids moyen d’une pièce ou APW) doit être établi à l'aide d'une petite quantité de pièces. Cette APW est stockée jusqu'à...
FR-12 Balances Scout ®Séries - STX La valeur par défaut (ou dernière valeur) du poids de ré férence est affichée. 1. Dans la partie supérieure gauche de l'écran d'accueil, sélectionnez Pesée en pourcentage. 2. Placez un objet sur le plateau. La différence entre l'échantillon et le poids de ré férenceest affichée à...
Balances Scout ®Séries – STX FR-13 Alternativement, appuyez sur le bouton Réf. de l’écran Recalculer le poids de Poids référence de la pesée en pourcentage afin d’établir un nouveau poids de référence manuellement via un clavier numérique. Saisir le poids de ré férence désiré, puis appuyez sur Sauvegarder.
Page 110
FR-14 Balances Scout ®Séries - STX 5. Lorsque le compte à rebours est terminé, le résultat estaffiché et conservé. Appuyez sur Effacer pour supprimer le poids conservé etrevenir à l'écran initial. Remarque : Dé barrasser le plateau avant de commencer un nouveau cycle de pesée dynamique.
Un kit de détermination de la masse volumique (non inclus, vendu séparé ment) est conç u pour être utilisé avec la Ohaus Scout STX. Cependant, il est possible d’utiliser tout appareil de laboratoire qui répond aux exigences de mesure de masse volumique. L’utilisation de la pesée sous crochet est recommandée si le poids des matières solides est supérieur à...
Page 112
FR-16 Balances Scout ®Séries - STX Principale ligne d'affichage Icône de l’application Champs de référence ; Boutons d'application : 4.5.1 Mesure de la masse volumique d'un solide à l’aide d'eau (par défaut) Appuyez le bouton Paramètres élément pour ouvrir l'écran des paramètres de la Détermination de la masse volumique.
Balances Scout ®Séries – STX FR-17 Étape 2 de 2 - Peser l'échantillon immergé dans le liquide. Suivez les instructions à l'écran, puis appuyez sur Accepter pour stocker le poids de l'échantillon (immergé dans un liquide). Lorsque les poids nécessaires ont été déterminés, la masse volumique de l'échantillon est affiché...
Page 114
FR-18 Balances Scout ®Séries - STX Type de masse volumique : solide Liquide auxiliaire : Autre Matériau poreux : arrêt Confirmer que les valeurs par défaut affichées (masse volumique du liquide, etc.) soient correctes. Commencez le processus de dé termination de la masse volumique en appuyant sur Démarrer et en suivant les instructions à...
Page 115
Balances Scout ®Séries – STX FR-19 Étape 1 sur 2 - Peser la masse en milieu aérien. Suivez les instructions à l'écran, puis appuyez sur Accepter pour stocker le poids de la masse (« en milieu aérien »). Étape 2 de 2 - Peser la masse immergée dans le liquide test.
Page 116
FR-20 Balances Scout ®Séries - STX Pour régler les valeurs de la température de l’eau ou de la masse volumique de l'huile, appuyer sur la touche Température eau ou Masse volumique huile. La balance calcule la masse volumique de l'eau en fonction de la valeur de température de l'eau saisie (table de correspondance).
Balances Scout ®Séries – STX FR-21 Étape 3 sur 3 - Pesage de l'échantillon imprégné d’huile immergé dans un liquide. Suivez les instructions à l'écran, puis appuyez sur Accepter pour stocker le poids de l'échantillon imprégné d’huile (immergé dans un liquide). Lorsque les poids nécessaires ont été...
FR-22 Balances Scout ®Séries - STX Appuyez sur le bouton Paramètres élément. L'écran Paramètres est affiché. Nom échantillon:Saisissez un nom d'échantillon. Unités de pesage : Sélectionnez l'unité affichée. Paramètres d’impression : Pour afficher ou modifier les paramètres d'impression 4.6.2 Limites Pour afficher ou modifier les paramètres actuels Appuyez sur la touche Limites.
