Electrical Information ________________

Electrical Requirements
It is your responsibility to have all electrical connections made
by a properly licensed and competent electrician to ensure
that the electrical installation is adequate and conforms to
local and state regulations or codes. In the absence of such
codes, all electrical connections, materials, and workmanship
must conform to the applicable requirements of the National
Electrical Code ANSI/NFPA NO. 70-LATEST EDITION or in
Canada, the Canadian Electrical Codes Parts 1 & 2 CSA
C22.1-1990 or LATEST EDITION.
IMPORTANT: Failure to comply with these codes or
ordinances, and/or the requirements stipulated in this manual
can result in personal injury or component failure.
NOTE: Component failure due to improper installation will
void the warranty.
Each dryer should be connected to an independently
protected branch circuit. The dryer must be connected with
copper wire only. Do not use aluminum wire, it could create
a fire hazard. The copper conductor wire/cable must be of
proper ampacity and insulation in accordance with electric
codes for making all service connections.
NOTE: The use of aluminum wire will void the warranty.
Wiring diagrams are affixed to the left side panel area behind
the top control (access) door.
IMPORTANT: The dryer must be connected to the electric
supply shown on the data label. In the case of 208 VAC or
230/240 VAC, the supply voltage must match the electric
service specifications of the data label exactly.
WARNING
!
208 VAC and 230/240 VAC are not the same. Any
damage done to dryer components due to improper
voltage connections will automatically void the
warranty.
NOTE: The manufacturer reserves the right to make changes
in specifications at any time without notice or obligation.
113386- 28
Electrical Service Specifications
Gas and Steam – Reversing
ELECTRICAL SERVICE SPECIFICATIONS (PER DRYER)
IMPORTANT: 208 VAC AND 230/240 VAC ARE NOT THE SAME. When
ordering, specify exact voltage.
NOTES: A. When fuses are used they must be dual element, time delay,
current limiting, class RK1 or RK5 ONLY . Calculate/determine
correct fuse value, by applying either local and/or National
Electrical Codes to listed appliance amp draw data.
B. Circuit breakers are thermal-magnetic (industrial) motor curve type
ONLY . For others, calculate/verify correct breaker size according
to appliance amp draw rating and type of breaker used.
C. Circuit breakers for 3-phase (3ø) dryers must be 3-pole type.
SERVICE
VOLTAGE
208
220
230
240
240
380 / 400
380 / 400
416
440
460 / 480
575
* 3-Wire is available.
ELECTRICAL SERVICE SPECIFICATIONS (PER DRYER)
IMPORTANT: 208 VAC AND 230/240 VAC ARE NOT THE SAME. When
ordering, specify exact voltage.
NOTES: A. When fuses are used they must be dual element, time delay,
current limiting, class RK1 or RK5 ONLY . Calculate/determine
correct fuse value, by applying either local and/or National
Electrical Codes to listed appliance amp draw data.
B. Circuit breakers are thermal-magnetic (industrial) type ONLY .
For others, calculate/verify correct breaker size according to
appliance amp draw rating and type of breaker used.
C. Circuit breakers for 3-phase (3ø) dryers must be 3-pole type.
SERVICE
VOLTAGE
220
380
380
230
400
460
208
240
416
480
575
220
440
600
* 3-Wire is available.
www.adclaundry.com
APPROX.
WIRE
PHASE
AMP DRAW
SERVICE
60 Hz
3ø 3 15
3ø 3 14
3ø 3 —
3ø 3 15
3ø 3 —
3ø 3 9
3ø 4* —
3ø 4* —
3ø 3 9
3ø 3 8
3ø 3 7
Electric – Reversing
APPROX.
WIRE
PHASE AMP DRAW
SERVICE
60 Hz
60.5 kW
3ø 3 173
3ø 3 101
3ø 4* —
66 kW
—
3ø 3
3ø 4* —
3ø 3 91
72 kW
3ø 3 215
3ø 3 188
3ø 4* —
3ø 3 95
3ø 3 79
75.6 kW
3ø 3 214
3ø 3 108
78.6 kW
3ø 3 81
CIRCUIT
BREAKER
50 Hz
— 20
— 20
18 25
— 20
18 25
— 15
9 15
10 15
9 15
— 15
— 15
12/8/14
CIRCUIT
BREAKER
50 Hz
—
225
—
150
101 150
184 250
104 150
— 125
—
300
— 250
109 150
— 125
—
100
— 300
—
150
—
1.25
12/8/14