Balances Scout ®Séries – STX FR-23 4.7 Maintien de l'affichage L'application Maintien d'affichage permet à l'utilisateur de capturer et de stocker le poids stable le plus élevé d’une série de pesées. Dans le coin supérieur gauche de l'écran d'accueil, sélectionnez Maintiend’affichage. L'écran d'accueil du Maintiend’affichage : Principale ligne d'affichage Icône de l’application...
FR-24 Balances Scout ®Séries - STX 4.7.3 Mode maintien du maximum Ce mode permet à l'utilisateur de maintenir la lecture du poids stable le plus élevé. Suivez les instructions à l'écran pour commencer. 1. Sélectionnez le mode Maintien du maximum dans les paramètres de l'article(cf. section 4.7.1).
Balances Scout ®Séries – STX FR-25 Le poids de l'échantillon est affiché sur la ligne principale d’affichage. 3. Appuyez Cumul pour ajouter le poids de l’article au total. Une fois stabilisé, le nouveau total est indiqué sur la ligne d’affichage secondaire. 4.
FR-26 Balances Scout ®Séries - STX Unités de pesage : Sélectionnez l'unité affichée pour brut et tare. Paramètres d’impression : Pour afficher ou modifier les paramètres d'impression 4.9.2 Saisie masse molaire Appuyez sur Masse molaire, et u pavé tiliser le numérique pour saisir la valeur requise de la masse molaire de la substance, puis appuyez sur Sauvegarder.
Figure 4-4. Arrière de la balance * Ces kits d'interface varient selon les réglementations locales Les marques verbales et les logos Bluetooth® sont des marques déposées appartenant à Bluetooth SIG, Inc. ; l’exploitation de ces marques par OHAUS est autorisée sous licence.
FR-28 Balances Scout ®Séries - STX 5. PARAMÈTRES MENU 5.1 Navigation dans le menu Toute la navigation dans le menu est effectuée en touchant l'écran. Pour entrer dans le menu, appuyez Menu à partir de tout écran d’accueil d’application. Le menu principal s’affiche, avec des touches pour Retouret Sortie.
Balances Scout ®Séries – STX FR-29 5.2 Menu principal La structure du menu principal de la balance Scout est illustré e ci-dessous. 5.2.1 Étalonnage Les balances Scout ST offrent le choix de deux méthodes d’étalonnage : Étalonnage par intervalle de mesure et étalonnage linéaire. Remarque : ne pas toucher la balance lors de l’étalonnage.
Page 126
FR-30 Balances Scout ®Séries - STX 5.2.2 Configuration de la balance Dans ce sous-menu, on peut personnaliser l’affichage de la balance. Langue Paramètres Niveau filtre Suivi du zéro utilisateur automatique Stabilité Tarage Date et heure automatique Sous-menu de configuration de la balance Les paramètres d'usine par défaut sont indiqués ci-dessous, en caractères gras.
Page 127
Balances Scout ®Séries – STX FR-31 Arrêt automatique Réglez le temps d’inactivité qui entraîne l’arrêt de l’appareil. Arrêt, 1 min, 5 min, 10 min Remarque : L’arrêt automatique ne fonctionne seulement qu’en brut ou lorsque l'interrupteur de sécurité est en position de marche. Aide à...
Page 128
FR-32 Balances Scout ®Séries - STX 5.2.3 Unités de pesage Entrez dans ce sous-menu pour activer les unités de mesure désirées. Remarque : En raison de lois nationales, l'indicateur peut ne pas inclure certaines des unités de mesure énumérée. Sous-menu des unité s milligramme gramme kilogramme...
Balances Scout ®Séries – STX FR-33 5.2.4 Maintenance des données Sous-menu de maintenance des données : Exportation Importation Information d’une clef vers une clef balance Exportation vers une clef USB Exporter des données vers un lecteur flash USB. Deux types de données peuvent être exportés : - Paramètres du mode application = APW, Poids de ré...
Page 131
Balances Scout ®Séries – STX FR-35 En-tête simple uniquement Définir les critères d'impression. ARRÊT = les en-têtes sont imprimés pour toutes les demandes d'impression MARCHE = les en-têtes sont imprimés une fois par jour Options d'impression* Définir les critères d'impression. Imprimante = imprimer des données sur une imprimante = imprimer des données sur un ordinateur...
Page 132
FR-36 Balances Scout ®Séries - STX Nom de l’échantillon Sélection Définir le statut. Définir le statut. = le nom de l’échantillon Sélectionnez Tous= toutes les options ARRÊT seront activées n'est pas imprimé. = le nom de l’échantillon Désélectionnez Tous = toutes les MARCHE options seront désactivées est imprimé.
Page 133
Balances Scout ®Séries – STX FR-37 Nom d'utilisateur Définir le statut. Ligne de signature Définir le statut. ARRÊT = le nom de l’utilisateur n'est pas imprimé. ARRÊT = la ligne de MARCHE = le nom de signature n'est pas imprimée. l’utilisateur est imprimé.
FR-38 Balances Scout ®Séries - STX Autre commande de tare Paramétrez le caractère de l’autre commande pour Tare. Des réglages de A à Z sont disponibles. Le paramétrage par défaut est vide, sauf P et Z. Autre commande de Zéro Paramétrez le caractère de l’autre commande pour Zéro.
Balances Scout ®Séries – STX FR-39 Pied de page Active l'impression des en-têtes BPL. Il y a deux en-têtes disponibles. Un paramétrage alphanumérique jusqu'à 25 caractères est disponible pour chacun des paramètres d'en-tête. . 5.2.7 Retour aux paramètres d’usine Utilisez ce sous-menu pour réinitialiser les menus à leurs paramètres d'usine par défaut.
États-Unis, composer le numéro gratuit 1-800-672-7722, poste 7852 entre 8h00 et 17h00 (GMT - 5). Un spécialiste du service produit OHAUS est disponible pour apporter son aide. En dehors des États-Unis, bien vouloir se rendre sur notre site web, www.ohaus.com...
Page 137
Balances Scout ®Séries – STX FR-41 FICHE TECHNIQUE 7.1 Spécifications Conditions ambiantes Utilisation d'intérieur seulement Plage de température de fonctionnement +5 ° C à +40 ° C Humidité relative: 10 % à 80 % à 31 ° C sans condensation, diminution linéaire jusqu'à 50 % à...
Remarque : * Le kit Bluetooth n’est disponible qu’uniquement dans certaines régions conformément à la réglementation locale. 8. MISES À JOUR DE LOGICIEL Ohaus améliore continuellement le logiciel de la balance. Pour obtenir la dernière version, veuillez contacter votre revendeur Ohaus agréé ou Ohaus Corporation.
La conformité aux normes suivantes est indiquée par la marque correspondante sur le produit. Marquage Standard EN 61010-1, 61326-1 Se reporter à la déclaration de conformité en ligne sur www.ohaus.com/ce. Ce produit est conforme à la Directive européenne 2002/96/CE (DEEE). Bien vouloir mettre au rebut ce produit, conformément à la réglementation locale, au point spécifié...
Page 142
En 1994, Ohaus Corporation, États-Unis, a reç u la certification ISO 9001 du Bureau Veritas Quality International (BVQI), qui confirme que le système de gestion de la qualité de Ohaus est conforme aux spécifications de la norme ISO 9001. Le 21 juin 2012, Ohaus Corporation, USA,...
Page 143
FR-47 GARANTIE LIMITÉE Les produits Ohaus sont garantis contre des défauts matériels et vices de fabrication à partir de la date de livraison et durant toute la duré e de la période de garantie. Pendant la période de garantie, Ohaus va réparer, ou, selon son propre choix, remplacer sans frais tout (tous) composant(s) qui s'avère(ent) défectueux, à...
Page 145
SCOUT® WAAGEN-SERIEN - STX DE-1 INHALTSVERZEICHNIS 1. EINFÜHRUNG....................3 Beschreibung ............................... 3 Definition der Warnhinweise und Symbole ....................3 Vorsichtsmaßnahmen ..........................3 Funktionen ..............................4 2. INSTALLATION ....................4 Installationskomponenten ..........................4 2.1.1 Lösen der Transportsicherung ........................4 2.1.2 Installation der Waagschale ........................4 2.1.3 Sicherheitsslot ............................4 Auswahl des Stellplatzes ..........................
SCOUT® WAAGEN-SERIEN - STX DE-3 1. EINFÜHRUNG 1.1 Beschreibung Der Scout STX Waage ist eine hochwertige Waage, die wenn sie richtig gepflegt wird jahrelang ihre Dienste tut. Modelle sind von 120 g bis 8200 g erhältlich. 1.2 Definition von Warnhinweisen und Symbolen Sicherheitshinweise sind mit Warnhinweisen und Symbolen gekennzeichnet.
DE-4 SCOUT® WAAGEN-SERIEN - STX 1.4 Eigenschaften Tippschaltungen: Schneller, grafischer Zugriff auf alle Steuerfunktionen, Anwendungen und Funktionen. 2. INSTALLATION 2.1 Installieren der Komponenten Schauen Sie auf die Abbildungen und Anweisungen unten, um die Komponenten zu identifizieren und zu sehen, wie Sie diese an Ihre Scout Waage montieren. Alle Komponenten müssen vor Verwendung der Waage zusammengebaut werden.
SCOUT® WAAGEN-SERIEN - STX DE-5 2.3 Nivellieren der Waage Die Scout hat eine beleuchtete Nivellierungsanzeige, die daran erinnert, dass die Waage zum genauen Wiegen nivelliert werden muss. Auf der Vorderseite der Waage befindet sich in einem kleinen runden Fenster eine Nivellierungsanzeige. Um die Waage zu nivellieren, stellen Sie die Füße an jeder Ecke so ein, dass die Blase im Kreis zentriert ist.
DE-6 SCOUT® WAAGEN-SERIEN - STX 3. BETRIEB 3.1 Bedienelemente Tastenfunktionen Tabelle 3-1. Taste Tara Primärfunktion Eingeben/deaktivieren Schaltet die Waage ein. (Kurz drücken) eines Tara-Werts. Zero Wenn die Waage eingeschaltet ist, steht sie auf Zero (Null) Sekundä rfunktion Schaltet die Waage aus. (Lange drücken) Hinweise: Kurzes Drücken: Drü...
SCOUT® WAAGEN-SERIEN - STX DE-7 Hauptfunktionen und Hauptmenü Wiegen: Drücken Sie auf die Null, um die Anzeige auf Zero zu setzen. Legen Sie einen Gegenstand auf die Schale. Das Display zeigt das Bruttogewicht an. Tarieren: Ohne Last auf der Schale, drücken Sie Tara, um die Anzeige auf Zero (Null) zu setzen.
DE-8 SCOUT® WAAGEN-SERIEN - STX Der Scout Waage enthält die folgenden Anwendungen. Wiegen: Stückzählung Prozentgewichtung Dynamische Dichtebestimmun Kontrollwiege (tierisches) Wiegen Display Summieren Mole Hold Hinweis: Bevor Sie irgendeine Anwendung benutzen, stellen Sie sicher, dass die Waage nivelliert und kalibriert ist. 4.1 Wiegen Verwenden Sie diese Anwendung, um das Gewicht der Gegenstände in der ausgewählten Maßeinheit festzulegen.
USB Flash-Laufwerk während es an die Waage angeschlossen ist kaputt geht. Um das Risiko von auftretenden Problemen zu minimieren, rät OHAUS, einen hochwertigen USB-Stick zu verwenden. Für weitere Informationen, schauen Sie bitte in die Bedienungsanleitung des USB Anbieters.
DE-10 SCOUT® WAAGEN-SERIEN - STX Der Standard-Startbildschirm für STÜCKZÄHLEN: Hauptanzeigenzeile Anwendungs Referenzfelder symbol Anwendungstasten 4.2.1 Artikeleinstellungen Zum Anzeigen oder Anpassen der aktuellen Einstellungen, tippen Sie auf die Taste Artikeleinstellungen: Tippen Sie auf die Taste Artikeleinstellungen. Der Bildschirm Einstellungen wird angezeigt. Probename: Geben Sie mit der alphanumerischen Tastatur einen Probenamen ein und drücken Sie auf...
Page 155
SCOUT® WAAGEN-SERIEN - STX DE-11 APW: Stellen Sie ein bekanntes Durchschnittliches Stückgewicht (APW) ein Um den APW-Wert direkt einzustellen, berühren Sie die APW-Taste Ein numerisches Eingabefenster erscheint. Geben Sie das gewünschte APW-Gewicht ein und drücken Sie dann auf Speichern. Das Display kehrt mit dem neuen APW-Wert im Referenzfeld zum Startbildschirm der Anwendung zurück.
DE-12 SCOUT® WAAGEN-SERIEN - STX Der PROZENTWÄGE Startbildschirm: Hauptanzeigenzeile Anwendungssymbol Referenzfelder Anwendungstasten 4.3.1 Artikeleinstellungen Zum Anzeigen oder Anpassen der aktuellen Einstellungen Tippen Sie auf die Taste Artikeleinstellungen. Der Bildschirm Einstellungen wird angezeigt. Probename: Geben Sie mit der alphanumerischen Tastatur einen Probenamen ein und drücken Sie auf Speichern, um den Namen zu speichern.
Page 157
SCOUT® WAAGEN-SERIEN - STX DE-13 4.4 Dynamische/Tierwägung Verwenden Sie diese Anwendung, um eine instabile Last zu wiegen, wie zum Beispiel ein sich bewegendes Tier. Zwei verschiedene Start/Zurücksetzen-Modi stehen zur Auswahl: Manuell (Start und Stopp ü ber Tastendruck) und Automatisch (automatisch starten und stoppen). Der DYNAMISCHE WIEGEN Startbildschirm: Hauptanzeigezeile Referenzfelder...
Page 158
DE-14 SCOUT® WAAGEN-SERIEN - STX 4.4.1 Artikeleinstellungen Zum Anzeigen oder Anpassen der aktuellen Einstellungen: Tippen Sie auf die Taste Artikeleinstellungen. Der Bildschirm Einstellungen wird angezeigt. Mittelungszeit: Die Mittelungszeit kann von 1 bis 99 Sekunden eingestellt werden. Der Standardwert ist 5 Sekunden. Automatischer Modus: Der Zyklus beginnt, wenn ein Objekt (Tier) auf die Schale gelegt wird, und der gehaltene Wert...
Objekte zu bestimmen. Ein Dichtebestimmungs-Kit (nicht im Lieferumfang enthalten aber separat erhältlich) ist so konzipiert, dass es mit der OHAUS Scout STX verwendet werden kann. Jedoch können Sie jedes beliebige Laborgerät verwenden, das den Anforderung der Dichtemessungen gerecht wird. Wenn das Feststoffgewicht mehr als 200 g beträgt, wird empfohlen, den Unterflurwiegehaken zu verwenden.
Page 160
DE-16 SCOUT® WAAGEN-SERIEN - STX Ein numerisches Eingabefenster erscheint. Geben Sie die aktuelle Wassertemperatur ein, und drücken Sie dann auf Speichern. Die Waage berechnet die Wasserdichte bezogen auf den eingegebenen Wassertemperaturwert (interne Referenztabellen). Messen Sie die tatsächliche Wassertemperatur mit einem Präzisionsthermometer.
Page 161
SCOUT® WAAGEN-SERIEN - STX DE-17 Sobald die erforderlichen Gewichte bestimmt wurden, wird die Dichte der Probe auf dem Anwendungsbildschirm in g/cm angezeigt (zusammen mit dem Gewicht in Luft und in Wasser). Drücken Sie auf Start, um alle Gewichtswerte zurückzusetzen und den Vorgang neu zu starten. Die Waage kann auch verwendet werden, um die Dichte eines schwimmfähigen Materials unter Verwendung von Wasser zu messen.
Page 162
DE-18 SCOUT® WAAGEN-SERIEN - STX 4.5.3 Messen der Dichte einer Flüssigkeit mit einem kalibrierten Senkblei (nicht mitgeliefert) Aktivieren Sie diese Funktion, geben Sie auf dem Bildschirm Artikeleinstellungen die Dichte ein und wählen Sie das folgende: Dichtetyp: Flüssigkeit Hinweis: wenn der Dichtetyp auf Flüssigkeit gesetzt ist, sind die Auswahlmöglichkeit Flüssigkeitsart und Poröses Material deaktiviert.
Page 163
SCOUT® WAAGEN-SERIEN - STX DE-19 Schritt 2 von 2 - Wiegen Sie das Senkblei eingetaucht in Testflüssigkeit. Folgen Sie den Bildschirmanweisungen, und drücken Sie dann auf Akzeptieren, um das Senkbleigewicht (in Flüssigkeit eingetaucht) zu speichern. Sobald die erforderlichen Gewichte bestimmt wurden, wird die Dichte der Flüssigkeitsprobe auf dem Anwendungsbildschirm in g/cm angezeigt (zusammen mit dem Gewicht in der...
Page 164
DE-20 SCOUT® WAAGEN-SERIEN - STX Ein numerisches Eingabefenster wird angezeigt. Geben Sie den gewünschten Wert ein und drücken Sie auf Speichern. Um zum Startbildschirm Dichtebestimmung zurückzukehren, tippen Sie auf Beenden. Drücken Sie auf Start, um mit der Dichtebestimmung zu beginnen. Schritt 1 von 3 - Wiegen Sie die nicht- geölte Probe in Luft.
SCOUT® WAAGEN-SERIEN - STX DE-21 Sobald die erforderlichen Gewichte bestimmt wurden, wird die Dichte der Probe auf dem Anwendungsbildschirm in g/cm angezeigt (zusammen mit dem Gewicht in der Luft und im Wasser). Der Wert verbleibt auf dem Display bis auf Start getippt wird.
DE-22 SCOUT® WAAGEN-SERIEN - STX 4.6.2 Grenzwerte Zum Anzeigen oder Anpassen der aktuellen Einstellungen Tippen Sie auf die Taste Grenzwerte. Der Bildschirm Grenzwerteinstellungen erscheint. Die Prü fgrenzwerte werden im Einstellungsbildschirm angezeigt. Um den Übergrenzwert einzustellen, berühren Sie die Taste Übergrenzwert und geben Sie dann die gewünschte Gewichtsgrenze ein.
SCOUT® WAAGEN-SERIEN - STX DE-23 Hauptanzeigezeile Anwendungssymbol Referenzfelder Anwendungstasten 4.7.1 Artikeleinstellungen Zum Anzeigen oder Anpassen der aktuellen Einstellungen: Tippen Sie auf die Taste Artikeleinstellungen. Der Bildschirm Einstellungen wird angezeigt. Modus: Wählen Sie den Modus, um entweder Peak Hold oder Display Hold (Standard) einzustellen.
DE-24 SCOUT® WAAGEN-SERIEN - STX 4.7.3 Peak-Hold-Modus Dieser Modus ermöglicht es dem Benutzer, den höchsten stabilen Gewichtswert zu halten. Folgen Sie den Bildschirmanweisungen, um zu beginnen. 1. Wä hlen Sie in Artikeleinstellungen den Peak Hold-Modus (siehe Abschnitt 4.7.1). 2. Geben Sie den Artikel auf die Waagschale und drücken Sie auf Start.
SCOUT® WAAGEN-SERIEN - STX DE-25 Das Probengewicht wird auf der Hauptanzeigezeile angezeigt. 3. Drücken Sie auf Akkumulieren, um das Gewicht des Gegenstandes der Gesamtmenge hinzuzufügen. Wenn stabil, wird die neue Summe auf der sekundären Displayzeile angezeigt. 4. Entfernen Sie den Artikel von der Waagschale, dann geben Sie den nächsten Artikel hinein und fahren wie oben fort.
DE-26 SCOUT® WAAGEN-SERIEN - STX Probenamen: Geben Sie einen Probenamen ein. Wiegeeinheiten: Wä hlen Sie die angezeigte Einheit für Brutto und Tara. Druckeinstellungen: Um die Druckeinstellungen anzuzeigen oder anzupassen 4.9.2 Geben Sie die Molmasse ein Drücken Sie auf Molmasse und benutzen Sie das numerische Tastenfeld, um den erforderlichen Molmassewert des Stoffes einzugeben, und drücken Sie dann auf...
®* Verbindung Bluetooth Netzteil Slot Buchse Abbildung 4-3. Rückseite der Waage * Schnittstellen-Kits können nach den örtlichen Bestimmungen variieren Bluetooth® Warenzeichen und Logos sind eingetragene Warenzeichen der Bluetooth SIG, Inc. und die Verwendung dieser Marken durch OHAUS erfolgt unter Lizenz.
DE-28 SCOUT® WAAGEN-SERIEN - STX 5. MENÜEINSTELLUNGEN Menü Navigation Jede Menü-Navigation wird durch Berührung des Displays durchgeführt. Um das Menü aufzurufen, tippen Sie von jeder Bildschirmanwendung aus auf Menü. Das Hauptmenü erscheint, mit den Tasten Zurück und Beenden. Machen Sie weiter, indem Sie auf den entsprechenden Listeneintrag tippen, um durch die Menüpunkte zu navigieren, oder tippen Sie auf eine Taste, um die Position zu verändern.
SCOUT® WAAGEN-SERIEN - STX DE-29 5.2 Hauptmenü Die Hauptmenüstruktur der Scout Wage ist unten dargestellt. 5.2.1 Kalibrierung Scout STX Waagen bieten eine Auswahl von zwei Kalibrierungsmethoden: Bereichskalibrierung und Linearitätskalibrierung. Hinweis: Berühren Sie die Waage während der Kalibrierung nicht. Kalibrierung Untermenü Bereichskalibrierung Linearitätskalibrierung 5.2.1.1 Bereichskalibrierung...
DE-30 SCOUT® WAAGEN-SERIEN - STX 5.2.2 Einstellung der Waage Gehen Sie in dieses Untermenü, um die Anzeigefunktion der Waage anzupassen. Sprache Benutzereinstellungen Filterstufe Automatische Nullverfolgung Stabilität Auto Tara Datum & Uhrzeit: Einstellungsuntermenü der Waage Werkseinstellungen sind unten fett gedruckt. Sprache Stellen Sie die angezeigte Sprache für Menüs und angezeigte Meldungen ein.
Page 175
SCOUT® WAAGEN-SERIEN - STX DE-31 Auto-Aus Stellen Sie die Inaktivitätszeit ein, nach der sich das Gerät automatisch ausschaltet. Aus, 1 Minute, 5 Minuten, 10 Minuten Hinweis: Auto-Aus funktioniert nur bei Brutto oder wenn der Sicherheitsschalter in der Stellung Ein ist. Nivellierungshilfe Zeigt, wie die Geräte durch Verstellen der Fü...
DE-32 SCOUT® WAAGEN-SERIEN - STX 5.2.3 Wiegeeinheiten Gehen Sie in dieses Untermenü, um die gewünschten Maßeinheiten zu aktivieren. Hinweis: Aufgrund nationaler Gesetze kann der Indikator einige der aufgeführten Maßeinheiten nicht enthalten. Einheiten Untermenü Milligramm Gramm Kilogramm Karat Unze Feinunze Pfund Pfund-Unze Pennyweight Kornstärke...
SCOUT® WAAGEN-SERIEN - STX DE-33 5.2.4 Datenpflege Datenpflege-Untermenü: Exportieren auf USB Von USB importieren Waage Info Exportieren auf USB* Exportieren Sie Daten auf ein USB Flash-Laufwerk (USB-Stick). Zwei Arten von Daten können exportiert werden: - Anwendungsmodus-Einstellungen = APW, Bezugsgewicht usw. - Menü...
Page 179
SCOUT® WAAGEN-SERIEN - STX DE-35 Nur Einzelne Kopfzeile Stellen Sie die Druckkriterien ein. = Kopfzeilen werden für jeden Druckbedarf gedruckt = Kopfzeilen werden einmal am Tag gedruckt Druckoptionen* Stellen Sie die Druckkriterien ein. Drucker = Druckdaten an einen Drucker = Druckdaten an einen PC Hinweis: Wenn die Sprachauswahl auf Chinesisch, Japanisch oder Koreanisch eingestellt ist, sollen diese Optionen zum aktuellen Peripheriegerät passen.
Page 180
DE-36 SCOUT® WAAGEN-SERIEN - STX Auswahl Probename Legen Sie den Status fest. Legen Sie den Status fest. Alle auswählen = alle Optionen AUS = der Probename wird nicht werden eingeschaltet sein gedruckt. Auswahl aufheben = alle Optionen = der Probename wird gedruckt. werden ausgeschaltet sein Ergebnis Kopfzeile...
Page 181
SCOUT® WAAGEN-SERIEN - STX DE-37 Benutzername Signaturzeile Stellen Sie den Status ein. Legen Sie den Status fest. AUS = der Benutzername wird AUS = die Signaturzeile wird nicht gedruckt. nicht gedruckt. = der Benutzername wird = die Signaturzeile wird gedruckt. gedruckt.
DE-38 SCOUT® WAAGEN-SERIEN - STX Alt-Befehl (Alternativer Druckbefehl) Alternativer Druckbefehl Stellen Sie das alternative Befehlszeichen zum Drucken ein. Einstellungen von A bis Z stehen zur Verfügung. Die Standardeinstellung ist leer außer P.T oder Z. Alternativer Befehl für Tarieren Stellen Sie das alternative Befehlszeichen für Tarieren ein. Einstellungen von A bis Z stehen zur Verfügung.
SCOUT® WAAGEN-SERIEN - STX DE-39 Projektname Gehen Sie auf dieses Menü, um die Projektidentifikation festzulegen. Alphanumerische Einstellungen von bis zu 25 Zeichen stehen zur Verfügung. Die Standardeinstellung ist leer. Fußzeile Ermöglicht das Drucken von GLP-Schriften. Es stehen bis zu 2 Kopfzeilen zur Verfügung.
Wenn der Abschnitt zur Fehlerbehebung Ihr Problem nicht löst oder beschreibt, kontaktieren Sie Ihren autorisierten OHAUS Service-Agent. Für Hilfe oder um den technischen Support in den USA zu erreichen, rufen Sie von 8.00 bis 17.00 Uhr EST. gebührenfrei 1-800-672-7722 ext.
SCOUT® WAAGEN-SERIEN - STX DE-41 TECHNISCHE DATEN 7.1 Spezifikationen Umgebungsbedingungen Nur im Innenbereich verwenden Betriebstemperaturbereich: +5 ° C bis +40 ° C Relative Luftfeuchtigkeit: 10% bis 80% bei 31 ° C, linear abnehmend bis 50% bei 40 ° C, nicht kondensierend ...
